Kingsman PVH58FM Installation Instructions Manual

Flush mount horizontal power vent
Table of Contents

Advertisement

Quick Links

WARNING
Improper installation, adjustment, alteration, service, or
maintenance can cause injury or property damage. Refer
to the owner's information manual provided with this
appliance. For assistance or additional information,
consult with a qualified installer, service agency, or the
gas supplier.
WARNING
If the information in these instructions is not followed
exactly, a fire or explosion may result causing property
damage, personal injury, or loss of life.
READ THIS COMPLETE MANUAL BEFORE BEGINNING INSTALLATION.
CONSUMER: R
INSTALLATION TO BE DONE BY A QUALIFIED INSTAL LER.
The PVH58FM Horizontal Flush Mount Power Vent is intended
for use where standard venting configurations are not possible.
MILLIVOLT/STANDING PILOT NOTE:
Downward vertical vent runs are NOT permitted for models that
are equipped with millivolt / standing pilot ignition.
INTERMITTENT PILOT NOTE:
For units equipped with Proflame 1 or Proflame 2 ignition
system, downward vertical vent runs are permitted provided that
the Cold Climate Switch (Standing Pilot Mode) is NOT used.
All electrical installations much be performed by a qualified
electrician to the latest Canadian Electrical Code (CSA C22.1 for
Canada), and/or U.S. National Electrical Code (ANSI/NFPA 70 for
the USA).
ELECTRICAL SPECIFICATIONS
VOLTS: 120VAC 60Hz 1 Phase
AMPS: 1A
Installation Instructions
INSTALLER: L
EAVE THIS MANUAL WITH THE APPLIANCE
ETAIN THIS MANUAL FOR FUTURE REFERENCE
Model PVH58FM
F
M
H
LUSH
OUNT
ORIZONTAL
K
F
INGSMAN
IREPLACES
A Division of R-Co. Inc.
2340 Logan Avenue
Winnipeg, MB R2R 2V3
Canada
Ph: (204) 632-1962
Printed in Canada November 13, 2019 Part No. 58PVHFM-MAN
P
V
OWER
ENT
Recognized
Component
.
.

Advertisement

Table of Contents
loading

Summary of Contents for Kingsman PVH58FM

  • Page 1 CONSUMER: R ETAIN THIS MANUAL FOR FUTURE REFERENCE INSTALLATION TO BE DONE BY A QUALIFIED INSTAL LER. The PVH58FM Horizontal Flush Mount Power Vent is intended for use where standard venting configurations are not possible. MILLIVOLT/STANDING PILOT NOTE: Downward vertical vent runs are NOT permitted for models that are equipped with millivolt / standing pilot ignition.
  • Page 2: Table Of Contents

    PVH58FM Intermittent Pilot Ignition (IPI) System Connections (Basic) ........................... 16 Recommended Method of Connection ....................................16 PVH58FM Operating the Receiver without Batteries for EGT / EGTM Remote Controls ....................17 Recommended Method of Connection ....................................17 PVH58FM Intermittent Pilot Ignition (IPI) System Connections (with Accessories) ......................18 Recommended Method of Connection ....................................
  • Page 3: Warnings, Installations, And Operations

    ARNINGS NSTALLATIONS PERATIONS Installation Regulations This gas appliance must be installed by a qualified installer in accordance with local building codes, or—in the absence of local codes—with the current CAN/CSA-B149.1 or .2 Installation Code (in Canada), or the current National Fuel Gas Code Z223.1- NFPA 54 (in the USA). All electrical installations much be performed by a qualified electrician to the latest Canadian Electrical Code CSA C22.1 (for Canada), and/or U.S.
  • Page 4: Operations And Maintenance Instructions

    Gas fired appliances may be used only for supplemental heat and/or decorative purposes, and under no circumstances shall they provide a primary heat source. This appliance must not be connected to a chimney flue serving a separate solid-fuel burning appliance. NOTE: It is recommended that a Carbon Monoxide (CO) Detector be installed in or near bedrooms and on all levels of your home.
  • Page 5: Pvh58Fm Installation Overview

    Hard Pipe or Flex (page 7), and Venting Configurations (page 9) sections of this manual. Install PVH58FM Wall Thimble if mounting in a combustible wall. Refer to Openings and Wall Thimble Installation section on page 11. Install PVH58FM Power Vent (refer to Power Vent Mounting section) and venting.
  • Page 6: Venting Clearances

