Summary of Contents for X2E OABR2CAN
- Page 1 OABR2CAN Media Gateway User Manual Version: 1.8 / November 2019...
- Page 2 This user manual is protected by copyright; all usual rights reserved. Reproduction of this user manual, even in part, is only permitted with the approval of X2E GmbH. Any infringement will result in liability for damages and may result in criminal prosecution.
-
Page 3: Table Of Contents
User Manual OABR2CAN Table of contents Introduction ..................... 4 Intended use .................... 4 Delivery contents ..................4 General safety instructions ..............5 Product overview..................6 Identification ..................... 6 Connections and controls ................ 6 Installation ....................9 Mounting ....................9 Connecting ....................9 Gateway configuration ................ -
Page 4: Introduction
Suite ORAYA USB driver Check to ensure that the delivery is complete and all hardware components are in sound condition. If the delivery is incomplete or supplied components are damaged, contact X2E immediately. Do not use damaged components. -
Page 5: General Safety Instructions
User Manual OABR2CAN General safety instructions The OABR2CAN Media Gateway is only intended for use by qualified personnel. Read the user manual and especially this chapter thoroughly before operating. CAUTION Electric shock due to damaged components Damages to the gateway or the connection cable can result in electric shock. -
Page 6: Product Overview
User Manual OABR2CAN Product overview Identification The identification plate is located on the bottom side of the OABR2CAN Media Gateway. It contains information about: device type hardware revision serial number date of manufacture This user manual applies to the OABR2CAN Media Gateway in hardware revision 1.01. - Page 7 User Manual OABR2CAN Activity LED for OABR (A) Colour Meaning green interface ready green (blinking) data transmission on this interface yellow USB bootloader mode Connection for power, OABR and CAN (B) Function CAN_1_H CAN_1_L CAN_2_H CAN_2_L KL30(Ubatt) KL31(GND) OABR_N OABR_P Service interface (C) Use the Micro USB interface to change the configuration or to update the firmware.
- Page 8 User Manual OABR2CAN LED for CAN (E) Colour Meaning blue at least one CAN interface in initialisation phase green at least one CAN interface ready red (blinking) data transmission on at least one CAN interface Link LED for OABR (F)
-
Page 9: Installation
User Manual OABR2CAN Installation Mounting CAUTION Device damage due to overheating Overheating may result in malfunction or destruction of the gateway. Do not operate the gateway outside the specified temperature range. Do not operate the gateway in the vicinity of heat sources. - Page 10 User Manual OABR2CAN The following instructions refer to the connection cable provided by X2E. If you use other ca- bles, connect accordingly. Plug the connection cable into the socket (B). Connect the cable labelled OABR to an OABR device.
-
Page 11: Gateway Configuration
The X Suite is a collection of programs to configure and ORAYA control X dataloggers and additional devices like the OABR2CAN Media Gateway. ORAYA Supported operating systems: Microsoft® Windows® 7 (32 Bit or 64 Bit) ... -
Page 12: Install Xoraya Suite
User Manual OABR2CAN The OABR2CAN Media Gateway supports three modes depending on the routing direction: OABR to CAN CAN to OABR CAN to CAN These modes are set by configuring the receiving and sending interfaces in Gateway config- uration. -
Page 13: Start Gateway Configuration
User Manual OABR2CAN Start Gateway configuration Start the X Suite. ORAYA Click in the Windows notification area. Select Extra tools > Gateway configuration. -
Page 14: Buttons
User Manual OABR2CAN Buttons The following table displays a short overview of the toolbar buttons and the equivalent menu commands. You find detailed step-by-step instructions on the subsequent pages. Function Menu command creates a new project Project > New loads an existing project (*.xgc) Project >... -
Page 15: Gateway-Settings
User Manual OABR2CAN Gateway-Settings Gateway-Settings are general settings that apply to all interface mappings of the current pro- ject. Setting Function IPv4 address of the gateway SubNet IPv4 subnet address of the gateway Gateway IPv4 gateway address of the gateway... -
Page 16: Connect To Gateway
User Manual OABR2CAN Select a message and click to add this message to the routing table. Repeat this step for up to 255 further messages if required. Click somewhere in the message list, then and Yes to route all messages of the interface unfiltered. -
Page 17: Transfer Configuration
User Manual OABR2CAN Transfer configuration Establish a connection to the gateway (see chapter Connect to gateway). Click to load a saved configuration. Navigate to the directory that contains the configuration file and select the File name. ... -
Page 18: Cleaning
Never open the gateway. Maintenance and repair must be carried out by X2E personnel only. In case of malfunctions or damages, please contact X2E via e-mail to get information about returning the gateway: xoraya-return@x2e.de Disposal Within the European Union, the disposal of electrical devices is determined... -
Page 19: Appendix
-40 °C to +65 °C Message structure The OABR2CAN Media Gateway wraps up to three SOME/IP messages in one Ethernet packet. For the tunnelling of CAN messages, the SOME/IP header is defined as follows: The complete identifier is encoded in the field CAN-ID in LSB-first order. The 29th Bit (la- belled with e) is an indicator for an Extended Identifier. -
Page 20: Pin Assignments Of The Connection Cable
User Manual OABR2CAN Pin assignments of the connection cable Function CAN_1_H CAN_1_L CAN_2_H CAN_2_L KL30(Ubatt) KL31(GND) OABR_N OABR_P CAN1 Function CAN_1_L CAN_1_H CAN2 Function CAN_2_L CAN_2_H OABR Function OABR_N OABR_P Ubatt/GND Colour Function KL30(Ubatt) black KL31(GND) - Page 22 X2E GmbH Jahnstrasse 2b 76870 Kandel GERMANY Phone +49 7275 9143 100 +49 7275 9143 109 E-Mail info@x2e.de Internet http://www.x2e.de...
