Summary of Contents for Grafenthal DAVIDE Mini PC
- Page 1 Handbuch GRAFENTHAL DA VIDE Mini PC GRAFENTHAL GmbH • von-Monschaw-Straße 3 • 47574 Goch • info@grafenthal.de • www.grafenthal.de Copyright © 2017 GRAFENTHAL GmbH, Alle Rechte vorbehalten. GRAFENTHAL ist eine eingetragene Marke der GRAFENTHAL GmbH.
-
Page 2: Table Of Contents
Installing or upgrading the M.2 SSD ........29 Installing or upgrading the wireless card ......30 Installing 2.5” HDD / SSD ............31 Appendix Safety information ..............34 Setting up your system ............34 Care during use ..............34 DAVIDE Mini PC... -
Page 3: About This Manual
NOTE: This message contains additional information and tips that can help complete tasks. WARNING! This message contains important information that must be followed to keep you safe while performing certain tasks and prevent damage to your DAVIDE's data and components. DAVIDE Mini PC... -
Page 4: Package Contents
• If the device or any of its components fail or malfunction during normal or proper use and it is still within the warranty period, bring the device to you nearest GRAFENTHAL Service Partner. DAVIDE Mini PC... - Page 5 DAVIDE Mini PC...
-
Page 6: Getting To Know Your Davide
Getting to know your DAVIDE... -
Page 7: Features
Headphone jack This port allows you to connect amplified speakers or headphones. USB 3.0 port The USB 3.0 (Universal Serial Bus 3.0) port provides a transfer rate up to 5 Gbit/s and is backward compatible to USB 2.0. DAVIDE Mini PC... - Page 8 HDDs, speakers, cameras and printers. Power button The power button allows you to turn the DAVIDE on or off. You can also press the power button once to put your DAVIDE to sleep mode. DAVIDE Mini PC...
-
Page 9: Left Side
IMPORTANT! For optimum air flow, ensure that the air vents are free from obstructions. Right side Air vents The air vents allow air to enter your DAVIDE chassis. IMPORTANT! For optimum air flow, ensure that the air vents are free from obstructions. DAVIDE Mini PC... -
Page 10: Rear Panel
Rear panel Kensington® security slot The Kensington® security slot allows you to secure your DAVIDE using Kensington® compatible DAVIDE security products. DAVIDE Mini PC... - Page 11 The 8-pin RJ-45 LAN port supports a standard Ethernet cable for connection to a local network. USB 3.0 port The USB 3.0 (Universal Serial Bus 3.0) port provides a transfer rate up to 5 Gbit/s and is backward compatible to USB 2.0. DAVIDE Mini PC...
- Page 12 Memory card slot This built-in memory card reader slot supports MMC, SD, SDHC, and SDXC card formats. DAVIDE Mini PC...
- Page 13 DAVIDE Mini PC...
-
Page 14: Using Your Davide
Using your DAVIDE... -
Page 15: Getting Started
DAVIDE from the power socket. • Power adapter information: - Input voltage: 100-240Vac - Input frequency: 50-60Hz - Rating output current: 6.32A max. (120W) / 9.23A max. (180W) - Rating output voltage: 19V / 19.5V DAVIDE Mini PC... -
Page 16: Connect The Usb Cable From Keyboard Or Mouse
Connect the USB cable from your keyboard and mouse to any of the USB ports of your DAVIDE. NOTE: The illustrations in this section are for reference only and may vary per model. Connecting keyboard or mouse via USB port DAVIDE Mini PC... -
Page 17: Connect A Display Panel To Your Davide
To connect a display panel to your DAVIDE: Connect a display cable either to the HDMI, DisplayPort or DVI port. NOTE: The illustrations in this section are for reference only and may vary per model. Connecting display via HDMI port Connecting display via DisplayPort DAVIDE Mini PC... - Page 18 Connecting display via DVI port DAVIDE Mini PC...
