Sound Labs ShrutiVani Operating Instructions

ShrutiVani is India's FIRST 2-in-1 Electronic Shruti Box capable of playing high quality TAMBURA
SHRUTI and HARMONIUM SHRUTI along with an accurate inbuilt electronic TUNER.
OPERATING INSTRUCTIONS

ON/OFF:

Switch on the instrument by pressing the ON/OFF button.
Before you switch on, make sure to plug in the mains cord; the two-pin male plug into your AC
wall power supply, and the female connector on the back of the Shrutivani.
Once ON, pressing the ON/OFF switch again will turn the Shrutivani off.

SHRUTI 2-in-1:

Press this button to select the Shruti Instrument you want to play: Tambura Shruti or Harmonium
Shruti. The corresponding LED will glow against the selected Shruti.

VOLUME:

Use the arrow buttons against VOLUME to set the volume of the instrument.
Press the Up or Down arrow buttons to respectively increase or decrease the volume of the Shruti
Box.

MAIN SA:

Use the arrow buttons against MAIN SA to select your required sur (note).
Press the Up or Down arrow buttons to navigate from the lowest to the highest sur (i.e. main
notes).
The sur indication is arranged like the keys of a harmonium or a piano keyboard for quick
reference.
The selected sur is represented by its corresponding LED in the display above.
The first LED indicates A scale 6 Kattai (lowest sur). The last LED indicates B scale 7 Kattai
(highest sur 2nd octave)

FINE SA:

Use the arrow buttons against FINE SA to further fine tune your sur (note). The Up & Down buttons
allow fine pitch adjustment between two main notes.
Press the Up button to adjust between C & C#. Press the Down button to adjust between C & B.

SELECT:

Press this button to selection the style on a rotational basis: PA (Pancham), MA (Madhyam), NI
(Nishad) or only SA.
The corresponding LED will glow against the selected style only for PA, MA or NI.
To select SA, press the button until the LED is off i.e. when the selected style is SA, all LEDs will be
turned off.
