MC Electronics UC 300 User Manual

Universal counter

Advertisement

Quick Links

UC 300
UNIVERSAL COUNTER
USER'S MANUAL
NR.1111-EN
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UC 300 and is the answer not in the manual?

Questions and answers

Summary of Contents for MC Electronics UC 300

  • Page 1 UC 300 UNIVERSAL COUNTER USER’S MANUAL NR.1111-EN...
  • Page 2 UNIVERSAL COUNTER UC 300 This product complies with EMC requirements as defined by Directives 2004/108/CE and successive modifications in accordance with standard EN ISO 14982 applied : MC elettronica S.r.l. Manufacturer : Via E. Fermi, 450/486 Address Fiesso Umbertiano (ROVIGO) – ITALY Tel.
  • Page 3: Table Of Contents

    UNIVERSAL COUNTER UC 300 Content 1. Rules and general warning .................. 4 1.1 Introduction ....................... 4 1.2 Terms of guarantee ..................5 1.3 Service ......................5 2. General description ....................6 3. Description of the panel and electrical connections ......... 7 4.
  • Page 4: Rules And General Warning

    UNIVERSAL COUNTER UC 300 1. Rules and general warning 1.1 Introduction This manual gives all the specific information that you need for a proper use of the equipment. After buying the instrument, read the manual carefully and refer to it any time you have doubts on how to use the equipment or when you have to carry out maintenance operations.
  • Page 5: Terms Of Guarantee

    Service is available in all the countries where the equipment is officially supplied by MC elettronica (during and after the guarantee period). Any kind of operation that is to be carried out on the UC 300 must be done in accordance with the instructions stated in this manual or as agreed with MC elettronica.
  • Page 6: General Description

    4) counter of distance covered (in metres or feet, in units of 1 metre or 1 foot) 5) working hour counter (in units of 0.1 hours) Provided with the UC 300 are a battery charging cable, a magnetic sensor and a magnet of reference: the code for the complete kit is 00KIT-0014;...
  • Page 7: Description Of The Panel And Electrical Connections

    UNIVERSAL COUNTER UC 300 3. Description of the panel and electrical connections UC 300 ha ac Km/h mph m ft PROG Select Reset Rif. Description signal Type Pin connector INput/OUTput S.SEAL 4-way LCD Display: A1-A5: arrows indicating the size selected A6: arrow indicating low battery Selection key size and "-"...
  • Page 8: Overall Dimensions

    UNIVERSAL COUNTER UC 300 4. Overall dimensions UC 3000 ha ac Km/h mph m ft PROG Select Reset 3.5 jack connector panel for battery charging Cable 50 cm with cigarette lighter plug for charging battery (supplied) cod. CAV-0017 cable 20 cm with conn. s.seal 4-way for connection the magnetic sensor sens.
  • Page 9: Operation

    UNIVERSAL COUNTER UC 300 5. Operation When the counter is started up for the first time (or after the battery is charged after having run down completely), the total area counter is shown on the display. The UC 300 is set by default to show metric measurements: the area is given in hectares, the speed in km/h and the distance covered in metres.
  • Page 10: Standby Mode

    UNIVERSAL COUNTER UC 300 the residual autonomy of the UC 300 before it turns off completely is limited and will depend also on use. If the battery runs down completely and the UC 300 turns off, some of the data may be lost (refer to the previous section); to charge the battery, connect the cable with the jack connector (provided) to a 12V battery: Do NOT use car battery charging devices.
  • Page 11: Programming The "Un" (Unit Of Measurement) Parameter

    Programming of this parameter is very important to the work in hand and to the programmable parameters. You need to select either the metric or imperial unit of measurement; you then only need to program the parameters of the UC 300 for the chosen unit of measurement.
  • Page 12: Automatic Programming Of Parameter "C" (Pulses Of The Speed Sensor)

    It is advisable to repeat this operation at least twice. If you try to acquire a value of less than 20 pulses, “Err” appears on the display and the UC 300 retains the last valid value to have been saved. User’s manuale...
  • Page 13: Programming Parameter "L" (Working Width)

    UNIVERSAL COUNTER UC 300 8.4 Programming parameter “L” (working width) This parameter is the working width of the machine in metres (or feet). Enter the programming phase as described above and edit the value with the “+” and “-” buttons; pressing and holding either button will speed up the editing process.
  • Page 14: Maintenance

    UNIVERSAL COUNTER UC 300 9. Maintenance This chapter gives instructions on how to carry out ordinary and extraordinary maintenance. Ordinary maintenance refers to those operations which must be carried out periodically. As they do not require specific skills, they can be carried out by the users (operators etc.).
  • Page 15: Technical Data

    UNIVERSAL COUNTER UC 300 10. Technical data Power supply voltage 3.6 Vdc (internal batteries) Max. energy consumption in stand by < 50µA Protection degree IP 65 Range of operating temperature -20 / +70 °C Range of storage temperature -25 / +85 °C...
  • Page 16 Electronic equipments for agricultural www.mcelettronica.it Printed in Italy...