    ENTING LEARANCES NOTES Clearances are to the edge of terminal plate, add 5-1/2” to clearances to arrive at center line. Local Codes or Regulations may require different clearances. Figure 2 - General clearances. Clearance above a veranda, porch, deck, or balcony or other combustible surface is 27”. Clearance above grade is 12in [30cm] min Clearance to window or door that may be opened.
  • Page 7: Venting Hard Pipe Or Flex

    ENTING IPE OR Z57DFA DuraVent Hard Pipe Adapter The PVH58FM Power Vent is approved for use with M&G (5/7” to 5/8” at Flue of Fireplace) DuraVent DirectVent Pro Direct Vent system (Model DV-GS Series), SECTION 2 DIRECT VENT HARD PIPE 4 x 6-5/8”...
  • Page 8: Adapters And Adapter Kits

    DAPTERS AND DAPTER Adapters at Fireplace Adapters at Termination ZDVDKA Z47PVA DuraVent Fireplace Adapter Flex Pipe Adapter Kit ZDVDFA & Z58DFA Z57PVA DuraVent Fireplace Adapter Flex Pipe Adapter Kit ZDVDRA Z58PVA DuraVent Reducer Flex Pipe Adapter Kit Z57DFA ZDVDIA DuraVent Hard Pipe Adapter DuraVent Hard Pipe Adapter Z69DFA Z69PVA...
  • Page 9: Venting Configurations

    ENTING ONFIGURATIONS Maximum Maximum vent length is 125ft [38.1m] plus six 90° elbows with Air Intake setting at LOW. Termination MUST NOT be below unit. Refer to the Air Intake Adjustment section of this manual to adjust Air Intake. This Power Vent can be installed up to 8ft [2.4m] below the installed fireplace on runs less than 100ft [30.4m] and not more than four 90°...
  • Page 10: Pvh58Fm Dimensions

    PVH58FM D IMENSIONS Figure 5 – PVH58FM unit general dimensions. BEND OUT SIX (6) STANDOFF TABS Figure 6 - PVH58FM Wall Thimble general dimensions. Page 10...
  • Page 11: Openings And Wall Thimble Installation

    PENINGS AND HIMBLE NSTALLATION The Wall Thimble is installed on the frame side. A Frame Opening of 12-9/16” x 13-9/16” [31.9cm x 34.4cm] is required for the Thimble to properly mount. To install, bend the six [6] standoff tabs on the Wall Thimble as shown in Figure 7, orient the assembly so that the bottom is open, insert into the wall frame, and secure with 5 screws.
  • Page 12: Pvh58Fm Recess Installation

    NSTALLATION The PVH58FM Power Vent unit allows for a recess installation up to 4-1/2 inches [11.4cm] into the wall. Use silicone or insulating foam to properly provide a waterproof seal. Secure Venting Adapters to Power Vent unit by fastening them to the Attachment Straps with screws.
  • Page 13: Pvh20H Main Wiring Harness Extension

    XTENSION The PVH58 / PVH58FM Power Vent is supplied with a 20ft [6m] wiring harness. This harness can be used on both the main Power Vent assembly and the Double Pole Switch assembly. Should more length be required, additional Harness Extensions can be ordered (PVH20H) and daisy-chained together.
  • Page 14: Pvh58Fm Millivolt System Connections

    PVH58FM M ILLIVOLT YSTEM ONNECTIONS MV Valve PVH58FM Speed Kit 58FM-RHEO PVH58FM See page 23. Power Vent Control Module MV Model FIREPLACE IS SUPPLIED WITH ONE JUNCTION BOX. ADDITIONAL OUTLETS MAY BE REQUIRED. CONSULT A QUALIFIED ELECTRICIAN. DPST Switch (Supplied) Figure 14 - Connecting Power Vent to a Millivolt system.
  • Page 15: Pvh58Fm Power Vent Control Module (Pvcm) Schematics - Millivolt

    PVH58FM P (PVCM) S OWER ONTROL ODULE CHEMATICS ILLIVOLT Page 15...
  • Page 16: Pvh58Fm Intermittent Pilot Ignition (Ipi) System Connections (Basic)

    First ensure the entire IPI system is working properly with connecting any Power Vent components. Then connect the Power Vent Control Module as shown in the diagram below. In the USA, thermostats are NOT PERMITTED for Vented Gas Fireplaces (ANSI Z21.50b-2016-Decorative) PVH58 / PVH58FM PVH58FM Speed Kit 58FM-RHEO See page 23.
  • Page 17: Pvh58Fm Operating The Receiver Without Batteries For Egt / Egtm Remote Controls

