Ricoh THETA SC2 User Manual

Hide thumbs Also See for THETA SC2:

Quick start manual (40 pages)

Table of Contents

Quick Links

RICOH THETA - User Guide

RICOH THETA

User Guide

file:///C|/r22/en/support/manual/index.html[2019/11/12 2:03:29]

RICOH THETA SC2

(Model: R03030)

RICOH THETA Z1

(Model: R02020)

RICOH THETA V

RICOH THETA SC

Table of Contents

Need help?

Do you have a question about the THETA SC2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ricoh THETA SC2

Page 1 RICOH THETA - User Guide RICOH THETA User Guide RICOH THETA SC2 (Model: R03030) RICOH THETA Z1 (Model: R02020) RICOH THETA V RICOH THETA SC file:///C|/r22/en/support/manual/index.html[2019/11/12 2:03:29]...
Page 2 RICOH THETA - User Guide RICOH THETA S RICOH THETA (Model: RICOH THETA m15) RICOH THETA (2013 model) © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/index.html[2019/11/12 2:03:29]...
Page 3 See below for the details of apps available for RICOH THETA SC2. https://theta360.com/en/about/application/ Images of the basic app for smartphone used throughout this guide are from “RICOH THETA for iPhone” (the basic app for iOS). There may be some differences from “RICOH THETA for Android” (the basic app for Android).
Page 5 Turning the Power On/Off Downloading the App Connecting to a Smartphone via Wireless LAN ® Connecting to a Smartphone via Bluetooth ® Connecting to a Bluetooth Accessory ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/sc2/content/menu-prepare.html[2019/11/12 2:04:10]...
Page 6: Checking The Package
When opening the package, check that the following items are included: RICOH THETA SC2 USB cable Soft case Quick Start Guide Important Message to Customers ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/sc2/content/prepare/prepare_01.html[2019/11/12 2:04:16]...
Page 7: Names Of Camera Parts
RICOH THETA SC2 - User Guide > > Preparation Names of Camera Parts Names of Camera Parts This section explains the names and functions of the buttons, lamps, etc. on the camera. 1. Speaker 2. Microphone 3. Lens Caution Be careful when handling the lens section to avoid damage.
Page 8: Communication Status
Note For the accessories with which proper operation has been confirmed, see the RICOH website. 11. USB terminal (Micro-B) Used to connect the camera to a computer via the provided USB cable. (Details)
Page 9 RICOH THETA SC2 - User Guide : Processing Note The countdown is displayed on the entire OLED panel during the self-timer shooting. ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/sc2/content/prepare/prepare_02.html[2019/11/12 2:04:17]...
Page 10: Charging Time
The time described above is a guide for full charging. The charging time differs according to the remaining battery level. If the remaining battery level is low, it may take time for the camera to be recognized by the computer. ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/sc2/content/prepare/prepare_03.html[2019/11/12 2:04:18]...
Page 11: Turning The Power On/Off
When the camera is connected to a computer with a USB cable, the lamp lights green and the battery is charged. The lamp is unlit when charging is complete. ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/sc2/content/prepare/prepare_04.html[2019/11/12 2:04:19]...
Page 12: Downloading The App
Installing the App for Computer There are some differences between functions provided by the “RICOH THETA for iPhone” (iOS app) and “RICOH THETA for Android” (Android app). The screens of “RICOH THETA for iPhone” (iOS app) are used as examples in this user guide.
Page 13 RICOH THETA SC2 - User Guide Connecting to a > > Preparation Smartphone via Wireless Connecting to a Smartphone via Wireless LAN When the camera is connected to a smartphone via a wireless LAN, you can use the smartphone to capture images remotely, view images, and make function settings.
Page 14: Date And Time Settings
Date and Time Settings The date and time of the camera are synchronized with the smartphone or computer when the camera is connected to the basic app. ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/sc2/content/prepare/prepare_06.html[2019/11/12 2:04:20]...
Page 15 RICOH THETA SC2 - User Guide file:///C|/r22/en/support/manual/sc2/content/prepare/prepare_06.html[2019/11/12 2:04:20]...
Page 16 Date and Time Settings The date and time of the camera are synchronized with the smartphone or computer when the camera is connected to the basic app. ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/sc2/content/prepare/prepare_07.html[2019/11/12 2:04:21]...
Page 17 RICOH THETA SC2 - User Guide Connecting to a > > Preparation ® Bluetooth Accessory ® Connecting to a Bluetooth Accessory ® An accessory can be connected to the camera via Bluetooth 1. Turn on the power of the camera.
Page 18: Connection Information
® Bluetooth connection information. Caution ® If you reset the Bluetooth connection information, the wireless LAN password is also reset. ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/sc2/content/prepare/prepare_09.html[2019/11/12 2:04:21]...
