DIY Build Instructions – KOSMODROM CHAOS DIVIDER [v 1.4 PCB SET]
First of, thank you for your purchase of the Tsyklon Labs KOSMODROM CHAOS DIVIDER DIY Kit [details below]. If you are a DIY Synth
Veteran [or, as we like to say at Tsyklon Labs - "Hero of Synthesizer DIY"], then this kit will be a fun build. If you are a DIY Synth Novice, you
have selected a build that will certainly strengthen your skills – but, follow the directions and take your time with this build. It is not
exceptionally complicated, but there are a lot of steps. During the build, you will put together many types of circuits – power, digital logic,
analog signal manipulation, high voltage DC [160V], and cold cathode tubes. If you are into coding, you'll even have the option of creating
your own alternate frmware for the Chaos Divider HV. Also, if you are not familiar with component naming, please check out page 37.
First, let's make sure that you have everything on hand before we heat up the iron. The tools you will need are as follows:
- Soldering Iron [if you have both a fne point and a chisel point, that will work well] and Solder
- Wire Cutters
- Needle Nose Pliers
- Fine Point Tweezers [ESD safe is preferred]
- 2.5mm Allen Wrench or Small Phillips Screw Driver for tightening M3 screws on PCB Standofs
- 10mm Deep Well Socket for tightening Potentiometer nuts and 7mm for Toggle Switch nuts
- Knurled Nut Tool [Xicon 382-0006] or 8mm Socket for tightening Jack nuts
- Insulated Trimmer Resistor adjustment tool
- Voltmeter w/ clip leads for trimming On Board Voltage Regulators [10VDC and 160VDC]
- Two pieces of electrical tape, both 2.5" [64mm] long
The following parts have been included in your kit:
Qty Part Description
1
Kosmodrom Chaos Divider Front Panel [WHITE Aluminum Panel with BLUE, BLACK, and RED screen printing]
1
Kosmodrom Chaos Divider Power/Logic Printed Circuit Board v1.4 [RED Solder Mask with BLACK screen printing]
1
Kosmodrom Chaos Divider Signal Printed Circuit Board v1.4 [BLUE Solder Mask, with WHITE screen printing]
1
Kosmodrom Chaos Divider Control Printed Circuit Board v1.4 [WHITE Solder Mask with BLACK screen printing]
9 Orange Water-clear 3mm Orange LEDs [2 pin]
1
Common Cathode 3mm Red/Blue LED [3 pin]
1
ИН-17 [IN-17] 10 Digit Nixie Cold Cathode, Common Anode Vacuum Tube
1
КМ155ИД1 [KM155ID1] Ceramic Nixie Driver IC [16 pin DIP IC]
1
Microchip PIC18F4520 Microcontroller Chaos Engine with Chaos Divider v1.4.x frmware [40 pin DIP IC] with 40 Pin Socket
DIY Build DOC/BOM
KOSMODROM CHAOS DIVIDER
V 1.4
Page 1
Advertisement
Summary of Contents for Tsyklon Labs KOSMODROM CHAOS DIVIDER
- Page 1 First of, thank you for your purchase of the Tsyklon Labs KOSMODROM CHAOS DIVIDER DIY Kit [details below]. If you are a DIY Synth Veteran [or, as we like to say at Tsyklon Labs - “Hero of Synthesizer DIY”], then this kit will be a fun build. If you are a DIY Synth Novice, you have selected a build that will certainly strengthen your skills –...
- Page 2 In fact, it is not safe to lick any side of any circuit board of any of your modules, the Chaos Divider included. Especially the Chaos Divider. Seriously, stop thinking about it. [front and back sides are shown]: DIY Build DOC/BOM KOSMODROM CHAOS DIVIDER V 1.4 Page 2...
- Page 3 ALSO OF NOTE: There are four Mouser carts for this build. One for each of the PCBs and one for miscellaneous hardware such as fasteners and stand-ofs. Be sure to get ALL of them. DIY Build DOC/BOM KOSMODROM CHAOS DIVIDER V 1.4 Page 3...