    First ensure the entire IPI system is working properly with connecting any Power Vent components. Then connect the Power Vent Control Module as shown in the diagram below. In the USA, thermostats are NOT PERMITTED for Vented Gas Fireplaces (ANSI Z21.50b-2016-Decorative) PVH58 / PVH58FM PVH58FM Speed Kit 58FM-RHEO See page 23.
  • Page 18: Pvh58Fm Intermittent Pilot Ignition (Ipi) System Connections (With Accessories)

    In the USA, thermostats are NOT PERMITTED for Vented Gas Fireplaces (ANSI Z21.50b-2016-Decorative) Harness Legend PV1A – Valve PV1B – Orange Wire on 912 Harness PV2 – Power Vent PVH58 / PVH58FM PV3A – Green Wire PVH58FM Speed Kit on both 912 Harness 58FM-RHEO Thermodisc and 905 Harness See page 23.
  • Page 19: Pvh58Fm Power Vent Control Module (Pvcm) Schematics - Intermittent Pilot Ignition (Ipi)

    PVH58FM P (PVCM) S – I (IPI) OWER ONTROL ODULE CHEMATICS NTERMITTENT ILOT GNITION Page 19...
  • Page 20: Pvh58Fm Proflame 2 (Pf2) System Connections (With Accessories)

    2 (PF2) S ROFLAME YSTEM ONNECTIONS WITH CCESSORIES In the USA, thermostats are NOT PERMITTED for Vented Gas Fireplaces (ANSI Z21.50b-2016-Decorative) PVH58 / PVH58FM PVH58FM Speed Kit 58FM-RHEO See page 23. PF2 Power Cord 584-PWR-C 110VAC Fan Kit 58PVH Wire Harness...
  • Page 21: Pvh58Fm Proflame 2 (Pf2) Power Vent Preparations

    PVH58FM P 2 (PF2) P ROFLAME OWER REPARATIONS NOTE: PVC58IPI Power Vent Control module is NOT REQUIRED for Proflame 2 systems. Prior to making connections, two items in the Proflame 2 system must be slightly modified for it to operate in Power Vent configuration:...
  • Page 22: Pvh58Fm Power Vent Control Module (Pvcm) Schematics - Proflame 2 (Pf2)

    PVH58FM P (PVCM) S – P 2 (PF2) OWER ONTROL ODULE CHEMATICS ROFLAME IMPORTANT To ENABLE Power Vent mode, be sure to REMOVE INTERNAL JUMPER from circuit board. Page 22...
  • Page 23: Pvh58Fm Power Vent Air Flow Adjustment

    DJUSTMENT The PVH58FM is shipped with Variable Speed Switch to adjust discharge air flow rate based on specific venting configuration. Once the fireplace appliance has been completely installed and setup, the flame characteristics can be adjusted to achieve optimum performance and aesthetics.
  • Page 24: Pvh58Fm Troubleshooting

    Vacuum switch is not closed. Check / replace vacuum hose. Check / replace vacuum switch. Main Burner Flame is lazy, and sooting is Air Intake Requires Adjustment See PVH58FM Power Vent Air Flow occurring. Adjustment section. Leaking Exhaust Vent Check Installation Main Burner Flame is running very fast.
  • Page 25: Pvh58Fm Parts List

    Z57PVA* Pipe Reducer 8”Sm – 7”Sm, ZDV5FC (Adapts PVH58FM to accept 5/7” Flex Pipe) * One 12” section of hard pipe must be connected directly to the Power Vent before any adapters are connected. Order the appropriate lengths of venting (see below).
  • Page 26 ZDV7FCL Flex Clamp 7” Diameter ZDV10FCL Flex Clamp 10” Diameter ZDV7SS Spring – Standoff Spacer for Inner Pipe PVH58FM TERMINATION COMPONENT PARTS 58FM-RHEO Power Vent Variable Speed Control 58FM-HR Power Vent Speed Control Wire Harness 58PVH-230S Blower Motor and Housing Assembly...
  • Page 27 During the first year after installation, we will provide a replacement for any component part of your unit found to be defective in materials or workmanship, including labour costs. Repair work requires prior approval by Kingsman, labour costs are based on a predetermined rate schedule and any repair work must be done through an authorized Kingsman dealer.
