WARNING! Read the safety precautions in this section before installing, powering, operating or servicing this product The following symbols are used to identify important safety information on the product and in this manual: DANGER! DANGER! WARNING! WARNING! WARNING! WARNING! WARNING! Safety hazard.
Page 4
Refer any service operation not described in this manual to a qualified technician. Socket outlets used to supply the fixture with power or external power switches must be located near the fixtures and easily accessible so that the fixtures can easily be disconnected from power. PROTECTION FROM BURNS AND FIRE The exterior of the fixture becomes hot during use.
Using for the first time Warning! Read “Safety Information” on page 2 before installing, powering, operating or servicing the fixture. Before applying power to the fixture: Check that the local AC mains power source is within the fixture’s power voltage and frequency ranges. See “Power cables and power plug”...
power cables Power input and throughput cables must be rated 16A minimum, have three conductors 1.5 mm² minimum conductor size and an outer cable diameter of 5 - 15 mm. Cables must be hard usage type and heat- resistant to 90°C minimum. In the EU the cable must be HAR approved or equivalent. If you install a power plug on the power cable, install a grounding-type (earthed) plug that is rated 16A minimum.
Physical installation Warning! The fixture must be either fastened to a flat surface such as a stage or wall, or clamped to a truss or similar structure in any orientation using a rigging clamp. Warning! If the fixture can cause injury or damage it if falls, attach an approved safety cable to one of the safety cable attachment points on the base (see “Fixture overview”...
SETUP Warning! Read “Safety Information” on page 2 before installing, powering, operating the fixture. Control panel and menu navigation The onboard control panel and backlit graphic display are used to set the fixture’s DMX address, configure individual fixture settings (personality), read out data and execute service utilities. See “Onboard control menus”...
Onboard control menus NO. Main Menu Menu level 2 Menu level 3 Remark 001-512 Default 1.Cool white, 2.warm white 1.Dimmer, 2.Cool white, 3.warm white 1.Dimmer, 2.Cool white, 3.warm white, 4.CCT Default : 5CH MODE 1.Dimmer, 2.Cool white, 3.warm white, 4.CCT, 5.Strobe 1.Dimmer, 2.Cool white, 3.warm white, 4.CCT, 5.Strobe.
Page 11
Signal priority after boot: 1. DMX mode: If the EL 150.TW detect an DMX signal, it will be controlled by this signal. 2. Master/Slave The master is controlled by the dimmer switch + CCT switch and controls all connected slaves. To change a slave to master use the onboard control menu (Set/Master/Master) or turn the dimmer switch to 0%, pause 1 sec, turn it to 100% and pause 1 sec.
Page 12
DIMMER MODE provides five dimming options (see picture below): DMX % DMX % DMX % LINEAR SQUARE LAW INVERSE SQUARE LAW DMX % DMX % Up DMX % Down S-CURVE SPECIAL LINEAR – the increase in light intensity appears to be linear as DMX value is increased. SQUARE LAW –...
