OTTERSPOT WIRELESS CHARGING SYSTEM
Works with Apple, Samsung, Google and other certified Qi Wireless enabled phones
USER MANUAL
INTRODUCTION
Thank you for purchasing your OtterSpot Wireless Charging System — the world's first expandable, sharable and portable
wireless charging system by OtterBox. As the next innovative solution in phone charging, it eliminates the inherent hassles
of cord and power outlet management to ensure you, and those around you, always have a healthy charge to stay connected
wherever and whenever you need it.
FEATURES
•
Qi Wireless charging base and wireless charging batteries charge devices at home, in the office and everywhere you go
•
Wireless batteries have a USB-C port to recharge without the base
•
Works with Apple, Samsung, Google and other certified Qi Wireless enabled devices
•
10W fast charging base powers up multiple OtterSpot batteries and one device simultaneously
•
Eliminates tangled mess of wires on countertops and nightstands
•
Limited lifetime warranty supported by hassle-free customer service
DEVICE AND CASE COMPATIBILIT Y
OtterSpot Wireless Charging System works with Apple, Samsung, Google and other certified Qi Wireless enabled devices. Since
there are hundreds of Qi Wireless enabled devices from a variety of device manufacturers in market today, you can easily find
out if yours is certified by searching for Qi certified devices on the Wireless Power Consortium database webpage: https://www.
wirelesspowerconsortium.com/products.
OtterSpot Wireless Charging System works with all OtterBox branded phone cases, including Otter + Pop cases. It also works
with most other phone cases.
HOW TO USE OTTERSPOT WIRELESS CHARGING SYSTEM
Using OtterSpot Wireless Charging System is quick and easy. Just follow the key steps outlined below.
CHARGE THE SYSTEM
For the OtterSpot Charging Base and OtterSpot Battery combo, or the OtterSpot Battery-only product, you need to charge the
battery as your first step. There are a couple of ways to do this, including:
•
Stack battery on the base and plug the base into your wall outlet with the wall charger
Advertisement
Table of Contents
Related Manuals for OtterBox OTTERSPOT
Summary of Contents for OtterBox OTTERSPOT
-
Page 1: User Manual
Qi certified devices on the Wireless Power Consortium database webpage: https://www. wirelesspowerconsortium.com/products. OtterSpot Wireless Charging System works with all OtterBox branded phone cases, including Otter + Pop cases. It also works with most other phone cases. - Page 2 OTTERSPOT WIRELESS CHARGING SYSTEM Works with Apple, Samsung, Google and other certified Qi Wireless enabled phones USER MANUAL • Or, connect the battery to the wall charger and plug the wall charger into your wall outlet CHARGE 2 OR MORE BATTERIES AND A DEVICE 1.
- Page 3 OTTERSPOT WIRELESS CHARGING SYSTEM Works with Apple, Samsung, Google and other certified Qi Wireless enabled phones USER MANUAL 3. Center phone on battery, screen side up 4. Charge multiple batteries and a phone at once CHARGE A DEVICE 1. Grab battery from stack...
- Page 4 OTTERSPOT WIRELESS CHARGING SYSTEM Works with Apple, Samsung, Google and other certified Qi Wireless enabled phones USER MANUAL 2. Press the button to initiate wireless charging 3. Center phone on battery, screen side up 4. Acknowledge charging status Note: If equipped, two-way USB-C port charges battery and delivers power to phone.
- Page 5 Note: You can expect to charge up to three OtterSpot batteries (consumer version) at once with a max charging rate (4.5 hours to full), or up to five commercial batteries at max charging rate (4.5 hours to full) when charging in a stack.
- Page 6 It is composed of two major components, a Wireless Charging Base and Wireless Charging Batteries. The charging base accommodates up to three OtterSpot Wireless Charging Batteries charging at the same time for the consumer version, and up to five OtterSpot Wireless Charging Batteries for the commercial version. For optimal performance, we recommend stacking three OtterSpot Wireless Charging Batteries on the OtterSpot Wireless Charging Base (five on commercial base).
- Page 7 Ensure you are using the wall charger that was included with your OtterSpot unit or an OtterBox branded wall charger. Remove OtterSpot from any direct sunlight, as this can cause the battery to overheat. OtterSpot may become warm to the touch when in operation.
- Page 8 Confirm that battery pogo pins are properly aligned with base pogo pins. iii. OtterSpot USB-C charger is connected (consumer only) — Confirm charger and USB Type C-C cable is being used. Reset battery: double-click button then hold down for >5 seconds until all LEDs light up.
- Page 9 OTTERSPOT WIRELESS CHARGING SYSTEM Works with Apple, Samsung, Google and other certified Qi Wireless enabled phones USER MANUAL <10% charge – 1 LED flashing 10-25% charge – 1 LED on 26-50% – 2 LEDs on 50-75% – 3 LEDs on 76-100% –...
- Page 10 WARRANTY While we‘re confident you will enjoy your product, OtterSpot Wireless Charging System includes a limited lifetime warranty and will be replaced at no charge to you except for shipping, handling and applicable taxes. Learn more about our warranty statement and customer service assistance at https://www.otterbox.com/en-us/warranty-full.html or call (855) 688-7269.
- Page 11 Battery Capacity: 3.8V 5000 mAh (19 Wh) Rated Capacity (min.): 1200 mAh (10.8 Wh) Model(s): OBFTC-0025-A (OtterSpot Wireless Charging Battery) Input Contacts: 12VDC/5A (only while OtterSpot charging) Output Contacts: 12VDC/5A (only while OtterSpot charging) Output Wireless: 5W / 10W Battery Capacity: 3.8V 5000mAh (19Wh) Rated capacity (min.): 1200mAh(10.8Wh)
-
Page 12: Customer Service
USA + Canada - Toll Free otterbox.com/support ©2018 Otter Products, LLC. All rights reserved. The OtterBox name and OtterBox trademarks are the property of Otter Products, LLC, registered in the U.S. and other countries. Other trademarks are the property of their respective owners.