Page 19: Updating The Camera Firmware
RICOH THETA SC2 - User Guide Updating the Camera > Firmware Updating the Camera Firmware Updating the Camera Firmware Using a Computer Updating the Camera Firmware Using a Smartphone ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/sc2/content/menu-update.html[2019/11/12 2:04:10]...
Page 20 Do not disconnect the camera from the computer during the firmware file transfer. Note flash alternately on the OLED panel of the camera during the firmware update. ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. update_01.pdf[2019/11/12 16:08:39]...
Page 21 RICOH THETA SC2 - User Guide Updating the Camera Updating the Camera > > Firmware Using a Firmware Smartphone Updating the Camera Firmware Using a Smartphone The camera firmware can be updated using the basic app for smartphone. The app is required to update the firmware. Download the app from the following site.
Page 22 Do not disconnect the wireless LAN connection between the camera and the smartphone during the firmware file transfer. Note flash alternately on the OLED panel of the camera during the firmware update. ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/sc2/content/update/update_02.html[2019/11/12 2:04:23]...
Page 23: Shooting Still Images
Shooting Still Images Using Only the Camera with the Self-timer Function Shooting Still Images While Connected to a Smartphone with the Self-timer Function Registering the Still Image Shooting Settings with the My Settings Function ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/sc2/content/menu-shooting-photo.html[2019/11/12 2:04:11]...
Page 24 RICOH THETA SC2 - User Guide Shooting Still Images Using > > Shooting Still Images Only the Camera Shooting Still Images Using Only the Camera This section explains basic methods for shooting still images. 1. Turn on the power of the camera.
Page 25 If no more images can be captured, delete images from the camera. Deleting Captured Still Images and Videos Importing Still Images and Videos to a Computer ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/sc2/content/shooting-photo/shooting_photo_01.html[2019/11/12 2:04:23]...
Page 26 RICOH THETA SC2 - User Guide Shooting Still Images While > > Shooting Still Images Connected to a Smartphone Shooting Still Images While Connected to a Smartphone You can capture still images using the basic app for smartphone. 1. Turn on the power of the camera.
Page 27 [Display after shooting] is set to off and videos are not transferred automatically. Transferring Captured Still Images and Videos to a Smartphone The OLED panel and all lamps turn off during exposure. ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/sc2/content/shooting-photo/shooting_photo_02.html[2019/11/12 2:04:24]...
Page 28 RICOH THETA SC2 - User Guide Shooting Still Images Using > > Shooting Still Images Only the Camera with the Self-timer Function Shooting Still Images Using Only the Camera with the Self-timer Function This section explains the shooting method using the self-timer function.
Page 29 If no more images can be captured, delete images from the camera. Deleting Captured Still Images and Videos Importing Still Images and Videos to a Computer ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/sc2/content/shooting-photo/shooting_photo_03.html[2019/11/12 2:04:25]...
Page 30 RICOH THETA SC2 - User Guide Shooting Still Images While > > Connected to a Shooting Still Images Smartphone with the Self- timer Function Shooting Still Images While Connected to a Smartphone with the Self-timer Function You can capture still images using the self-timer function with the basic app for smartphone.
Page 31 Checking and Changing the Shooting Conditions Changed countdown time is kept even if the camera power is turned off. To cancel the self-timer, set [Shooting method] to [Normal shooting]. ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/sc2/content/shooting-photo/shooting_photo_04.html[2019/11/12 2:04:26]...
Page 32 RICOH THETA SC2 - User Guide Registering the Still Image > > Shooting Still Images Shooting Settings with the My Settings Function Registering the Still Image Shooting Settings with the My Settings Function You can register the shooting conditions as “My Settings” using the basic app for smartphone to use the desired settings as defaults when the camera is turned on.
Page 33 If no more images can be captured, delete images from the camera. Deleting Captured Still Images and Videos Importing Still Images and Videos to a Computer ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/sc2/content/shooting-photo/shooting_photo_05.html[2019/11/12 2:04:26]...
Page 34: Shooting Videos
Shooting Videos Using Only the Camera with the Self-timer Function Shooting Videos While Connected to a Smartphone with the Self-timer Function Registering the Video Shooting Settings with the My Settings Function ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/sc2/content/menu-shooting-movie.html[2019/11/12 2:04:11]...
