INSTALLATION, OPERATING AND MAINTENANCE INSTRUCTIONS
The following is intended to provide the basic instructions for installation, operating and maintenance of the
Electric Ladder Pipe & SaberMaster Nozzle.
TOOLS REQUIRED FOR INSTALLATION OF ELECTRIC LADDER PIPE
• Utility knife
• Medium Phillips screwdriver
• Small Phillips screwdriver
• Electrician's pliers (multipurpose,
stripping and crimping)
PRODUCT RATINGS FOR ELECTRIC LADDER PIPE
Maximum motor current draw:
12 volt versions
24 volt versions
Normal operating current (depending on operating conditions—pressure, flow, etc.):
12 volt versions
24 volt versions
Minimum Voltage:
All 12 volt motors: 11.5 volts
All 24 volt motors: 23 volts
Mass: 30 lbs. (13.6 kg)
Maximum Flow: 1000 GPM
Maximum Pressure: 200 PSI
Noise Emission: 93 Db @ 1m with maximum flow
STYLE 1494 ELECTRIC LADDER PIPE
& STYLE 1577 SABERMASTER™ NOZZLE
(
Versions Available)
14.0 amps for elevation motor
3.0 amps for nozzle pattern motor
7.5 amps for elevation motor
1.5 amps for nozzle pattern motor
3 - 10 amps for elevation motor
0.7 amps for nozzle pattern motor
2 - 5 amps for elevation motor
0.4 amps for nozzle pattern motor
117299 & 119210
• Medium flat screwdriver
• Small flat screwdriver
1
inch hex head wrench
2
3
Allen Wrench
1 6

Advertisement

loading
Need help?

Need help?

Do you have a question about the SABERMASTER 1577 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Akron SABERMASTER 1577

  • Page 1 STYLE 1494 ELECTRIC LADDER PIPE & STYLE 1577 SABERMASTER™ NOZZLE INSTALLATION, OPERATING AND MAINTENANCE INSTRUCTIONS Versions Available) The following is intended to provide the basic instructions for installation, operating and maintenance of the Electric Ladder Pipe & SaberMaster Nozzle. TOOLS REQUIRED FOR INSTALLATION OF ELECTRIC LADDER PIPE •...
  • Page 2 Akron Brass Monitors and Nozzles are matched to a custom engineered electrical control pack- age. Caution must be observed if the SaberMaster is used on a non-Akron Brass style monitor. In order to prevent mechanical and electrical damage to the SaberMaster nozzle, the control package being used must have current sense protection that matches the load requirements for the SaberMaster.
  • Page 3 Mismatched threads may allow the nozzle to suddenly come off under pressure possibly caus- ing property damage and/or serious bodily injury. PRODUCT CAUTIONS FOR SABERMASTER NOZZLE CAUTION: If any tags or bands on the nozzle are worn or damaged and cannot be easily read, they should be replaced.
  • Page 4 • Drain the Electric Ladder Pipe monitor and nozzle after use to prevent “freeze damage”. • Ensure that the thread in the nozzle swivel matches the thread on the Ladder Pipe outlet. Do not overtighten the nozzle onto the Ladder Pipe. •...
  • Page 5: Dimensional Specifications

    Figure 1 DIMENSIONAL SPECIFICATIONS Page 5...
  • Page 6: Wiring Schematic

    Figure 2 WIRING SCHEMATIC SLAVE MASTER Page 6...
  • Page 7: Electrical Component Layout

    Figure 3 ELECTRICAL COMPONENT LAYOUT Page 7...
  • Page 8 Figure 4 MONITOR ATTACHMENT Page 8...
  • Page 9 SOURCE TO OPERATE THE MONITOR PROPERLY (equivalent to 12 awg). YOU MUST USE 20 AWG OR LARGER FOR THE CONTROLLER WIRES. AKRON BRASS SUPPLIED CABLE REEL HAS 100 FOOT OF USABLE CABLE. DO NOT EXTEND LADDER FURTHER THAN THE USABLE CABLE LENGTH.
  • Page 10 tight when in the locked position. 9. Snug down rear screw (6) and then securely tighten front screw (5) and the rest of the screws (5 & 6) to approximately 100-125 in-lbs. Do not over-tighten middle screw (5). 10. Test the safety catch operation to ensure proper locking action before putting the unit into service. NOTE: Periodically check for wear between the safety catch (2) and the locking handle (3).
  • Page 11 • Under normal conditions, periodically flushing the nozzle with clean water and and cleaning grit and dirt from around exterior moving parts will allow the nozzle to operate as designed. • Over time, the seals may need to be replaced. This can be accomplished by returning the nozzle to Akron Brass for repair.
  • Page 12 REVISED 06/05 WARRANTY AND DISCLAIMER: We warrant Akron Brass products for a period of five (5) years after purchase against defects in materials or workmanship. Akron Brass will repair or replace prod- uct which fails to satisfy this warranty. Repair or replacement shall be at the discretion of Akron Brass. Products must be promptly returned to Akron Brass for warranty service.

This manual is also suitable for:

1494
