Shakespeare Electronic FM TAKE-OFF 4358 Quick Start Manual

STEP 2.
To Install The FM Take-Off Between An-
tenna and Power Supply.
Attach cable going to power supply to jack on
FM Take-Off marked POWER SUPPLY. At-
tach cable going to antenna to jack on FM
Take-Off marked ANTENNA.
ELECTRONIC PRODUCTS
OR
FM TAKE-OFF
To Install The FM Take-Off Between Power
Supply and TV Set.
Attach cable going to TV set to jack on FM
Take-Off marked POWER SUPPLY. Attach STYLE 4358
cable going to power supply to jack on FM
Take-Off marked ANTENNA.
STEP 3. Plug 12" cable with Motorola plugs
into jack marked FM OUT on FM Take-Off, plug
other end into antenna jack of FM radio. See
WARNING: TO REDUCE
ELECTRONIC PRODUCTS
Figure 1. Peel paper from one side of mounting
THE RISK OF FIRE OR
3801 Westmore Drive, Columbia, SC 29223
adhesive pad and press it firmly onto back of
Ph: 803.227.1590
SHOCK HAZARD, DO NOT
FM Take-Off, peel paper from other side and
FAX: 803.419.3099
EXPOSE THIS
press onto surface.
APPLIANCE TO RAIN
OR MOISTURE.