Page 35 RICOH THETA SC2 - User Guide Shooting Videos Using > > Shooting Videos Only the Camera Shooting Videos Using Only the Camera This section explains basic methods for shooting videos. 1. Turn on the power of the camera. 2. Press the mode button to select the video shooting mode.
Page 36 If no more time remains for shooting, delete images from the camera. Deleting Captured Still Images and Videos Importing Still Images and Videos to a Computer ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/sc2/content/shooting-movie/shooting_movie_01.html[2019/11/12 2:04:27]...
Page 37 RICOH THETA SC2 - User Guide Shooting Videos While > > Shooting Videos Connected to a Smartphone Shooting Videos While Connected to a Smartphone You can capture videos using the basic app for smartphone. 1. Turn on the power of the camera.
Page 38 The camera may get hot if you record a video for a long period of time or perform shooting multiple times in quick succession. In this case, the camera may stop operating to prevent damage from high temperatures. ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/sc2/content/shooting-movie/shooting_movie_02.html[2019/11/12 2:04:28]...
Page 39 RICOH THETA SC2 - User Guide Shooting Videos Using > > Shooting Videos Only the Camera with the Self-timer Function Shooting Videos Using Only the Camera with the Self-timer Function This section explains the shooting method using the self-timer function.
Page 40 If no more images can be captured, delete images from the camera. Deleting Captured Still Images and Videos Importing Still Images and Videos to a Computer ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/sc2/content/shooting-movie/shooting_movie_03.html[2019/11/12 2:04:29]...
Page 41 RICOH THETA SC2 - User Guide Shooting Videos While > > Connected to a Shooting Videos Smartphone with the Self- timer Function Shooting Videos While Connected to a Smartphone with the Self-timer Function You can record videos using the self-timer function with the basic app for smartphone.
Page 42 The camera may get hot if you record a video for a long period of time or perform shooting multiple times in quick succession. In this case, the camera may stop operating to prevent damage from high temperatures. ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/sc2/content/shooting-movie/shooting_movie_04.html[2019/11/12 2:04:30]...
Page 43 RICOH THETA SC2 - User Guide Registering the Video > > Shooting Videos Shooting Settings with the My Settings Function Registering the Video Shooting Settings with the My Settings Function You can register the shooting conditions as “My Settings” using the basic app for smartphone to use the desired settings as defaults when the camera is turned on.
Page 44 If no more images can be captured, delete images from the camera. Deleting Captured Still Images and Videos Importing Still Images and Videos to a Computer ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/sc2/content/shooting-movie/shooting_movie_05.html[2019/11/12 2:04:30]...
Page 45 RICOH THETA SC2 - User Guide Shooting in the Preset > Shooting Modes Shooting in the Preset Shooting Modes Shooting Still Images in the Preset Shooting Modes ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/sc2/content/menu-shooting-preset.html[2019/11/12 2:04:12]...
Page 46: Night View
The seam between the images captured with the front and rear lenses is located in the center of the entire image. The seam between the images captured with the front and rear lenses may be noticeable. ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/sc2/content/shooting-preset/shooting_preset_01.html[2019/11/12 2:04:31]...
Page 47 Deleting Captured Still Images and Videos Transferring Captured Still Images and Videos to a Smartphone Blurring Still Images (iOS App Only) Sharing Still Images and Videos ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/sc2/content/menu-phone.html[2019/11/12 2:04:13]...
Page 48 RICOH THETA SC2 - User Guide Viewing and Sharing Using Viewing Captured Still > > a Smartphone Images and Videos Viewing Captured Still Images and Videos The basic app for smartphone can be used to view images saved in the camera or transferred to a smartphone.
Page 49 You can display a desired area of a spherical image taken with the camera, and zoom in or out to check details in the image. The screens of “RICOH THETA for iPhone” are used as examples in the following descriptions. Zooming in or out: Pinch out, pinch in Changing the displayed area: Swipe or flick Tap the screen when an image is displayed in the Viewer to display the buttons and perform various operations.
Page 50 : Returns the display area to the default state. : Repeats playback from the beginning. : Plays back/Pauses the video. : Changes the display format. ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/sc2/content/phone/phone_01.html[2019/11/12 2:04:32]...
