AD610 -- ShowLink® Access Point
IMPORTANT SAFETY INSTRUCTIONS
1. READ these instructions.
2. KEEP these instructions.
3. HEED all warnings.
4. FOLLOW all instructions.
5. DO NOT use this apparatus near water.
6. CLEAN ONLY with dry cloth.
7. DO NOT block any ventilation openings. Allow sufficient distances for adequate ventilation and install in accor­
dance with the manufacturer's instructions.
8. DO NOT install near any heat sources such as open flames, radiators, heat registers, stoves, or other appara­
tus (including amplifiers) that produce heat. Do not place any open flame sources on the product.
9. DO NOT defeat the safety purpose of the polarized or grounding type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wider
blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
10. PROTECT the power cord from being walked on or pinched, particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
11. ONLY USE attachments/accessories specified by the manufacturer.
12. USE only with a cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus.
When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
13. UNPLUG this apparatus during lightning storms or when unused for long periods of time.
14. REFER all servicing to qualified service personnel. Servicing is required when the apparatus has been dam­
aged in any way, such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has
been dropped.
15. DO NOT expose the apparatus to dripping and splashing. DO NOT put objects filled with liquids, such as vas­
es, on the apparatus.
16. The MAINS plug or an appliance coupler shall remain readily operable.
17. The airborne noise of the Apparatus does not exceed 70dB (A).
18. Apparatus with CLASS I construction shall be connected to a MAINS socket outlet with a protective earthing
connection.
19. To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.
20. Do not attempt to modify this product. Doing so could result in personal injury and/or product failure.
1/13

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ShowLink AD610 and is the answer not in the manual?

Questions and answers

Related Manuals for Shure ShowLink AD610

Summary of Contents for Shure ShowLink AD610

  • Page 1 AD610 -- ShowLink® Access Point IMPORTANT SAFETY INSTRUCTIONS 1. READ these instructions. 2. KEEP these instructions. 3. HEED all warnings. 4. FOLLOW all instructions. 5. DO NOT use this apparatus near water. 6. CLEAN ONLY with dry cloth. 7. DO NOT block any ventilation openings. Allow sufficient distances for adequate ventilation and install in accor­ dance with the manufacturer’s instructions.
  • Page 2 Shure Incorporated 21. Operate this product within its specified operating temperature range. Explanation of Symbols Caution: risk of electric shock Caution: risk of danger (See note.) Direct current Alternating current On (Supply) Equipment protected throughout by DOUBLE INSULATION or REINFORCED INSULATION...
  • Page 3 Shure Incorporated • Automated channel selection—Independently scans 2.4 GHz frequency range and determines best channel for • Automatic frequency agility—Moves a ShowLink network to the best available 2.4 GHz channel in the event of signal degradation • Wireless Workbench 6 software supports networked control of all device functions and provides a ShowLink plot for viewing 2.4 GHz signal levels...

  • Page 4: Furnished Accessories

    Wireless Microphone Clip WA371 5/8" to 3/8" Thread Adapter 31A1856 Shielded 25 foot Ethernet cable for ShowLink access point, RJ45-to-EtherCon 95A15104 connector Power Supply PS43 Note: Model availability depends on region. See your local Shure dealer or distributor for details. 4/13...

  • Page 5: Optional Accessories

    Shure Incorporated Optional Accessories Directional 2.4 GHz patch antenna AXT644 (available depending on regional regulations) ShowLink Basics ShowLink Channels and 2.4 GHz Spectrum ShowLink channels that enable remote control of Axient transmitters operate in the 2.40 to 2.484 GHz portion of the RF spectrum in accordance with the IEEE 802.15.4 protocol.

  • Page 6: Power Over Ethernet

    Power Over Ethernet The Shure Ethernet switch and Axient rack components offer network ports with Power over Ethernet (PoE). The network port powers the access point as long as the host component is powered on.

  • Page 7: Reset Option

    Shure Incorporated Networking Networking the access point using a DHCP­enabled router automatically assigns an IP address, simplifying net­ work setup. The network connection allows the access point to share data with networked components and en­ ables wireless control of the transmitters. To manually assign an IP address to the access point, use Wireless Workbench 6.
  • Page 8 Shure Incorporated Microphone Stand Mount Horizontal Mount Wall Mount 8/13...

  • Page 9: Setting Power Levels

    Shure Incorporated Control and Configure the Access Point with Wireless Work­ bench 6 Wireless Workbench 6 adds the following configuration and networking options for the access point: • Edit Device ID • View connected transmitters • View transmitter capacity • Disable channel agility for troubleshooting •...
  • Page 10 Shure Incorporated Mounting Type WA371 Mic Clip or 1/4-20 thread mount Operating Temperature Range -18°C (0°F) to 60°C (140°F) Storage Temperature Range -29°C (-20°F) to 74°C (165°F) Dimensions 190 mm x 102 mm x 47 mm (7.48 in. x 4 in. x 1.85 in.) H x W x D, without antennas Weight 464 g (16.3 oz.), without antennas...

  • Page 11: Antenna Connection

    This product meets the Essential Requirements of all relevant European directives and is eligible for CE marking. Hereby, Shure Incorporated declares that the radio equipment is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: http://www.shure.com/europe/ compliance (http://www.shure.com/europe/compliance)

  • Page 12: Important Product Information

    Licensing: A ministerial license to operate this equipment may be required in certain areas. Consult your national authority for possible requirements. Changes or modifications not expressly approved by Shure Incorporated could void your authority to operate the equipment. Licensing of Shure wireless microphone equipment is the user’s re­ 12/13...
  • Page 13 Shure Incorporated sponsibility, and licensability depends on the user’s classification and application, and on the selected frequency. Shure strongly urges the user to contact the appropriate telecommunications authority concerning proper licens­ ing, and before choosing and ordering frequencies. Information to the user This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
