Eufficio Innera Piatto Installation Instructions

Design & Electric
INSTALLATION INSTRUCTIONS

Components:

Cat 6
Cat 6
1 x Innera
Piatto

Critical safety information:

Prior of use, please examine and verify that the product is not defected. Please do not install or operate if there is a defect of any kind.
If in any case you are facing misunderstanding of installation procedure, the installation should be carried out by certified electrician
Make sure you are installing the product on smooth straight surface. Do not install in any case that the surface is not straight or if there are levels differences.
Make sure water will not penetrate into the unit. In any case please make sure you are installing the unit, where proper leakage protection device is connected.

Installation:

A
L
Drill hole into the surface according to the
Installation Table on page 2. Please verify
your purchased item's model No and drill the hole
according to the model's cutout dimensions.
D
Cat 6 Cat 6
Insert the Innera Piatto into the hole.

Cleaning:

The product can be cleaned by a soft and dry fabric. Please do not use moisture, abrasives materials,solvents or any detergents which can be conductive
Engineered in Germany
Innera Piatto
Read the instructions prior to installation.
ATTENTION:
2 x Cover
screws
4 x Screws
B
W
Cat 6 Cat 6
Remove the screws cover by sliding it to the sides.
E
Cat 6 Cat 6
Using screw driver install the 4 screws.

Operation:

Cat 6
Cat 6
The Innera Piatto is ready to use.
ISRAEL

Tools required:

Power Saw
Connect the GST Male connector to power.
Install the screws cover by sliding it to the sides.
1
Hole Cutter
C
F
Cat 6 Cat 6
www.eufficio.com
Power Drill
