Active UTP Transceiver Hub
with Integral Camera Power
Installation Guide
Models Include:
HubWayLD8Di
- UL Listed eight (8) Channel Active UTP
Transceiver Hub with Integral Isolated Camera Power
HubWayLD82Di
- UL Listed eight (8) Channel Active UTP
Transceiver Hub with Integral Isolated Camera Power
- Includes eight (8) UL Listed Accessory
HubWayAv Video Balun/Combiners
HubWayLD83Di
- UL Listed eight (8) Channel Active UTP
Transceiver Hub with Integral Isolated Camera Power
- Includes eight (8) UL Listed Accessory
HubWayDv Video Balun/Combiners
Rev. 030408
HubWayLD16Di
- UL Listed sixteen (16) Channel Active UTP
Transceiver Hub with Integral Isolated Camera Power
HubWayLD162Di
- UL Listed sixteen (16) Channel Active UTP
Transceiver Hub with Integral Isolated Camera Power
- Includes sixteen (16) UL Listed Accessory
HubWayAv Video Balun/Combiners
HubWayLD163Di
- UL Listed sixteen (16) Channel Active UTP
Transceiver Hub with Integral Isolated Camera Power
- Includes sixteen (16) UL Listed Accessory
HubWayDv Video Balun/Combiners
Z1409
More than just power.
TM
Advertisement
Table of Contents
Summary of Contents for HUBWAY HubWayLD8Di
-
Page 1: Installation Guide
Video • Data • Power Active UTP Transceiver Hub with Integral Camera Power Installation Guide Models Include: HubWayLD8Di HubWayLD16Di - UL Listed eight (8) Channel Active UTP - UL Listed sixteen (16) Channel Active UTP Transceiver Hub with Integral Isolated Camera Power... - Page 2 4 cameras over a single CAT-5 or higher structured cable back to the HubWayLD8Di/16Di. In addition, the HubSat4D provides power to these cameras locally to eliminate the possibility of voltage drop associated with long cable runs.
-
Page 3: Installation Instructions
Installation Instructions: 1. Set the input voltage selector switch located on the left side of the HubWayLD8Di/LD16Di unit (facing front panel) for 115VAC or 230VAC operation (Fig. 1k, pg. 4). 2. Attach mounting brackets to HubWayLDi unit for rack or wall mount installation (Figs. 6-7, pg. 8). Affix rubber pads to HubWayLDi for shelf installation (Fig. - Page 4 + -- - 4 - HubWayLD8Di / HubWayLD16Di...
- Page 5 2 - Orange [VIDEO -- ] 3 - White/Green [DATA +] 4 - Blue [AC 1] 5 - White/Blue [AC 2] 6 - Green [DATA -- ] 7 - White/Brown [AC 2] 8 - Brown [AC 1] HubWayLD8Di / HubWayLD16Di - 5 -...
-
Page 6: Typical Applications
Video Balun HubWayDv/Dvi Combiner Video Balun HubWayAv Fixed Combiner 115VAC Video Balun Camera Fixed Input, 50/60Hz Combiner Camera Outdoor Camera NEMA Rated Power Fig. 4a - Optional hookup utilizing HubSat4D. Supply 115VAC Input, Power 50/60Hz - 6 - HubWayLD8Di / HubWayLD16Di... - Page 7 (servicing) instructions in the literature accompanying the appliance. CAUTION: To reduce the risk of electric shock do not open enclosure. There are no user serviceable parts inside. Refer servicing to qualified service personnel. HubWayLD8Di / HubWayLD16Di - 7 -...
-
Page 8: Wall Mount Installation
Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A. MEMBER IIHubWayLD8Di/HubWayLD16Di E16R - 8 - HubWayLD8Di / HubWayLD16Di...
