SymmetryOffice Align 300 Installation Instructions

Align 300
Installation Instructions
INSTALLATION WARNINGS:
Read the entire instruction sheet before you begin installation or assembly. Installer must verify that the wall will safely
support the combined weight of all the attached equipment and hardware. Improper installation of this product can cause
extensive property damage or serious personal injury, either during or after the installation. It is the
responsibility of the installer to ensure that all applications including wood, concrete, block, brick, steel, etc.
are secured properly to code. California Installations could require specific anchorage, and additional
mounting screws. Check with local authorities for codes in your
area. Other seismic states have similar regulations.
DISCLAIMER: The Manufacturer and/or Distributor
will bear no responsibility for any damages of any
kind arising from any improper installation of this
product. Because wall construction varies widely and
the ultimate method of mounting is out of the
Manufacturers or Distributors control, it is imperative
that the installer consult with local engineering,
architectural, or construction personal to ensure the
wall mount is constructed properly and to code to handle
the applied load.
Parts in Box
Provided
5x
#12 x 2-1/2
5x
1/4-20 x 3
4x 4x
M4 x 8mm M4 x 12mm
Toggler
Bolts
6x
Velcro
1x
Mouse
Track
House
Cover
1x Quick
Connect
Bracket
Tools Needed
5x
1x
1/8"
3/16"
154420180 Rev. A
