- Page 1 Manual Core English www.soundbrenner.com/start 他の言語もオンラインで確認できます DE Weitere Sprachen online verfügbar 온라인으로 더 많은 언어 이용 가능 FR Plus de langues disponibles en ligne 线上有更多语言版本 IT Sono disponibili più lingue online ZH-HANS 網上有更多語言版本 ES Más idiomas disponibles online ZH-HANT...
-
Page 2: Table Of Contents
Index Contents What’s in the box Navigating the device Smart watch Vibrating metronome Contact tuner Decibel meter Other apps Troubleshooting Safety... -
Page 3: What's In The Box
First steps What’s in the box. Soundbrenner Core Body strap Watch strap rig Body strap rig Charging cable Magnetic tuner mount Earplugs Silicone strap Core Steel only. Core Steel only. Italian leather strap Carrying pouch Video: Getting started www.snbr.io/sbc-gettingstarted... - Page 4 First steps Charging the Core. To charge your Core, attach the cable to the magnetic port located on the side of the device. The Core takes 1.5 hours to fully charge. Battery life • 3 days of regular usage or •...
- Page 5 First steps App & compatibility. To ensure your Core has the latest firmware, you need to activate the device in our app first. Download our app by visiting the website below, or search for “Soundbrenner” in the Google Play or iOS App Store.
- Page 6 First steps Magnetic lock system. To put the Core on its rig, hover it right above the rig and let go. Once the Core drops on the rig, it will magnetically snap into place. When placing the Core on its rig, make sure the buttons point towards the direction of your hand.
- Page 7 To change your watch strap, simply turn the device on its back and open the two rivets on each side. We’ve created a range of stylish strap options for the Soundbrenner Core. They’re made from the finest materials such as silicone, woven nylon or Italian leather.
-
Page 8: Navigating The Device
Navigating the device Device overview. Wheel Top button Touch surface (soundwave) Magnetic port Bottom button... - Page 9 Navigating the device Device controls. 1. Top button 2. Bottom button • Go forwards • Go backwards • Start editing selection • Stop editing selection • Open app menu • Power on & off (long press) 3. Wheel 4. Touch surface •...
- Page 10 Navigating the device Power on & off. Power on Hold the top button for 1 second to turn on the Core. Power off Hold the top button for 3 seconds Select yes, by pressing the until the power off prompt appears.
- Page 11 Navigating the device Menu hierarchy. 12:00 Sat. 10 Oct Watch face 100 % Metronome Tuner App menu...
- Page 12 Navigating the device Touch interactions. The Core features a capacitive touch surface. To ensure it can reliably detect your inputs, make sure that you use two fingers flat across the surface. Don’t just use your fingertips! Start or pause a feature...
-
Page 13: Smart Watch
Smart watch Time & notification features. Time notation Use the app to change the time notation from AM/PM to 24h clock Time/date and vice versa. Smart notifications Available after software update in Status December 2019. Status icons Some status icons may not be available until a later update. -
Page 14: Vibrating Metronome
Vibrating metronome Body strap. Where you place the Core on your body can have a big impact on your experience. What works best is different for each musician. The included body strap and body strap rig allow you to wear the Core on your arm, shoulder or ankle. - Page 15 If you have thin arms or ankles To set the body strap to its smallest setting, align the arms of the rig with the markings on the strap as shown in the illustration below. Video: Metronome www.snbr.io/sbc-metronome...
- Page 16 Using a vibrational metronome is different. When you first start using the Core, you need to get used to it first. Don’t give up - you’ll get better over time. It’s just like learning to practice with a traditional metronome! Over time, the vibration can even become a subconscious feeling that helps you keep the beat without thinking about it.
- Page 17 Vibrating metronome Setting up a rhythm. 1. Press the bottom button to select 2. While selected, use the wheel the first value. to change the value. Remember to turn the wheel slowly. 3. Press the bottom button again to 4. Tap the soundwave twice quickly edit the next value.
- Page 18 Vibrating metronome Change lights, vibrations & sounds. Because we know every musician is different, you can customize the Core to your own liking with our app. Lights & vibrations To customize or turn off the lights and vibrations, open our mobile app and go to Settings →...
- Page 19 You can sync up to a total of five devices, allowing you to feel the beat together. If you want to connect a Core to a different mobile device, you need to unpair it from the existing mobile device first. To bring up the unpairing prompt, open the Settings app on your Core, navigate to Bluetooth and press the bottom button.
-
Page 20: Contact Tuner
Don’t worry - should you ever want to remove it, the adhesive leaves no residue behind. Tip: we included a few extra adhesives in the manual holder, just in case you need them. If you want to purchase additional tuner mounts, go to: www.soundbrenner.com/shop Guitar -10Cents 440Hz... - Page 21 First, open the Tuner app on your Core. Next, take the device off its rig by twisting it counterclockwise. Finally, stick the magnetic port located on the side of the Core to the tuner mount. Once you play a string, the LED ring and the screen of the Core will light up. Happy tuning! Video: Tuner www.snbr.io/sbc-tuner...
-
Page 22: Decibel Meter
Decibel meter Sound levels & volume alarm. Tip: for a more accurate reading, we recommend to take the Core off its rig and place it on a soft surface (e.g. a cloth or your hand) before opening the Decibels app. -
Page 23: Other Apps
Shows your current connection status. Press the bottom button to unpair and make your Core ready to pair again. Factory reset This will erase all data and preferences and reset the Core back to factory settings. The device will be locked until the setup is completed with the Soundbrenner app. -
Page 24: Troubleshooting
Troubleshooting Get help. If your Core shows unexpected behavior, perform the following two steps: Soft restart Hard restart Hold both buttons for 5 seconds Make sure the charging cable is and keep them pressed until connected to a power source. Then Recovery mode launches. -
Page 25: Safety
• Coronary Stents affected by the Soundbrenner • Defibrillators Core, consult with your physician • Pacemakers before using the product. Medical • Any other implanted medical conditions include (but are not... - Page 26 Safety Caution: electrical equipment Caution: batteries Your Soundbrenner Core and its Use only an authorized charging cable are electrical devices Soundbrenner charging cable to and should be handled with care. charge your device to avoid any Never use your device in extremely safety or electrical hazards.
- Page 27 Warranty benefits are bands. in addition to rights provided under local consumer laws. You Store your Soundbrenner Core in a are required to provide proof of well-ventilated and dry environment purchase details when making a when not in use.
- Page 28 This product contains QD EU compliance statement Soundbrenner Limited hereby ID 78915. Declaration ID D029964. declares that the Soundbrenner Core is in compliance with the TM and © 2019 Soundbrenner essential requirements and other Limited. All Rights Reserved. relevant provisions of Directive...
- Page 31 Designed for musicians by Soundbrenner.
