- Page 1 G-kit Bonanza 1m2 ___________________________________________________________________ Installation instructions Versie: Eng. 2018-9 www.g-tools.nl...
-
Page 2: Specifications
Warranty procedure: G-tools offers a 2 years warranty on all components of the Bonanza except bulbs and filters. Please contact your G-tools rep to explain the problem as there might be an easy fix without having to replace a part. - Page 3 1023 back panel top right -1 x hole 21mm 1028 -3 x hole 76mm Total packing 3 boxes (without box or pallet) Items marked with a * are only part of a complete version. www.g-tools.nl...
- Page 4 Picture 1: composition of all parts of the G-kit Bonanza. www.g-tools.nl...
- Page 5 Make a “ring” with 2 x profile O and 2 x profile J. Use the 4 plastic connectors (R). Place the ring on the 4 angle profile 505mm (M) and push it tight carefully. www.g-tools.nl...
- Page 6 Place the roof panel (A2) on the 4 angle profiles 1000mm and push it tight carefully. Make sure the carbon filter is at the front side and timer on the right. G-kit Bonanza installation instructions: 1. General: www.g-tools.nl...
- Page 7 The cable from the timer box has to be pulled through the turn buckle before the suplied plug can be mounted. The blue and brown wire should be connected to the plug’s poles. The green/yellow cable should be fixed to the connector in the centre. 2. The air inlets Each air inlet consists of 2 parts. www.g-tools.nl...
- Page 8 Put the timer on Set the time by turning the▲ at current time. The green pins in the outer ring mean: Positioned outside – ON Positioned inside – OFF Set the timer for lights ON by pushing the pins outwards www.g-tools.nl...
- Page 9 Contact: For all your questions visit our website www.g-tools.nl or send an e-mail to: info@g-tools.nl WEEE registration number: DE 68161470 The symbol of the crossed-out wheelie bin on electrical and electronic equipment means that it mustn’t be removed in household waste.