-
Page 19: Turn On Your Davide
Turn on your DAVIDE Press the power button to turn on your DAVIDE. DAVIDE Mini PC... -
Page 20: Turning Your Davide Off
• You have installed a new system component that requires further BIOS settings or update. WARNING! Inappropriate BIOS settings may result to instability or boot failure. We strongly recommend that you change the BIOS settings only with the help of a trained service personnel. DAVIDE Mini PC... -
Page 21: Quickly Enter The Bios
• Enter the BIOS by following the steps mentioned in the Quickly enter the BIOS section. • Navigate to the Exit menu. • Select the Load Optimized Defaults option, or you may press <F5>. • Select Yes to load the default BIOS values. DAVIDE Mini PC... -
Page 22: Upgrading Your Davide
Upgrading your DAVIDE... -
Page 23: Upgrading Memory Modules
(4) screws securing the top cover. IMPORTANT! The rubber covers are designed to be attached to the bottom side. DO NOT force to detach it or completely remove it from the compartment cover. DAVIDE Mini PC... - Page 24 Lift and remove the top cover and set it aside. IMPORTANT! Remove the top cover carefully to prevent pulling on and causing damage to the cables connected. This may vary per model. Remove the screw from the HDD layer. DAVIDE Mini PC...
- Page 25 Align and insert the memory module into the slot and press it down (A) until the retaining clips snaps back into place and it is securely seated in place. Repeat the same steps to install the other memory module. DAVIDE Mini PC...
- Page 26 Replace the HDD layer. NOTE: Ensure to organize the cables to prevent any your DAVIDE and to ensure the HDD layer can be replaced successfully. 9. Replace the screw to secure the HDD layer. DAVIDE Mini PC...
- Page 27 DAVIDE and to ensure the top cover can be replaced successfully. 11. Reattach the screws to secure the cover back on the bottom side of the main box, then replace the rubber feet back on each screw hole. DAVIDE Mini PC...
-
Page 28: Installing Or Upgrading The M.2 Ssd
Align and insert the M.2 SSD into its slot inside the DAVIDE, then secure it with a screw. Follow steps 8-11 under the Upgrading memory modules section to replace the top cover and HDD layer of your DAVIDE. DAVIDE Mini PC... -
Page 29: Installing Or Upgrading The Wireless Card
Connect the black antenna to MAIN or and the white antenna to AUX or on the wireless card (C). Follow steps 8-11 under the Upgrading memory modules section to replace the top cover and HDD layer of your DAVIDE. DAVIDE Mini PC... -
Page 30: Installing 2.5" Hdd / Ssd
Follow steps 1-4 under the Upgrading memory modules section to remove the top cover of your DAVIDE. Remove four (4) screws from the HDD/SSD bracket. Remove the HDD/SSD bracket. Remove the cable from the holder, then remove the holder from the HDD/SSD bracket. DAVIDE Mini PC... - Page 31 Connect the cable to the HDD/SSD, then align the bracket to the HDD/SSD compartment of your DAVIDE and secure the bracket with the screws previously removed. Follow steps 10-11 under the Upgrading memory modules section to replace the top cover of your DAVIDE. DAVIDE Mini PC...
-
Page 32: Appendix
Appendix... -
Page 33: Safety Information
• Do not spill water or any other liquids on your system. • When the system is turned off, a small amount of electrical current still flows. Always unplug the power cord from the power outlets before cleaning the system. DAVIDE Mini PC... - Page 34 This symbol of the crossed out wheeled bin indicates that the product (electrical, electronic equipment, and mercury- containing button cell battery) should not be placed in municipal waste. Check local technical support services for product recycling. DAVIDE Mini PC...
- Page 35 I/O ports are located. • This device may not cause harmful interference, and • This device must accept any interference received including interference that may cause undesired operation. DAVIDE Mini PC...
- Page 36 • Consult the dealer or an experienced radio/TV technician for help. CAUTION: Any changes or modifications not expressly approved by the grantee of this device could void the user’s authority to operate the equipment. DAVIDE Mini PC...
