Summary of Contents for Synapse SDI110
Page 1
Warranty & Registration Thank you for purchasing a Bluefish444 Synapse SDI110 For your warranty to be valid and to obtain free email and telephone support please register your product at; www.bluefish444.com , select “Register here”. Or type in http://www.bluefish444.com/products/warranty/register.asp. You will be presented with a Product Registration page.
Page 3
Synapse converters support the following Input, and Output formats: Synapse converters are con gured via DIP switches on the side of the converter. SDI conversion to the HDMI signal includes video scaling, PsF mode and de-interlacing, all con gured via the DIP switches.
Page 4
NTSC - i59,94 525p29,97 PsF Mode O PsF Mode On De-Interlace O De-Interlace On Synapse converters come with Status LED’s for each connection these LED’s can be used to diagnose connection issues. See table below: LED Status Off Green Orange...
