20 Metre Pipe Inspection Camera
System
Model No. AVB-710
Instructions for Use.
ATP Instrumentation Ltd
Tournament Way
Ivanhoe Ind Est
Ashby De La Zouch
Leicestershire
LE65 2UU
Sales: 01530 566800
sales@atp-instruments.co.uk
Technical: 01530 566804
technical@atp-instruments.co.uk
www.atp-instrumentation.co.uk
Advertisement
Subscribe to Our Youtube Channel
Summary of Contents for ATP Instrumentation AVB-710
- Page 1 20 Metre Pipe Inspection Camera System Model No. AVB-710 Instructions for Use. ATP Instrumentation Ltd Tournament Way Ivanhoe Ind Est Ashby De La Zouch Leicestershire LE65 2UU Sales: 01530 566800 sales@atp-instruments.co.uk Technical: 01530 566804 technical@atp-instruments.co.uk www.atp-instrumentation.co.uk...
-
Page 2: Important Notice
IMPORTANT NOTICE Should this equipment ever need to be returned to ATP Instrumentation Ltd for any reason and based on the type of applications it is used for, please ensure that it is in a clean, hygienic condition (disinfected or sterilised where necessary). - Page 3 ATP PIPE & DUCT CAMERA INSPECTION SYSTEM SET-UP & OPERATING INSTRUCTIONS Read these instructions carefully before the operation of this system Fully charge the battery before first use...
- Page 4 Technical Specification: Camera Camera Size Φ 23mm*120mm Camera Housing Material Stainless steel Camera Lens Material Sapphire glass Sensor Size 1/4 inch Total Pixels PAL:720*576 NTSC:720*480 View Range 120 ° Illumination 12PCS white LEDS Waterproof Level IP68 Camera Work Current 100MA Camera Power Supply DC 12V Operating Temperature...
- Page 5 Fibreglass Diameter Φ4.8mm Fibreglass Colour Yellow WARNING! Read this manual carefully before operating this system Avoid using the device in extreme humidity or temperatures as this may cause damage to the device Do not drop or press on the system as this may cause damage to the device The warranty becomes void if any physical damage is present or if the system is disassembled by the user Do not disconnect the SD card while recording or playing as this may damage the...
- Page 6 Monitor: 1 – Sun shade 2 – 7” Monitor 1 – Video selector button 2 – Image rotation button 3 – Secondary menu button 4 – Secondary menu down 5 – Secondary menu up 6 – Fuse socket 7 – Charger port 8 –...
- Page 7 Controls: 1 – Power Controls 2 – LED brightness adjuster 3 – Battery level indicator 4 – DVR status indicators 5 – Menu up 6 – Menu down 7 – Menu left 8 – Menu right 9 – Playback stop/ Menu back 10 –...
- Page 8 Menu: Recorder setting: 1 – Work mode: Video – Record videos Photo – Snapshot photos Audio – Record audio 2 – Motion detection: Off – Stop the motion detection On – Start the motion detection 3 – Sensitivity: High – Highest sensitivity Medium –...
- Page 9 7 – Video time: Length of video recording 5 minutes 10 minutes 15 minutes 30 minutes 60 minutes 8 – FPS set: 15 FPS – 15 frames per second 30 FPS – 30 frames per second 9 – Audio record volume: Sets the volume that audio records at from 1-10 10 –...
- Page 10 System setting: 1 – Language: Select the operating language 2 – Date Time: Set the date and time, press OK to confirm 3 – Video output: Choose wither PAL or NTSC mode to suit your monitor and TV video output 4 –...
- Page 11 Event Playback: 1 – Video files: All videos stored on the system 2 – Photo files: All photos stored on the system 3 – Audio files: All audio recordings stored on the system 4 – All files: All file types on the system File Deletion: Press the playback button to find the files, press the menu button on the file of your choice and then select which one or all depending on the amount of files you want to delete.
- Page 12 Keyboard Overtyping: The font and text size are fixed and cannot be changed. The basic operation of the text overlay unit is straight forward. A flashing underscore cursor indicates the current screen position. This cursor can be moved around the screen by the keyboard cursor keys.
- Page 13 Downloading Files: Download of files from the system. Push the SD card in so it pops out. Put the SD card into the SD card reader (supplied) and plug this into a USB port on your computer This will then open the folder with the files you have recorded. You can then transfer them to the Computer.
- Page 14 Basic Operation: IMPORTANT!! – When connecting the camera to the cable or the cable to the monitor the power must be off. Connect the camera to the reel and connect the reel to the monitor. Make sure the camera lens is clean. Fully charge the battery.
- Page 15 ATP Instrumentation Ltd Tournament Way Ivanhoe Ind Est Ashby De La Zouch Leicestershire LE65 2UU Sales: 01530 566800 sales@atp-instruments.co.uk Technical: 01530 566804 technical@atp-instruments.co.uk www.atp-instrumentation.co.uk...
