1
Step 1.
Clean surface and peel the protective
backing from the Receiving Base.
3
Step 3.
Press firmly for several seconds to attach the
Receiving Base.
ASSEMBLY INSTRUCTIONS FOR
Lock & Locate
Boxes (#18672 and 18677)
™
Call Free 1.800.848.1633 • Fax Free 1.800.447.2923
Web: www.GoHCL.com • Email: hcl@GoHCL.com
2
Step 2.
Place the Receiving Base in the Wall Mount
or on countertop, cart top or shelves.
4
Step 4.
Loosely drive the screw into the desired
location on the wall or cabinet. (Screws are not
provided.)
© Health Care Logistics, Inc. 2011
Advertisement
Summary of Contents for Health Care Logistics Lock & Locate Series
- Page 1 Press firmly for several seconds to attach the Loosely drive the screw into the desired Receiving Base. location on the wall or cabinet. (Screws are not provided.) Call Free 1.800.848.1633 • Fax Free 1.800.447.2923 Web: www.GoHCL.com • Email: hcl@GoHCL.com © Health Care Logistics, Inc. 2011...
- Page 2 Pull up of the white button in the middle of the locking box. While pulling up on the button, pull the entire box forward off of the Receiving Base. Call Free 1.800.848.1633 • Fax Free 1.800.447.2923 Web: www.GoHCL.com • Email: hcl@GoHCL.com © Health Care Logistics, Inc. 2011...
- Page 3 “stop cam” and the cam back on. Combi-Cam 800-654-1786 18424 HWY 99 Division of the Fax (206)-523-9876 Lynnwood, WA 98037 Frank J Martin Co. www.combi-cam.com Call Free 1.800.848.1633 • Fax Free 1.800.447.2923 Web: www.HealthCareLogistics.com • Email: hcl@HealthCareLogistics.com © Health Care Logistics, Inc. 2011...
- Page 4 © Frank J. Martin Co. Combi-Cam 800-654-1786 18424 HWY 99 Division of the Fax (206)-523-9876 Lynnwood, WA 98037 Call Free 1.800.848.1633 • Fax Free 1.800.447.2923 Frank J Martin Co. www.combi-cam.com Web: www.HealthCareLogistics.com • Email: hcl@HealthCareLogistics.com © Health Care Logistics, Inc. 2011...
