Summary of Contents for Rainbow POWERNOZZLE
- Page 1 I N S T R U C T I O N M A N U A L...
-
Page 2: Important Safety Instructions
11. To avoid the risk of fire, do not use to pick up flammable liquids, such as gasoline, or use in areas where they may be present. 12. The Rainbow can be used by children aged 8 years and above and persons with reduced physical, sensory, or mental capabilities or lack of experience and knowledge, if they have been given supervision or instruction concerning use of the Rainbow in a safe way, and if they understand the hazards involved. -
Page 3: Air Flow Control
3. Upright Lock Release Pedal 4. Airflow Control 5. Brush Roll 6. Sole Plate Release Tabs Contact an Authorized Rainbow Distributor for replacement Power Nozzle belts and other supplies. Air Flow Control Polished or Glossy Finish Hard Surface The Power Nozzle features the ability... -
Page 4: Troubleshooting Guide
Troubleshooting Guide This Rainbow appliance has been thoroughly tested and inspected. If a minor issue develops, the following troubleshooting procedures may help identify and correct the issue. If you are unable to resolve the issue, contact an Authorized Rainbow Distributor for service. Any service procedure not listed below should be performed by an Authorized Rainbow Distributor or Service Center. -
Page 5: Operation
Operation release above the pivot arm. Plug in the Rainbow. Press down on the main power button. The Rainbow will always start in high speed. To disengage from the upright position, use your left foot to press down on the upright lock release pedal. - Page 6 ™ For best performance, we recommend you replace your Rainbow Power Nozzle belt every 12 to 18 months or when you notice decreased cleaning performance. Your Power Nozzle comes with one replacement belt and can be easily changed in just a few minutes. This replacement belt is located in the spare belt pocket under the sole plate. For additional replacement belts contact an Authorized Rainbow Distributor.
- Page 7 Contact an Authorized Rainbow Distributor for replacement Power Nozzle belts and other supplies. I N S T R U C T I O N M A N U A L...
-
Page 8: Instrucciones Importantes De Seguridad
12. El Rainbow puede ser utilizado por niños mayores de 8 años y por personas con capacidades físicas, sensoriales o mentales reducidas o sin experiencia y conocimiento si reciben supervisión o formación para usar el Rainbow de forma segura y si comprenden los peligros involucrados. Los niños deben recibir supervisión para garantizar que no jueguen con el Rainbow. La limpieza y mantenimiento del usuario no debe ser realizada por niños sin supervisión. - Page 9 4. Control del flujo de aire 5. Rodillo del cepillo 6. Pestañas de liberación de 7. La placa única Contacte a un distribuidor autorizado de Rainbow para obtener correas y otras piezas de repuesto del Power Nozzle. Control del Flujo de Aire...
-
Page 10: Guía Para La Resolución De Problemas
Este aparato Rainbow ha sido cuidadosamente probado e inspeccionado. Si surge un problema menor, los siguientes procedimientos para la resolución de problemas pueden ayudarle a identificar y corregir el problema. Si no puede resolver el problema, contacte a un distribuidor autorizado de Rainbow para obtener servicio técnico. Los procedimientos de servicio que no figuren a continuación deben ser realizados por un distribuidor o centro de servicio autorizado de Rainbow. -
Page 11: Operación
Luego, sujete el ensamble de la Antes de usar el Power Nozzle, siga varilla y presione hacia delante hasta que la Guía de inicio rápido del Rainbow el sistema de la varilla esté totalmente para preparar el Rainbow. acoplado en las pestañas de bloqueo. - Page 12 ™ Para un mejor rendimiento, recomendamos que reemplace la correa del Rainbow Power Nozzle cada 12 a 18 meses o cuando observe una reducción en el rendimiento de limpieza. Su Power Nozzle viene con una correa de reemplazo y se puede cambiar fácilmente en apenas unos pocos minutos. Esta correa de reemplazo se ubica en el bolsillo para correa de repuesto debajo de la placa única.
- Page 13 Contacte a un distribuidor autorizado de Rainbow para obtener correas y otras piezas de repuesto del Power Nozzle. | 12 M A N U A L I N S T R U C C I O N E S...
- Page 14 13 | P O W E R N O Z Z L E...
- Page 15 | 14 M A N U A L I N S T R U C C I O N E S...
- Page 16 rainbowsystem.com Rexair LLC | Troy, Michigan © 2019 Rexair LLC | R17480A-0...
Need help?
Do you have a question about the POWERNOZZLE and is the answer not in the manual?
Questions and answers
My rainbow unit has power, but the power nozzle doesn’t seem to.
The Power Nozzle may not be working for several reasons:
1. Power Nozzle motor is not running:
- Handle trigger is not activated – Squeeze the trigger on the hose handle.
- Wands are not connected – Ensure they are properly connected and seated.
- Automatic resetting motor protector has tripped – Turn the Rainbow off, wait 30 seconds, then turn it back on.
2. Power Nozzle motor runs, but the brush does not:
- Broken belt – Disconnect power, remove the sole plate, check if the brush rotates freely, and replace the belt if needed.
3. Power Nozzle brush is stopped and cannot rotate by hand:
- Object lodged in the brush chamber – Disconnect power, remove the sole plate, clear any foreign objects, and ensure the brush rotates freely.
- Bearing worn out – Contact an Authorized Rainbow Distributor or Service Center for a replacement brush roll.
4. Power Nozzle is not picking up debris well:
- Clogged air chamber – Disconnect power, remove the sole plate, and clear the air chamber.
- Clogged wands or hose – Disconnect power, remove the obstruction, reconnect to Rainbow, and ensure air flows freely.
- Bristles not in contact with the carpet – Check the sole plate positioning.
If the issue persists, consult an Authorized Rainbow Distributor or Service Center.