- Page 4 1-6) If any of the components listed above are missing or damaged, please let us know as soon as possible so that we can arrange to get you the replacement parts that you need! While each PCB's section lists specifc components for the PCB, below is a list of miscellaneous hardware parts that you will need to assemble the Kosmodrom Chaos Divider: Qty PCB Identifer...
- Page 5 1x3 Male 0.1” Pin Header 1 MHDR_OUTPUTS2 1x5 Male 0.1” Pin Header 2 MHDR_OUTPUTS1, MHDR_ICSP 1x6 Male 0.1” Pin Header 2 MHDR_INPUTS, MHDR_NIXIE 1x10 Male 0.1” Pin Header Power/Logic PCB BOM - http://www.mouser.com/ProjectManager/ProjectDetail.aspx?AccessID=37764c1f52 DIY Build DOC/BOM KOSMODROM CHAOS DIVIDER V 1.4 Page 5...
- Page 6 2-2) Next, install R302 – R307 [6 x 10kΩ] into the PCB and solder them in place: 2-3) Install the rest of the resistors into the PCB – R301 [47kΩ], R308 [470Ω], R309 [220Ω], R310 [560Ω], and solder them in place: DIY Build DOC/BOM KOSMODROM CHAOS DIVIDER V 1.4 Page 6...
- Page 7 2-6) Insert CLK_XTAL into the PCB as well as the 40-pin Microcontroller Socket into the PCB and solder in place.Once the 40 pin Socket has been installed, pinch the decoupling capacitors together so that they will stay below the Socket so that the Microcontroller will sit properly in the Socket. DIY Build DOC/BOM KOSMODROM CHAOS DIVIDER V 1.4 Page 7...
- Page 8 2-8) Next, install the last few components for the power supply that go onto the front side of the PCB – VR301 [5k], 10VREG [LM317L], and PF301 [RUSBF110]. Prepare trimmer VR301 by turning it to the middle position. We will adjust it in Step 2-20 when we test and set the power supply components: DIY Build DOC/BOM KOSMODROM CHAOS DIVIDER V 1.4 Page 8...
- Page 9 Use the pictures below and the screen printing on the PCB as a guide. Insert 5VREG into its Heat Sink until the lead end of 5VREG is as fush as possible to the Heat Sink while ensuring that the leads are not touching the Heat Sink: DIY Build DOC/BOM KOSMODROM CHAOS DIVIDER V 1.4 Page 9...
- Page 10 PCB. The other trick that might be helpful is to use a 2x5 pin ribbon connector to keep all of the pins in alignment – some plastic bases used in pin headers may get soft during soldering and this connector helps keep everything aligned: DIY Build DOC/BOM KOSMODROM CHAOS DIVIDER V 1.4 Page 10...
- Page 11 2-16) Install two of the female/female stand-ofs and two of the female/male stand-ofs into the Power/Logic PCB so that the stand-ofs are on the front side of the PCB and the M3 x 6mm screws are installed through the back of the PCB: DIY Build DOC/BOM KOSMODROM CHAOS DIVIDER V 1.4 Page 11...
- Page 12 Connect the Chaos Divider Power/Logic PCB to your power supply of choice and energise. If no “magic smoke comes out” we are ready to proceed. Set your meter to measure DC Volts and insert the test leads into their appropriate connection ports. DIY Build DOC/BOM KOSMODROM CHAOS DIVIDER V 1.4 Page 12...
- Page 13 Huzzah! One PCB completed, two more to go. It is very tempting to install the CHAOS_ENGINE, but resist the urge. We need to complete and test the Voltage Boost Circuit before installing it. DIY Build DOC/BOM KOSMODROM CHAOS DIVIDER V 1.4 Page 13...
