Summary of Contents for Notch Sentinel Arborist Harness
- Page 2 A-Side D ring B-Bridge adjustment strap C-Bridge strap buckle D-Rope bridge E-Bridge ring F-Bridge anchor plate G-Elastic waist strap H-Waist belt strap I-Waist belt connect buckle J-Leg strap with connect buckle K-Leg pad keeper straps L-Accessory loops (8) M-Accessory rings (2) N-Accessory pouch straps (not pictured) O-Leg Pads P-Suspender Loop...
-
Page 3: Field Of Application
Notch™ Sentinel Arborist Harness FIELD OF APPLICATION: Note: Elastic waist strap is for support and comfort only. This product can be part of personal protective equipment for Caution, do not over tension. protection (PPE) for position at the work station, or to prevent •... -
Page 4: Adjustment Instructions
ADJUSTMENT INSTRUCTIONS: BRIDGE STRAP ADJUSTMENT: Adjust the fit of your harness so that your body is supported • Locate the Bridge strap buckle positioned between the Bridge with weight evenly distributed between the belt and leg straps, anchor plate and the Side D ring balanced to hang upright and relaxed, without uncomfortable •... - Page 5 TYING THE ROPE BRIDGE STOPPER KNOT: This stopper knot is recommended by the rope manufacturer to secure the replacement Notch™ rope bridge. It stops the rope from passing thought the hole in the bridge anchor plate. The knots should be hand-tightened to prevent any possibility of movement/slippage.
- Page 6 TRIPLE-LOCK BUCKLE OPERATION: The Triple-Lock Buckles offer a very high safety standard by providing a three-way closure. To open the buckle, press the top button releasing the frame and pull back as shown below. To close the buckle, push frame into the main buckle body and pull back, audible click will be heard confirming secure closure. Strap length can be adjusting by pulling on the tail end of the webbing.
- Page 7 Failure to carefully and completely inspect your webbing in the strap loop keeper equipment could result in serious injury or death. Notch • Proper adjustment of the rear leg strap will ensure the pads are in the correct distance below the waist...
- Page 8 WORK POSITIONING HARNESS EN 358:1999 SEAT HARNESS EN 813:2008 These attachment points are designed to either hold the user Nominal maximum load = 140 kg (308 lbs). Designed for pro- in position at the work station, or to prevent the operator from gression on rope and work positioning.
- Page 9 WARNINGS: TRANSPORT: • Manufacturer’s instructions shall be provided by the user of The product must be transported to avoid direct sunlight, this product. If additional copy is needed, contact Notch moisture, chemicals, dirt, extreme temperatures and Equipment. mechanical damage. • Completely read, understand, and follow all instructions,...
- Page 10 • This harness is not designed to be used with a retro fit Fall Arrest Harness. suspenders are not safety products. Suspenders are • Notch™ harness is to be used for work positioning and designed to support only the weight of the saddle and the suspension only, NOT FOR FALL ARREST.
-
Page 11: Warranty
RETURNS: CE 0123: the authority supervising production of PPE You may return your Notch™ product for any reason. Please call (TÜV SÜD Product Service GmbH, 80339 Munich, Germany) Notch Equipment at 866-345-2468 to request a Return Merchandise Authorization (RMA). Mark the package with the... - Page 12 NOTCH EQUIPMENT Distribution Europe: 496 GALLIMORE DAIRY ROAD, SUITE D Notch by EDELRID GREENSBORO, NC 27409 Achener Weg 66 1-800-525-8873 88316 Isny im Allgäu info@notchequipment.com Germany PSA-Richtlinie / PPE-Guideline / EPI-directive 89/686 / (EWG/EEC/CEE) Certified by CE 0123: TÜV SÜD Product Service GmbH...
