Summary of Contents for DEVDEEP ELECTRICALS Solar
- Page 1 Solar Power Owner’s Manual Roof Top Grid Connected Solar PV System DEVDEEP ELECTRICALS...
-
Page 2: Table Of Contents
Table of Contents Introduction ........................................3 Owner Safety for Maintenance ..................................3 How Your DEVDEEP SOLAR System Works ............................. 4 System Performance ....................................4 Operating Instructions ....................................5 Operating Safety Instructions ..................................5 Trouble Shooting ......................................6 Maintenance of Solar PV System Equipments ............................7 Important Reminder ..................................... -
Page 3: Introduction
Switch OFF the Solar Supply Main Switch in the Main Switchboard or Meter Box Switch OFF the AC Isolator and DC Isolator adjacent to the Inverter Following these steps will safely isolate the solar array. To switch it back on, you simply reverse the procedure. -
Page 4: How Your Devdeep Solar System Works
Electricity to House (AC) The solar electric modules are usually fitted to the roof. The number of modules will depend on the nominal size of your system and, collectively, they are known as the solar array. The solar array converts sunlight into direct current (DC) electricity. -
Page 5: Operating Instructions
Do not Attempt to Clean or Come in contact with the surface of a solar module with broken • glass. This could result in a Dangerous Electric Shock. Be Aware that power may be present at any point in Electrical Circuits despite the Opening of •... -
Page 6: Trouble Shooting
POSSIBLE CAUSE RESOLUTION Check Array Supply. In day Hours with Array Voltage Absent. Check Array Supply Low/High Good Solar Array is at extremely Low/ Voltage Condition. Radiation. High Voltage Condition. Switch On Array Breaker, If It iii) Array breaker trip/off position. -
Page 7: Maintenance Of Solar Pv System Equipments
Space between two rows of solar structure should be at least twice of the height of the Solar panel structure at the highest point of Tilt. This minimum space is required to avoid shadow of one row of solar structure to fall on the row behind it. -
Page 8: Important Reminder
Refer to the warranty information contained in the documentation supplied with your solar electric modules. Solar PV modules have a 25-year limited warranty. This means they are guaranteed to perform to 90% capacity for 15 years and 80% for the remaining 10 years. The module warranty is provided by the manufacturer of the modules. -
Page 9: Accredited Installer Details
3. Elevation angle Expected loss 4. Shading of solar array Expected loss 5. Expected Average Daily output of Solar Array in Kilowatt hours 6. Location of Inverter 7. Location of PV array/s Actual System Performance (to be completed by owner) -
Page 10: Maintenance And Fault Log
Maintenance and Fault Log Please do not climb above 2 meters to maintain solar modules without observing all OH&S regulations. Use only clean water to clean solar modules, no detergents or solvents Date Problem Remedy Electrician... -
Page 11: Inverter Details
Inverter Details Make: Model: Size: Array Details Module type Model VOC ARRAY 1 VOC ARRAY 2 VMP ARRAY 1 VMP ARRAY 2... -
Page 12: Disclaimer
Personal Injury, Damage of Property, Prosecution (from a result of using our products), legal fees or loss of earnings and whether the DEVDEEP SOLAR product was fitted correctly as per this ‘Maintenance Guide’ or not.