- Page 14 47kΩ , 1/4W, 1% Metal Film Resistor 3 D201, D202, D203 1N4733 5.1V, 1W Zener Diode 9 VR201 – VR209 50kΩ PCB Mount Trimmer, side adjust 1 IC203 KM155ID1 and 16 pin DIP Socket DIY Build DOC/BOM KOSMODROM CHAOS DIVIDER V 1.4 Page 14...
- Page 15 The pads for these capacitors are the two squares on the back side of the Signal PCB from the TLV2372 Op Amp ICs [IC201, IC202, IC212, IC234, IC256, IC278, and IC209]. Even though there are pads for an SMD capacitor behind IC203, do not install one of these capacitors for the KM155ID1 Nixie Driver: DIY Build DOC/BOM KOSMODROM CHAOS DIVIDER V 1.4 Page 15...
- Page 16 COM lead to the PCB, freeing both hands for calibrating the output voltage of the Voltage Boost Circuit in Step 3-8. Bend one of these lead clippings in the middle and insert them into the two solder pads of 0VTP and solder in place. Discard the other lead clipping: DIY Build DOC/BOM KOSMODROM CHAOS DIVIDER V 1.4 Page 16...
- Page 17 Then, a quick brush with a soft toothbrush will clear it. Once this step has been completed, you are ready to continue with the Voltage Boost Circuit testing and calibration. DIY Build DOC/BOM KOSMODROM CHAOS DIVIDER V 1.4 Page 17...
- Page 18 Secure the PCBs together with two M3 x 6mm screws, and solder the pin header to the BLUE Signal PCB. 3-7) Install IC200 [NE555] into its socket, and turn the adjustment of VR_HV completely clockwise to prepare for the next step. DIY Build DOC/BOM KOSMODROM CHAOS DIVIDER V 1.4 Page 18...
- Page 19 Take care to not touch any of the components in the Voltage Boost Circuit with your body while calibrating the Voltage Boost Circuit. WEAR EYE PROTECTION! [seriously, we're not messing around] DIY Build DOC/BOM KOSMODROM CHAOS DIVIDER V 1.4 Page 19...
- Page 20 Once both PCBs are separated, insert your Chaos Engine Microcontroller into the 40 pin DIP Socket [being careful to note the notch – it should be away from the crystal/close to the top edge of the RED Power/Logic PCB] and set the RED Power/Logic PCB aside. DIY Build DOC/BOM KOSMODROM CHAOS DIVIDER V 1.4 Page 20...
- Page 21 3-12) Install resistors R221 – R229 [9 x 27kΩ] vertically into the PCB and solder them in place: 3-13) Install resistors R231, R232, R235, R236, R239, and R240 [6 x 24kΩ] vertically into the PCB and solder them in place: DIY Build DOC/BOM KOSMODROM CHAOS DIVIDER V 1.4 Page 21...
- Page 22 To be consistent, and to help with any later troubleshooting, I prefer to bend the anode lead so that the cathode stripe is fat against the circuit board: DIY Build DOC/BOM KOSMODROM CHAOS DIVIDER V 1.4 Page 22...
- Page 23 Red LED's anode and it matches up with the R solder pad. Be sure to insert the LED completely. Solder the center [cathode] pin frst, check for alignment, then solder the other two pins [Blue and Red anodes]: DIY Build DOC/BOM KOSMODROM CHAOS DIVIDER V 1.4 Page 23...
- Page 24 3-20) At this point, you are fnished with the BLUE Signal PCB – for now... It is recommended that you follow the next set of assembly steps closely. There are several components that must be installed in a specifc sequence in or to be successful with this build. Break time, Comrade! DIY Build DOC/BOM KOSMODROM CHAOS DIVIDER V 1.4 Page 24...
- Page 25 If you want to use the same Black Anodized Knobs that we use, you can fnd them here: Qty PCB Identifer Part Description 3 VR_MODE, VR_INTENS, 13mm x 16mm black aluminum knurled knob VR_INTERV http://www.mammothelectronics.com/4SKA-13X16KBK-p/700-1901.htm DIY Build DOC/BOM KOSMODROM CHAOS DIVIDER V 1.4 Page 25...
