Model:
MIHV16O
MIHV240
Page 1 of 2
The MIHV module provides an additional layer of independent Over-Voltage protection for Lithium based batteries.
To provide enhanced protection for both loads and lithium batteries the MIHV must be used with a suitable BMS. The
MIHV can also be used in Lead Acid based systems where a BMS is not used. The unit provides local and remote
system status indications.
Features:
● Automatic Over Voltage Disconnect to protect batteries and loads during a Over Voltage Event or BMS Tripping
● Auto-detection of 12V / 24V / 48V Nominal Battery Voltages.
● Self resetting Over Temperature Protection (OTP)
● 30% surge capability for short periods
● Remote Status Wire
Specifications:
Input Voltage(DC)
Peak Current
Constant Current
Over Voltage Protection Above (±3%)
Reconnection Below (±3%)
Low Battery Indication (±3%)
Dimensions
** Other voltages are possible MOQ applies.
Warranty Conditions: Our products come with guarantees that cannot be excluded under the Australian Consumer Law.
The customer is entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage.
The customer is also entitled to have the products repaired or replaced if the products fail to be of acceptable quality and the failure does not
amount to a major failure.
GSL Electronics (GSL) warrants that its products will, under normal use and service, be free of defects in material and workmanship for a period of
two (2) years from the date of the original purchase by the customer as marked on the customer's original invoice.
Please refer to our website for full warranty and return information which can be found at http://www.gsl.com.au/faq.html
Solid State Over-Voltage Disconnect
Please read these instructions before use
Model
Unit 2, 110 Station Road, Seven Hills ,NSW, 2147, Australia
More information https://www.caravansplus.com.au
Operating Instructions
MIHV Series
MIHV160
15V-95V
80A
60A
16.5V / 33V / 66V**
15.5V / 31V / 32V**
11.5V / 23V / 24V
135mm x 70mm x 50mm
MIHV240
15V-180V
55A
40A
MIHV-R5
Advertisement
Table of Contents
Summary of Contents for GSL electronics MIHV16O
-
Page 1: Specifications
GSL Electronics (GSL) warrants that its products will, under normal use and service, be free of defects in material and workmanship for a period of two (2) years from the date of the original purchase by the customer as marked on the customer’s original invoice. - Page 2 Model: Solid State Over-Voltage Disconnect MIHV16O MIHV240 Operating Instructions Page 2 of 2 Please read these instructions before use Wiring Diagram: BLACK - Common Negative GREEN - Remote Status Positive Output to Battery or Device Positive Positive Input from MPPT...
