Summary of Contents for Linear GDBPF-370A3
- Page 1 & user manual GDBPF-370A3 GDBPF-560A1 GDBPF-750A2 GDBPF-370D LINEAR MANUAL new.indd 1 29/4/10 14:48:32...
- Page 2 Installation & User Manual Thank you for choosing a Linear Food Waste Disposer. This product is engineered to provide many years of trouble free service. Please read this manual carefully and keep it safe for future reference. Important Notice: Before installing your Linear Food Waste Disposer, please read all of the following instructions carefully.
-
Page 3: Table Of Contents
What your food waste disposer can be used for What’s included Safety guide Assembly drawing Quick release model installation Dish-washer connection ABS clip model installation Electrical connections Air switch connection Operation Tips for successful operation Troubleshooting Cleaning and maintenance Specifications Contact us LINEAR MANUAL new.indd 3 29/4/10 14:48:32... -
Page 4: Introduction
Our models have been installed across Europe, Asia, Africa and also North and South America, for over 10 years. A Linear food waste disposer is an innovative household product that will enhance any kitchen. With the potential to reduce odour, harmful bacteria and viruses caused by rotten food leftovers, in addition to reducing land-fill waste, a Linear food waste disposer really is the ideal solution for the modern kitchen. -
Page 5: Safety Guide
Read all instructions before using your food waste disposer. Do not allow children, the infirm or persons with a mental disability to operate the unit. Do not put fingers or hands into a Linear food waste disposer. Do not put the following into a disposer: •... -
Page 6: Assembly Drawing
Assembly drawing Stopper Sink fl ange Sink Sink Rubber gasket Fibre gasket Protector gasket Support ring Tapping screw Fastening ring Splashing guard Elbow fl ange Screws Elbow gasket Elbow gasket Elbow gasket Discharge elbow LINEAR MANUAL new.indd 6 29/4/10 14:48:33... -
Page 7: Quick Release Model Installation
From under the sink, replace the fibre gasket, triangle ring and mounting ring back to the sink flange in turn. Tighten the 3 mounting screws evenly with a screwdriver. Then, put the stainless steel snap ring back to its original place. (figure. 6) LINEAR MANUAL new.indd 7 29/4/10 14:48:34... -
Page 8: Dishwasher Connection
(figure. 10) Connect dishwasher hose using a jubilee clip to secure. Make sure all plumbing connections are tight and in accordance with all building regulations. Run water and check for leaks. (figure. 11) LINEAR MANUAL new.indd 8 29/4/10 14:48:34... -
Page 9: Abs Clip Model Installation
Put the fastening ring around the splash guard and lock the buckle, checking that the installation is firm and stable. If everything is OK, go on to install the elbow and make the connection to the waste pipe. LINEAR MANUAL new.indd 9 29/4/10 14:48:34... -
Page 10: Electrical Connections
Put the end of the air switch pipe into the connection point and Step three ensure it is snug over the nipple. Slide the locking nut over and rotate in a clockwise direction Step four until the connection is tight. The installation is finished. LINEAR MANUAL new.indd 10 29/4/10 14:48:34... -
Page 11: Operation
It will handle all normal food wastes, but it will NOT grind or dispose of such items as plastic, tin cans, bottle caps, glass, china, leather, cloth, rubber, string, clam and oyster shells, aluminium foil or feathers. LINEAR MANUAL new.indd 11 29/4/10 14:48:34... -
Page 12: Troubleshooting
Improper seating of sink flange (gasket centring, putty or tightening). Support ring not tightened properly. Defective or improperly installed splash guard. If unit leaks at the waste elbow, leak may be due to improper tightening of elbow flange screws. LINEAR MANUAL new.indd 12 29/4/10 14:48:34... -
Page 13: Cleaning And Maintenance
Insert the plug back into the socket to supply power again and the machine can be used normally. Marks caused by deposits or scale on the cutter head are normal after use. The inner components and surfaces of the food waste disposer is made up of corrosion-proof materials. LINEAR MANUAL new.indd 13 29/4/10 14:48:34... -
Page 14: Specifications
Specifications Motor DC motor AC motor model BPF-370 BPF-370 BPF-560 BPF-750 BPF-750 Size 325.5 325.5 325.5 LINEAR MANUAL new.indd 14 29/4/10 14:48:34... -
Page 15: Contact Us
Address 70 High Park Drive Mill Park Industrial Estate Old Wolverton Mill East Milton Keynes Post code MK12 5TT Phone number 0845 257 6973 Fax number 0845 257 6975 Web site www.graftondistribution.co.uk Email customerservice@graftondistribution.co.uk LINEAR MANUAL new.indd 15 29/4/10 14:48:34... - Page 16 LINEAR MANUAL new.indd 16 29/4/10 14:48:34...
- Page 17 Pdf Supplied By http://www.plumbworld.co.uk/...
