Lamina Titan White Developer Kit Manual

t s
tM
itaN eries
K c
it oNteNts
3
2
6
5
4
Overall Case Size - 12" x 9" x 3"
Titan Warm White & Daylight White Developer Kit (DK-05D0-0399)
Item

Description

1 Driver Sub-Assembly, 1050mA
2 Light Source and Heat Sink, 3050K Warm White
3 Light Source and Heat Sink, 4700K Daylight White
4 Plug Adapter, AC, China/ANZAC
5 Plug Adapter, AC, UK
6 Plug Adapter, AC, Europe
o i
PeratiNg NstructioNs
1. Remove the white light engine assembly and driver from the kit case and place them on a suitable
work surface near an AC power outlet. Please verify the DC/DC connection cable is correctly attached
between the light engine and driver.
2. CAUTION. Lamina LED light sources are extremely bright! Before applying power, direct the light
source away from your eyes or wear suitable protective eye wear. Plug the AC adapter's power cord
into a 100-240 VAC/50-60 Hz power outlet using the adapter plugs if required. The light source will now
illuminate.
NOTE: Please unplug the AC power before connecting or disconnecting the LED light engine to avoid
potential damage to the light engine or the driver.
120 Hancock Lane | Westampton, NJ 08060
P
roject
t :
yPe
V
oltage
N
otes
D
escriPtioN
The Titan Warm White & Daylight White Developer Kit enables users to
quickly discover the world of solid state lighting and realize the power
of Lamina's super-bright LED light engines. This kit is intended for the
rapid evaluation and prototyping of LED lighting solutions. It comes fully
assembled and includes everything needed to jump start your design
efforts. As shown in the Developer Kit contents table and photo, this
comprehensive kit includes two white light engines, a commercially
available LED constant current driver, and prewired DC connections.
Figure 1
1
Qty. P/N
1 160-0251 Philhong PSA60W-240
1 160-0248
1 210-0249
1 210-0134
1 210-0135
1 210-0133
| USA | laminalighting.com | T +1 609.265.1401
:
:
:
Notes
N/A
N/A
Franzus NW-12C
Franzus NW-135C
Franzus NW-1C
| TF + 1 800.808.5822
