VDB720P
Smart Wi-Fi HD Video Doorbell
Bring safety and security to your home with a wireless video doorbell. Easily answer the door,
wherever you are, by receiving crystal clear images and enabling 2-way audio straight to your
smart device via the App. The handy motion detector feature sends alerts to your device when
someone's near the front door. For additional security, day and night mode automatically
switches and images are clearly visible even in darkness, for safety at all times. With quick and
convenient setup, install the App and connect the doorbell to your home Wi-Fi network in
minutes. The stylish and slim design will be a great addition to the front of your house, simply
mount to the wall and be assured with the confidence of knowing who's at the door, whether
you're at home or out.
Features:
•
HD Video: Receive and record crystal clear images direct to your smart device
•
Two-Way Audio: Answer the door wherever you are, then see and converse with
your visitors directly from your smart device
•
Night Vision Mode: Automatically enabled in the hours of darkness
•
Motion Detection: Sends alerts to your smart device when someone is in close
proximity of the unit
•
Quick and Easy Setup: Connects to your 2.4Ghz home Wi-Fi network in minutes
•
Easy to use App compatible with iOS and Android devices
•
Comes complete with rechargeable batteries and wall fixing kit
Specifications:
Video resolution
Viewing angle
Audio format
Transmission frequency
Storage capacity
IP rating
Batteries
Power consumption
Dimensions
Weight
1280 x 720
166°
Two-way audio with noise cancelling
IEEE 802 11 b/g/n (2.4Ghz only)
Up to 32GB SD card (not supplied)
IP44
2x 18650 batteries (total 5200mAh)
200uA in standby, 170mA in use
140 x 75 x 30mm
275g
Item ref: 350.025UK
User Manual
350.025UK User Manual
Advertisement
Table of Contents
Related Manuals for Mercury VDB720P
Summary of Contents for Mercury VDB720P
-
Page 1: User Manual
VDB720P Item ref: 350.025UK User Manual Smart Wi-Fi HD Video Doorbell Bring safety and security to your home with a wireless video doorbell. Easily answer the door, wherever you are, by receiving crystal clear images and enabling 2-way audio straight to your smart device via the App. - Page 2 Pack contents: 1pc Smart video doorbell 2pcs 18650 Rechargeable batteries 1pc Security screw and key 1pc Wall fixing kit including self-adhesive pad, screws and wall plugs User manual Unit features: IR LED PIR sensor Light Sensor Camera lens Microphone Lens Call Button Indicator LED Speaker...
- Page 3 correct direction and that any shipping tags have been removed from the contacts. Press the reset button for around 5 seconds until the indicator LEDs blink slowly to show that the unit is ready to use. Replace the battery cover, slot the main unit back into the mounting plate and fix securely with the security screw and hex-key provided.
- Page 4 Setup is now complete, and the doorbell will appear as a new device on the top of your device list. To view a live feed at any time, press the small screen within your device list. (see right) With live feed running you can enter the features and settings of the camera by clicking on the settings button on the bottom right hand corner.
-
Page 5: Troubleshooting
To view the video feed in full screen mode, rotate your smart device into the landscape position. Zoom in and out by using the pinching method on the screen, commonly used on most touch screen devices. The doorbell is fitted with a PIR sensor which detects movements around the unit and sends you an audible and visible notification when triggered. - Page 6 PIR detection is being Ensure the PIR on the doorbell is clean and free of triggered too often obstructions Adjust the sensitivity of the PIR in the settings mode to suit the environment PIR detection isn’t Ensure the PIR on the doorbell is clean and free of working obstructions Ensure the PIR settings on your device are set to the...
