Summary of Contents for Freedom Eye Electronic Reading Aid
- Page 1 Electronic Reading Aid User’s Guide www.freedom-eye.com...
-
Page 2: Table Of Contents
www.freedom-eye.com Table of Contents Precaution…..………………………….………………………….…2 Overview…..………………..…………...……………………..3 Open Box and Unpack Items……………………………….……3 Part Names & Functions….……….……………..……...………...4 Safety and Maintenance……………….………………...…..……5 Use the Reading Aid on TV………………..…….………………..6 Install the Reading Aid……………………………………………6 Start to Work……………………………………………………...9 Video Mode………...………………….…………….……………9 Magnification Adjustment………………………….…………..…10 Freeze Image…………………………………………………….10 Trouble Shooting…………………………..…………………….…11 Warranty card……………………………………………………...12... -
Page 3: Precaution
Welcome Thank you for purchasing an Electronic Reading Aid. It enables you to read better on TV easily. Please take a moment to read through this manual. Its contents will help you to get the best use of the device. -
Page 4: Overview
Overview Open Box and Unpack Items: 1 x Electronic Reading Aid 1 x power adaptor with power/video cable... -
Page 5: Part Names & Functions
www.freedom-eye.com 1 x carry bag 1 x user’s guide Part Names & Functions... - Page 6 www.freedom-eye.com 1. Power on/off 5. Minify 2. Video mode 6. Power indicator 3. Freeze & Unfreeze 7. DC plug 4. Magnify 8. Video plug...
-
Page 7: Safety And Maintenance
www.freedom-eye.com Safety and Maintenance To keep your Reading Aid in good condition, observe the following guidelines: Read the instructions in this user’s manual before attempting to use the unit. Do not attempt to repair the Reading Aid r or open its case. This product contains no user serviceable parts. -
Page 8: Install The Reading Aid
www.freedom-eye.com Install the Reading Aid 1. Insert the small end of the power adaptor into the black end of the Y-shaped power/video cable from the Reading Aid. 2. Plug the power adaptor into a wall socket. - Page 9 www.freedom-eye.com 3. Insert the yellow RCA plug on the video cable into one of your television’s yellow video input connectors. Refer to your television owner’s manual for more information locating these connectors.
- Page 10 www.freedom-eye.com 4. Turn on the television. If necessary, switch your television to the appropriate input channel. Items that you magnify then appear on the television screen. 5. Turn on the Reading Aid by sliding the on/off button to ON position. Then the power indicator will light.
-
Page 11: Start To Work
www.freedom-eye.com 6. Put the Reading Aid on newspapers, magazine etc and then you can read their big images from TV. Then you can enjoy your reading. Start to Work... -
Page 12: Video Mode
www.freedom-eye.com Video Mode Press Video Mode button to cycle through the Reading Aid’s four different video modes as the following: Full color Black and White Enhanced positive image (black on white) Enhanced negative image (white on black) Magnification Adjustment... -
Page 13: Freeze Image
www.freedom-eye.com Zoom + : Press to get bigger magnification rate. Zoom -: Press to back to previous magnification rate. Freeze Image Press Stop/Play button to switch between freezing and de-freezing the current image. -
Page 14: Trouble Shooting
www.freedom-eye.com Trouble Shooting Problem Solution Ensure: 1. The adaptor is plugged and connected Reading Aid is properly connected to a 2. The Reading Aid is powered on. television, but no 3. The video cable is connected correctly. magnified image 4. Verify that the item you want to appears on the screen. - Page 15 www.freedom-eye.com This symbol on the product or in the instructions means that your electrical and electronic equipment should be disposed at the end of its life separately from your household waste. There are separate collection systems for recycling in the EU. For more information, please contact the local authority or your retailer where you purchased the product.
