BEACH WAGON
Cart with parking brake / Bollerwagen mit Parkbremse /
Bolderwagen met parkeerrem / Le chariot de plage avec frein de stationnement /
Carro con freno de estacionamiento / Carretto con freno di stazionamento
USER MANUAL
GEBRAUCHSANWEISUNG
GEBRUIKSHANDLEIDING
MODE D'EMPLOI
MANUAL DE USUARIO
INSTRUZIONE PER L'USO
Have Fun!
Read these instructions carefully before use.
WARNING
This beach wagon is only for the transportation of
children older than 36 months and a maximum
transport weight of 80 kg.
WARNING
Check the beach wagon before use that it is setup
correctly. This beach wagon can hold maximum
2 children at one time.
WARNING
Do not sit on the tailgate, to avoid roll-over risk.
The wagon shall be used under the supervision
of adult in walking speed.
WARNING
Do not leave your child unattended. Always have the
beach wagon in break-position when moving the
children in and out the beach wagon.
WARNING
This product is not suitable to
attach to a vehicle.
info@axi.com
www.axi.com
WARNING
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Axi A030.190.00
Summary of Contents for Axi A030.190.00
- Page 1 Cart with parking brake / Bollerwagen mit Parkbremse / Bolderwagen met parkeerrem / Le chariot de plage avec frein de stationnement / Carro con freno de estacionamiento / Carretto con freno di stazionamento info@axi.com www.axi.com WARNING Read these instructions carefully before use.
- Page 2 BEACH WAGON A030.190.00 1. COMPONENTS 1x body 1x drawbar 2x shaft 2x end panel 2x side panel 1x handle 1x bottom plate 4x wheel cap 1x bushing 1x connection parts 1x safety pin 1x nuts (M4) 4x washer (M20) 8x wood screw...
- Page 3 BEACH WAGON A030.190.00 1x screw 3x nuts 4x washer 2x screw (M4 x 3 cm) (M6) (M8) (M6 x 2 cm) 8x screw 8x nuts 4x side panel pro les 8x washer (M3,5 x 3,5 cm) (M4) (M8) (M4) Please note: First, screw the components loosely together.
- Page 4 BEACH WAGON A030.190.00 2. ASSEMBLING F - handle P - brake line S - cable tie Have Fun!
- Page 5 BEACH WAGON A030.190.00 A - body B - drawbar K - nut (M4) I - nut X - screw C - 2x shaft Have Fun!
- Page 6 BEACH WAGON A030.190.00 W - 4x wheel M - 4x washer H - 4x wheel cap Have Fun!
- Page 7 BEACH WAGON A030.190.00 L - safety pin F - handle Have Fun!
- Page 8 BEACH WAGON A030.190.00 T - brake swing R - 2x spring Z - 1x nut U - brake pole V - long brake pole ZA - 4x washer J - connection parts T - brake swing Z - 2x nuts...
- Page 9 BEACH WAGON A030.190.00 J - connection parts Q - nuts with collar P - brake line Please place the brake pole in the right position and make sure that the distance between the end of the brake pole and the wheel rim is 3 mm (see image below).
- Page 10 BEACH WAGON A030.190.00 G - ground plate Put the bottom plate on the body E - 2x side panel ZC - 8x screw ZD - 8x nut ZE - 4x side panel pro les ZF - 8x washer Have Fun!
- Page 11 BEACH WAGON A030.190.00 E - 2x side panel D - 2x end panel Have Fun!
- Page 12 BEACH WAGON A030.190.00 O - 8x wood screws Pre-drilled holes Use the pre-drilled holes in the end panels to place the screws WARNING: Please make sure all the screws are tight before use Have Fun!
-
Page 13: Parking Brake
BEACH WAGON A030.190.00 3. PARKING BRAKE 1. Pull the brake on the beach wagon 2. Press on the botton 3. Release your hand - the beach wagon is now in parking modus 4. To release the parking modus, please pull the break again and release your hand 2. - Page 14 Have Fun! A Pragma Brand AXI is one of our brands with awesome products of great quality that off er hours of active fun! Article number / Artikelnummer / Artikelnummer / info@axi.com Numéro d’article / Número de artículo / Codice articolo www.axi.com...
