BARRON EXITRONIX 400E Series Installation Instructions

READ AND FOLLOW ALL SAFETY INSTRUCTIONS.

When using electrical equipment, basic safety precautions should always be followed including the following:

• DISCONNECT AC POWER SUPPLY BEFORE SERVICING.

• Installation and servicing of this equipment should be performed by qualified service personnel only.

• Ensure that the electrical wiring conforms to the National Electrical Code NEC® and local regulations if applicable.

• Do not mount near gas or electrical heaters.

• Do not use outdoors.

• Equipment should be mounted in locations and at heights where it will not be readily subjected to tampering by

unauthorized personnel.

• The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition.

• Any modification or use of non-original components will void the warranty and product liability.

• Do not use this equipment for other than intended use.

• Allow battery to charge for 24 hours before first use.

• For use with metal enclosed wiring systems.

1. Remove cover by pulling equally forward at the outer rim of the faceplate on opposite sides.

2. Remove pan assembly by removing 4 screws.

3. Punch desired knockouts located on the top, sides or back of the sign for mounting.

4. For mounting of canopy, wall or flush mount follow steps below.

a) Attach canopy to enclosure using threaded nipple and nut.

b) Secure mounting plate to junction box using screws provided with junction box.

c) Secure canopy to junction box using 6-32 x 3/8" screws.

5. Make connection with AC supply inside junction box as described in the Electrical Connection section.

6. Mount the housing/canopy assembly securely to the junction box mounting plate.

7. Connect battery leads, black to negative (-) and red to positive (+).

8. Remove the proper chevron(s) from the EXIT faceplate if necessary.

9. Reinstall pan assembly with 4 screws.

10. Replace faceplate onto housing and resecure.

10070160 Rev 3 - 12/18

IMPORTANT SAFEGUARDS

SAVE THESE INSTRUCTIONS!

INSTALLATION INSTRUCTIONS

400E SERIES

800.533.3948 • www.barronltg.com