- Page 26 4-2) Next, install diodes D103 and D104 [2 x 1N4733] into the PCB and solder them in place. These are polarised devices, so be sure to align the stripe on the cathode of the diode to the stripe on the component outline on the PCB: DIY Build DOC/BOM KOSMODROM CHAOS DIVIDER V 1.4 Page 26...
- Page 27 WHITE Control PCB and the male pin headers to the BLUE Signal PCB. Things will get crowded soon on the front of the WHITE Control PCB, so if you clean your fux residue, this is a good time to do it: DIY Build DOC/BOM KOSMODROM CHAOS DIVIDER V 1.4 Page 27...
- Page 28 Make sure that the LEDs are inserted completely against the PCB and that the short leg [cathode] is next to the Out jacks. Again, DO NOT solder any these components yet: DIY Build DOC/BOM KOSMODROM CHAOS DIVIDER V 1.4 Page 28...
- Page 29 If so, complete soldering all of these components except for the LEDs. Because of some taller components on the BLUE Signal PCB, be sure to trim the leads for PB_RESET and VR_MODE [circled in RED] – then re-fow solder as needed: DIY Build DOC/BOM KOSMODROM CHAOS DIVIDER V 1.4 Page 29...
- Page 30 4-10) Remove the Front Panel from the Control PCB. Since they are no longer supported by the front panel, be gentle with the LEDs: 4-11) Install three of the female/female stand-ofs with three of the M3 x 6mm screws onto the back of the Control PCB: DIY Build DOC/BOM KOSMODROM CHAOS DIVIDER V 1.4 Page 30...
- Page 31 1mm guitar pick as a shim to hold it in place. Solder Nixie leads to the BLUE Signal PCB. Take note that the leads will wick solder up towards the Nixie, so do not get heavy handed with the solder. Use just enough to make a good connection and solder joint: DIY Build DOC/BOM KOSMODROM CHAOS DIVIDER V 1.4 Page 31...
- Page 32 Blue Nixie backlight should also be on. De-energise your Power Supply: 4-16) This is another good spot for a break. This time will allow the Voltage Boost circuit to dissipate any stored voltage in the capacitors. DIY Build DOC/BOM KOSMODROM CHAOS DIVIDER V 1.4 Page 32...
- Page 33 4-18) Using two more M3 x 6mm screws [down through the front of the BLUE Signal PCB in the holes next to VR201 and VR209], install the fnal two female/female stand-ofs onto the back of the BLUE Signal PCB: DIY Build DOC/BOM KOSMODROM CHAOS DIVIDER V 1.4 Page 33...
- Page 34 Use the two female/male stand-ofs with the two other female/female stand-ofs on the WHITE Control PCB: 4-20) Connect the Red Power/Logic PCB to the WHITE/BLUE PCB stack. Secure with four more M3 x 6mm screws through the back of the RED Power/Logic PCB: DIY Build DOC/BOM KOSMODROM CHAOS DIVIDER V 1.4 Page 34...
- Page 35 4-21) Install the Front Panel onto the PCB stack and install all nuts on switch, pots, and jacks. Install knobs on VR_MODE, VR_INTENS, and VR_INTERV: 4-22) Power up and Play! Job well done, Udarnik!! DIY Build DOC/BOM KOSMODROM CHAOS DIVIDER V 1.4 Page 35...
- Page 36 250 miles [402 km] high traveling at 17,000 mph [27,359 kph]. Support and Contact Information: If you should have any issues or questions about the assembly of your Kosmodrom Chaos Divider, you can reach us at: diy@tsyklon.com We will make every efort to reply to you as soon as we possibly can.
- Page 37 INTERPRETING COMPONENT DESIGNATIONS FOR TSYKLON LABS MODULES As much as possible, we have tried to be very consistent with how our components are labeled on our Printed Circuit Boards (PCBs). Aside from being consistent component to component, PCB to PCB, and module to module within our own products – we have also done as much as possible to be consistent with standard naming conventions used by other module designers.
