These instructions outline the procedures to install a wireless router in
your NGX Jukebox.
Tools Required
11/32 nut driver.
Parts Included with this Kit:
Item #
Part Number
1
28280004
2
22323701
3
70093401
4
87843000
1
2 2
Installation Instructions
Kit Wireless Router 26704801
Description
Wireless Router
Router Mounting Bracket
½" Cable Clamps (Not Shown)
#8-32 Nuts (Not Shown)
These Instructions
Figure 1
Quantity
1
2
2
4
Page 1 of 2
26704850
REV. A
