Summary of Contents for Duux Mistral
- Page 1 Mistral dehumidifier user manual...
- Page 2 Mistral is the perfect tool to extract high levels of moisture from the air in rooms up to 40m². With its whisper quiet operation, it can remove up to 15L of moisture per day. The device is equipped with a LED hygrostat display to set the desired humidity level at 5% accuracy.
-
Page 3: Table Of Contents
Table of contents 1. Product overview 2. Installation & use 3. Functions 4. Maintenance 5. Technical specifications 6. FAQ... -
Page 4: Product Overview
1. Product overview Control panel Pop-up handle Air outlet Air inlet PET Filter Draining hose Removable water tank Water outlet Power cable... -
Page 5: Installation & Use
2. Installation and use Placement Note: Please take notice of below instructions before using the product. Please place away from walls, windows and furniture. Installation Top: • The machine must be put upright 2 hours at least 30cm before using. •... - Page 6 Control panel Status indicator LEDs Change hygrostat setting Power button Hygrostat display Timer indicator LEDs Change operation mode Operation mode indicator LEDs Activate / change timer mode...
- Page 7 Connecting the product Connect the power cable to a power socket Caution: • Do not plug in the device or pull plug out of the power supply with wet hands or use the product. • Thoroughly dry your hands before you use the device.
- Page 8 Using the drainage hose Note: Please check that the power is off before removing the water tank from the device. Attention: Never connect the draining hose during operation. Remove the water tank and remove remaining water; Connect the draining hose to the water outlet pipe;...
-
Page 9: Functions
3. Functions Note: see product overview (chapter 1) for Attention: If the running status indicator is reference. blinking, it means that the ambient temperature is below 0⁰C or above 40⁰C. Please adjust temperature. Control panel Use the control panel to adjust the settings. •... - Page 10 Operation mode button Note: Operating in quiet mode may decrease dehumidifying performance. Dry clothes – use this mode to speed up wet clothes drying in a humid environment. Pop-up handle Use this handle to carry and move the device. Note: In dry clothes operation mode, the Fold it back to hide.
- Page 11 Attention: Regularly check that the air inlet is not obstructed by hair or dust. Water outlet Water is drained in the water tank through the water outlet. Draining hose Use the draining hose for continuous water drainage. Note: Please make sure the hose is completely rolled out and that the end of the hose is lower than the water outlet pipe, otherwise the water will not drain and flooding may occur.
-
Page 12: Maintenance
4. Maintenance Maintenance before storing Important: Be sure to switch off the device and remove the power cable from the outlet before Please conduct the following maintenance before carrying out maintenance. storing the device: Important: Do not soak immerse the power Follow the same steps under ‘Weekly cable or the device in water. -
Page 13: Technical Specifications
5. Technical specifications Weight: 14 kg Power consumption: 220W Dehumidifying capacity : 15L/day Air circulation: 130CBM/hr 220 mm Water tank capacity: 2.5L Effective area: 30-50m Timer modes : 2/4/8hr Noise level: 38dBA Hygrostat range : 40-80% RH (5% interval) 300 mm The appearance Main materials: ABS, PP... -
Page 14: Faq
6. FAQ Q. The device does not turn on when pressing Q. The running LED indicator blinks. What the power button. What should I do? should I do? A. Please check if the power plug is connected to a A. – The device sensors indicate the ambient wall outlet and plugged in completely or if temperate is <0⁰C or >40⁰C. - Page 15 Q. The device is making a strange sound. What should I do? A. Please check if the device is on a stable surface and in upright position. Q. Can I also use this device in the winter season when the heating is on? A.
- Page 16 Designed in The Netherlands bij Duux International BV. Made in P.R.C. Duux International BV, P.O. Box 145, 5400 AC Uden Netherlands, www.duux.com © 2016 Duux. All rights reserved. DUUX® is a trademark of Duux International BV, registered in the EU and other countries.
