Juplink Vanin RX4-1500 Wi-Fi6 Quick Start Manual

Quick Start Guide-2
RX4-1500
Wi-Fi6 Router
V A N I N

Step 1: Basic Installation

Modem Apower Outlet
AC-DC Power cord
Internet Modem LAN out
Please ensure that the router has been turned on and connected to the Internet Service Provider(ISP)
① Connect the power adapter to the router's power port and plug the other end into a power outlet. The LED indicator becomes solid green
② Connect the WAN port of the router to a LAN port of your modem
③ Connect your device to the router.

Step 3: Log In to Your Router

① Lauch a web browser on the device which has been connected
to the repeater,Enter 192.168.0.1 in the address bar to log in.
http://192.168.0.1
② Username:admin / Passwrod:admin
Login 192.168.0.1 Juplink RX4-1500 router
Username
admin
Password
admin
Cancel Login
③ Click Login Button below

Step 5: 2.4G Network Setting

① Select Network then select 2.4G setting.
② You can modify your Wi-Fi Name (SSID) , Wi-Fi Password (Key)
Authentication Mode and Encryption Mode
③ After click Apply/Save Button, The router will reboot and you can
reconnected by using the new SSID and New Key (Password)

LED Status Indicators

LED indicator Status
Solid on
Green LED Indicator
Fast blinking

Ports / Buttons

WPS To start the WPS negotiation process of the router
RST To reset the router
LAN 1. 2. 3. 4 To connect to the wired devices such as computers, switches, ect
WAN Port To conncet this router to the internet
Power To connect to the power cord
Ethernet WAN in Front Panel LED Green

Step 4: Set up Internet Connection

Method 1 : Connect to the Internet Automatically

① Select DHCP type from the Addressing Type drop-down list
② Set 2.4G /5G SSID ( Wi-Fi Name ) and
2.4G /5G SSID Network Key ( Wi-Fi password ) then click Continue
Note: The Default Password Both 2.4G and 5G is: 12345678

Step 6: 5G Network Setting

① Select Network then select 5G setting.
② You can modify your Wi-Fi Name (SSID) , Wi-Fi Password (Key)
Authentication Mode and Encryption Mode
③ After click Apply/Save Button, The router will reboot and you can
reconnected by using the new SSID and New Key (Password)
Description
The router is starting to connect or has been successfully connected
to the internet.
The router is performing WPS negotiation
Description

Step 2: Connect Your Router

1. Basic connection - Wirelessly
① Find the SSID (Network Name) Juplink-RX4-1500_5G or
Juplink-RX4-1500 on phone or computer
Computer
WLAN
Juplink-RX4-1500
Juplink-RX4-1500_5G
Juplink-RX4-1500_5G
Juplink-RX4-1500
Juplink Wi-Fi 6 Router
② Click the network icon of your device or go to Wi-Fi Settings of your
smart device, and then select the SSID Juplink-RX4-1500_5G or
Juplink-RX4-1500 to join the network.
Ensure that Mobile Data ( if any ) is disabled.

Method 2 : Connect to the Internet - PPPoE

① Select PPPoE type from the Addressing Type drop-down list
② Enter the Username and Password provided by your ISP.
② Set 2.4G /5G SSID ( Wi-Fi Name ) and
2.4G /5G SSID Network Key ( Wi-Fi password ) then click Continue
What' s in the Box
1 x Juplink RX4-1500 Router
1 x Ethernet Cable
1 x AC-DC Adapter
1 x Quick Start Guide
Manufacturer's information
Nanjing Juplink Intelligent Technologies Co.,Ltd.
Address: No. 757 Dixiu Road, Binjiang Economic Development Zone
Jiangning District, Nanjing Technical
Support Email: Support@juplink.com
Made in China
Website : www.juplink.com
Email : Support@juplink.com
Before Setting
To customize your wireless network
connection and other advanced repeater
settings, please go to
www.juplink.com/pages/contact-us
to download RX4-1500 updated Firmware
and User Guide for more information.
Operating Conditions
Working Temperature: 0~45°C / 32~113°F
Working Humidity: 10%~90% RH
(No condensation)
Storage Temperature:-40~85°C / -40~185°F
Storage Humidity: 5%~95% RH
(No condensation)
2. Basic connection - WPS Button
Wireless devices that support WPS, including Android phones, tablets,
and most USB network adapters, can be connected to your router
through this method.
Back of your router view
Smart Device
① Tap the WPS icon on the device's
② Within two minutes, press the button on your router.
Note : ① WPS is not supported by iOS devices.
② The WPS function cannot be configured if the wireless function
of the router is disabled. Also, the WPS function will be disabled if
your wireless encryption is WEP. Please make sure the wireless
function is enabled and is configured with the appropriate
encryption before configuring the WPS.
③ Confirm your WiFi name and password and click OK button
④ The router will reboot and you can reconnect by using the new
Wi-Fi Name ( SSID ) and new password in 10 Seconds.
Note: Generally, the addressing type is DHCP. If it is PPPOE,
you need to fill in the username and password which
was provided by your ISP
Please refer to
Method 2: Connect to the Internet - PPPoE
WLAN
Juplink-RX4-1500
Juplink-RX4-1500_5G