Page 51 RICOH THETA SC2 - User Guide Viewing and Sharing Using Deleting Captured Still > > a Smartphone Images and Videos Deleting Captured Still Images and Videos Images that have been saved in the camera or transferred to a smartphone can be deleted.
Page 52 RICOH THETA SC2 - User Guide Images in the camera cannot be deleted while shooting video. ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/sc2/content/phone/phone_02.html[2019/11/12 2:04:33]...
Page 53 RICOH THETA SC2 - User Guide Transferring Captured Still Viewing and Sharing Using > > Images and Videos to a a Smartphone Smartphone Transferring Captured Still Images and Videos to a Smartphone Images saved in the internal memory, such as images taken using only the camera, can be transferred to a smartphone.
Page 54 Videos are not transferred automatically. Images in the camera cannot be transferred while shooting video. ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/sc2/content/phone/phone_03.html[2019/11/12 2:04:34]...
Page 55 You can edit a still image using the editing app “THETA+” by selecting [Edit in THETA+] after tapping . For details on the “THETA+”, see the following URL. https://theta360.com/en/about/application/edit.html#RICOH-THETA-PLUS ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/sc2/content/phone/phone_04.html[2019/11/12 2:04:34]...
Page 56 RICOH THETA SC2 - User Guide Viewing and Sharing Using Sharing Still Images and > > a Smartphone Videos Sharing Still Images and Videos Captured images can be directly uploaded to a social networking service from the basic app. 1. Turn on the power of the camera.
Page 57 LAN, change the wireless LAN connection to an access point. When using “RICOH THETA for Android” to connect the smartphone to the camera via a wireless LAN, you may need to switch network connections to post images. Therefore, when you want to use the camera by connecting it to the smartphone after posting images, reconnect them.
Page 58 Importing Still Images and Videos to a Computer Viewing Still Images on a Computer Viewing Videos on a Computer Sharing Still Images from a Computer Sharing Videos from a Computer ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/sc2/content/menu-pc.html[2019/11/12 2:04:13]...
Page 59: Recommended Computer Environment
Connections to USB ports that have been added using an expansion feature (PCI bus, etc.) are not supported. Correct operation may not be possible when used in combination with a USB hub or other USB device. ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/sc2/content/pc/pc_01.html[2019/11/12 2:04:36]...
Page 60 1. Access the following site and download the basic app for computer. https://support.theta360.com/en/download/ 2. Follow the instructions on the screen to install the basic app for computer. ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/sc2/content/pc/pc_02.html[2019/11/12 2:04:36]...
Page 61 Caution Do not turn off the power or remove the USB cable while importing images. Fully insert the USB cable when connecting it. ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/sc2/content/pc/pc_03.html[2019/11/12 2:04:37]...
Page 62 A full screen display can be launched by selecting [Display] → [Full Screen]. Press the “Esc” key to close the full screen display. Closing the Still Image Select [File] → [Close] in the menu. ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/sc2/content/pc/pc_04.html[2019/11/12 2:04:37]...
Page 63 RICOH THETA SC2 - User Guide Viewing and Sharing Using Viewing Videos on a > > a Computer Computer Viewing Videos on a Computer Using the basic app for computer allows you to convert videos taken on the camera and then scroll, zoom in, and zoom out while viewing spherical videos on the computer.
Page 65 An account for each social networking service is required to share images. When [Unlisted] is selected for shared images, only people who have the upload location URL can view the images. ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/sc2/content/pc/pc_06.html[2019/11/12 2:04:39]...
Page 66 In order to view MP4 files received as an e-mail attachment on a smartphone, save the MP4 file to the smartphone, select [Photos] or [Photo] on the basic app, and then play back the MP4 file. ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/sc2/content/pc/pc_07.html[2019/11/12 2:04:39]...
Page 67: Changing The Settings
Checking and Changing the Shooting Conditions Checking and Changing the Camera Settings Setting the Camera to the Light/Sound Off Mode Turning the Power Off Forcibly ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/sc2/content/menu-settings.html[2019/11/12 2:04:14]...
Page 68 RICOH THETA SC2 - User Guide Checking and Changing the > > Changing the Settings Shooting Conditions Checking and Changing the Shooting Conditions Various settings such as the exposure mode and white balance can be set to suit the shooting conditions.
