AGRI EASE SW42T Manual

Tow behind lawn sweeper
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SW42T
Tow Behind
Lawn Sweeper Manual
Operations & Parts Manual
Purchase Date
Dealer

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SW42T and is the answer not in the manual?

Questions and answers

Summary of Contents for AGRI EASE SW42T

  • Page 1 SW42T Tow Behind Lawn Sweeper Manual Operations & Parts Manual Purchase Date Dealer...

  • Page 2: General Warnings

    SW42T GENERAL WARNINGS READ and UNDERSTAND this manual completely before using the Lawn Sweeper. Operator must read and understand all safety and warning information, operating instructions, maintenance and storage instructions before operating this equipment. Failure to properly operate and maintain the lawn sweeper could result in serious injury to the operator or bystanders.
  • Page 3 SW42T HAZARD SIGNAL WORD DEFINITION This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. DANGER This indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.
  • Page 4 SW42T CONTROLS & FEATURES IDENTIFICATION 1) Hand Lever - Adjust the Brush Height. 2) Nylon Hopper - Holds all types of Debris. 3) Tires / Wheel - Semi pneumatic all terrain tires 4) Hitch - Pin-type design used only with approved vehicles.
  • Page 5 SW42T CAUTION Read and follow all instructions for assembly and operation. Failure to properly assemble this equipment could result in serious injury to the user or bystanders, or cause equipment damage. LAWN SWEEPER COMPONENT PARTS AND ASSEMBLY Take all parts out of the shipping crate and inspect components to ensure there are no missing pieces before starting to assemble the sweeper follow steps 1 through 8.
  • Page 6 COMPONENTS & HARDWARE PARTS SW42T REF NO. DESCRIPTION REF NO. DESCRIPTION Hex Bolt - M8x65 Bag Frame Strap Hex Bolt - M8x50 Hopper Support Rod Hex Bolt - M8x40 Lower Hopper Side Tube Hex Bolt - M6x40 Rear Hopper Tube...
  • Page 7 ASSEMBLY INSTRUCTIONS SW42T Step 1: Attach the Angle Bracket to Sweeper Housing 1. Assemble the angle bracket to the sweeper housing using M8x16 hex bolt and M8 hex lock nut. Note: Make sure the bracket is turned as shown and aligned straight with the housing and tighten.
  • Page 8 ASSEMBLY INSTRUCTIONS SW42T Step 3: Fasten Hitch Tubes Together 1. Fasten both hitch tubes together using two M8x65 hex bolts and M8 lock nuts. Loosely tighten. Step 4: Attach Hitch Bracket to the Hitch Tubes 1. Attach the hitch bracket to the hitch tubes using two M8x50 hex bolts and M8 hex lock nuts.
  • Page 9 ASSEMBLY INSTRUCTIONS SW42T Step 5: Assemble the Handle Assembly 1. Attach the height adjustable handle to the height adjustment tube using two M8x40 hex bolts and M8 lock nut. Loosely tighten. 2. Insert a M8x20 hex bolt through the angle bracket. In the following order put the spacer bushing, height adjustment strap, Ø8 big flat washer and M8 lock nut and tighten.
  • Page 10 ASSEMBLY INSTRUCTIONS SW42T 3. Insert the two upper hopper side tubes through the stitched flaps on each side of the bag. 4. Insert the ends of the rear hopper tube onto the ends of the upper hopper side tubes. Fasten together using the plastic plug.
  • Page 11 ASSEMBLY INSTRUCTIONS SW42T 10. Insert the bag frame strap into the stitched sleeve along the front edge of the bag bottom. 11. Attach the bag frame strap to the lower hopper side tubes using two Ø6x37 clevis pins and two hair cotter pins Ø2.
  • Page 12 ASSEMBLY INSTRUCTIONS SW42T 15. Feel along the stitched flap on the hopper bag to locate the lower hole in each upper hopper side tube. Place a hole through both sides of the stitched flaps in alignment with the lower hole.
  • Page 13 ASSEMBLY INSTRUCTIONS SW42T STEP 8: Attach Hopper Bag to Sweeper 1. Slide the ends of the bag arm tubes of the sweeper’s hitch tubes and secure using two Ø6x37 clevis pins and hair cotter pins Ø2. 2. Tighten all hardware before using the sweeper.
  • Page 14 OPERATION INSTRUCTIONS SW42T WARNING Before operating or using the sweeper, review the instructions below and safety information. Failure to follow these instructions may result in property damage or injury to the operator or bystanders. ATTACH SWEEPER TO TOW VEHICLE 1. Make sure the tow vehicle and sweeper are on a level surface.

  • Page 15: Maintenance And Storage

    MAINTENANCE AND STORAGE SW42T WARNING Improper maintenance and storage of the sweeper may void your warranty. MAINTENANCE • After each use clean material out of hopper. • Rinse/dry inside and outside of the sweeper after each use. • Remove any material which has wrapped around the brushes.
  • Page 16 MAINTENANCE AND STORAGE SW42T BRUSH REPLACEMENT 1. Remove the hopper bag from lawn sweeper. 2. Only replace one brush at a time. 3. Tip the sweeper forward on housing. Do not remove the hex bolts from double brush out of retainers.

  • Page 17: Parts Breakdown

    PARTS BREAKDOWN SW42T...

  • Page 18: Parts List

    PARTS LIST SW42T REF NO. DESCRIPTION REF NO. DESCRIPTION Hopper Rope Hex Bolt M6x12 Vinyl Cap Dust Cover Retainer Hopper Frame Tube (Rear) Inside Star Washer Bag Frame Strap Brush Shaft Bushing Hopper Support Rod Spacer Bushing Hopper Bag Spacer Axle Lock Washer Ø10...