Page 69 RICOH THETA SC2 - User Guide Still image: Auto (ISO 64 to 1600, upper limit settable); ISO sensitivity priority/Manual (ISO 64 to 3200) Video: Auto (ISO 64 to 6400, upper limit settable) White balance: Auto: Adjusted automatically. Outdoor: Adjusted for shooting outdoors (when sunny).
Page 70 Changing the Preset Shooting Mode Settings in the upper right-hand corner of the screen in the preset shooting mode to check and change various settings for the preset shooting. ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/sc2/content/settings/settings_01.html[2019/11/12 2:04:40]...
Page 71: Setting Items
RICOH THETA SC2 - User Guide Checking and Changing the > > Changing the Settings Camera Settings Checking and Changing the Camera Settings The status of the camera can be checked and various settings can be made with the basic app for smartphone.
Page 72 The account for each social networking service can be set. * Settings can only be checked and changed when the camera is connected to the smartphone. ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/sc2/content/settings/settings_02.html[2019/11/12 2:04:41]...
Page 73 1. Press and hold the mode button and self-timer button simultaneously. The camera enters the light/sound off mode To cancel the light/sound off mode, press a button other than the shutter button. ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/sc2/content/settings/settings_03.html[2019/11/12 2:04:42]...
Page 74 You can forcibly turn off the camera when it is operating incorrectly or becomes inoperable. 1. Press and hold the power button. The power is forcibly turned off. ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/sc2/content/settings/settings_05.html[2019/11/12 2:04:42]...
Page 75: Troubleshooting
> Troubleshooting Troubleshooting If the camera does not work properly or you think there may be a malfunction, check the following support website: https://support.theta360.com/en/ ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/sc2/content/troubleshoot.html[2019/11/12 2:04:14]...
Page 76: Additional Information
RICOH THETA SC2 - User Guide > Additional Information Additional Information Specifications Separately Sold Products Cautions on Use Care and Storage Safety Precautions Trademarks ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/sc2/content/menu-add_info.html[2019/11/12 2:04:15]...
Page 77: Specifications
RICOH THETA SC2 - User Guide > > Additional Information Specifications Specifications Image sensor: 1/2.3" back-illuminated CMOS image sensor × 2 File size (still images): 5376 × 2688 File size and frame rate (videos): 3840 × 1920 / 29.97 fps 1920 ×...
Page 78 Charge the battery by connecting the camera to a computer using the provided USB cable. (*5) The number of images that can be taken and recording time are guides based on RICOH’s measurement method. The actual number differs according to the usage conditions.
Page 80: Separately Sold Products
RICOH THETA SC2 - User Guide > > Additional Information Separately Sold Products Separately Sold Products See below for the accessories sold separately. https://theta360.com/en/about/theta/accessory.html ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/sc2/content/add_info/add_info_02.html[2019/11/12 2:04:43]...
Page 81: Cautions On Use
Charge the battery in an area with an ambient temperature of 10 to 40°C (50 to 104°F). Charging in a hot area may cause the battery to deteriorate. Charging in a cold area may prevent sufficient charging. ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/sc2/content/add_info/add_info_03.html[2019/11/12 2:04:44]...
Page 82: Care And Storage
(in your pocket, etc.) to help to keep free from dust or fiber particles. Precautions Regarding Care of the Camera Be sure to turn the power off. ← Back ▲ Back to Top © 2019 Ricoh Company, Ltd. All Rights Reserved. file:///C|/r22/en/support/manual/sc2/content/add_info/add_info_04.html[2019/11/12 2:04:45]...
Page 83: Safety Precautions
RICOH THETA SC2 - User Guide > > Additional Information Safety Precautions Safety Precautions Warning Symbols Various symbols are used throughout this user guide and on the product to prevent physical harm to you or other people and damage to property. The symbols and their meanings are explained below.
Page 84 RICOH THETA SC2 - User Guide Stop use immediately if you notice something unusual such as an abnormal smell, smoke, or overheating. Ask your nearest dealer or service center for repair. Warning Turn off the power immediately if any metallic object, water, liquid, or other foreign object gets into the camera. And contact the nearest service center.
Page 86 The Bluetooth word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Ricoh Company Ltd. is under license. Instagram and the Camera logos are trademarks of Instagram, LLC in the United States and elsewhere.

This manual is also suitable for:

R03030 Theta z1 R02020 Theta v Theta sc
