- Page 1 2 mega network high speed vehicle number identification & remote distance surveillance camera User Manual SNO-6095RH...
-
Page 2: User Manual
Disclaimer Samsung makes the best to verify the integrity and correctness of the contents in this document, but no formal guarantee shall be provided. Use of this document and the subsequent results shall be entirely on the user’s own responsibility. -
Page 3: Important Safety Instructions
overview Important Safety InStructIonS 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with dry cloth. 7. Do not block any ventilation openings, Install in accordance with the manufacturer’s instructions. -
Page 4: Explanation Of Graphical Symbols
overview WarnInG TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECT THROUGH THE VENTILATION GRILLS OR OTHER OPENNINGS ON THE EQUIPMENT. Apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus. - Page 5 class construction An apparatus with CLASS construction shall be connected to a MAINS socket outlet with a protective earthing connection. Battery Batteries(battery pack or batteries installed) shall not be exposed to excessive heat such as sunshine, fire or the like. Disconnection Device Disconnect the main plug from the apparatus, if it’s defected.
- Page 6 overview y Do not allow the camera to face the sunlight or intense light. (This may cause serious damage to the CMOS element or internal circuit.) y Do not touch the front window (be careful not to leave any fingerprints or scratches).
- Page 7 contentS oveRview Important Safety Instructions Product Features What’s Included At a Glance insTALLATion & How to install a camera for ConneCTion vehicle number identification How to connect the power supply and network web vieweR Connecting to the camera seTup sCReen Camera settings - for vehicle number identification Camera settings - for security...
-
Page 8: Product Features
overview proDuct featureS • Camera-linked high efficiency lighting using a power-IR LED enables photography of the number plate of an entering vehicle, even during nights with no illumination. • The camera power supply and the driver are embedded in the camera. •... - Page 9 WHat’S IncLuDeD Please check if your camera and accessories are all included in the product package. Appearance Item Name Quantity Description Screw Product installation fixture Washer spring Product installation fixture Washer Product installation fixture Perform camera test by connecting to a Monitor cable for testing portable display NETWORK CAMERA...
- Page 10 overview at a GLance main body Sun shield CONTROLLER Cover Compressive fitting for cable connection Terminal for power supply connection DC 12V 5A adapter Camera, Lens Fixing latch Front glass IR LED window 10_ overview...
- Page 11 camera Item Description Micro SD Memory Compartment for the Micro SD memory card. Card Compartment AUDIO OUT Used to connect to speakers. Audio terminal AUDIO IN Used to connect to a microphone. The button restores all camera settings to the factory default. Press and hold for about 5 seconds to reboot the system.
- Page 12 overview Item Description Lightning protective Used to discharge the lightning current safely outside in order to protect the grounding port camera. Power Port Used to plug the power cable. Network Port Used to connect the PoE or Ethernet cable for network connection. Used to connect the alarm input sensor or external day/ ALARM IN night sensor.
- Page 13 installation & connection HoW to InStaLL a camera for veHIcLe numBer IDentIfIcatIon Install the camera with an angle, horizontal distance and height that ensure the maximum LED radial distance of 20m is not exceeded (vertical angle: 40 degrees or below, horizontal angle: 40 degrees or below) Radial distance 40 degrees or below...
- Page 14 installation & connection HoW to connect tHe poWer SuppLy anD netWorK The camera is designed to connect the cable to the port (compressive fitting) on the bottom side at the rear of the housing. Unfasten the nut of the compressive fitting at the rear of the housing and insert the power cable and the network cable from the outside of the housing inside of it according to the size of each hole.
-
Page 15: Web Viewer
web viewer connectInG to tHe camera 1. Enter the network camera address into the Internet browser (Explorer browser) address bar to connect to the camera. The camera is set to receive an IP address that is automatically assigned from the DHCP server when it is released from the factory. -
Page 16: Setup Screen
setup screen camera SettInGS - for veHIcLe numBer IDentIfIcatIon 1. The camera is released from the factory optimized for vehicle number identification. 2. If you encounter any problems when installing or using a product dedicated to the identification of vehicle number plates, initialize the camera and set only the following 3 options. - Page 17 • Day/night 1) Mode : External 2) Dwell time : Normal 3) Duration : 30 seconds • Settings other than those specified above are given the default value. camera SettInGS - for SecurIty 1. As the camera is set to vehicle number identification mode when it is released, you need to initialize the camera and set it to the default values to use it in security mode.
- Page 18 Auto (ICR) / Color / B/W / External / Schedule Backlight Off / BLC / WDR Compensation Wide Dynamic Range Max. 120dB Contrast Enhancement SSDR (Samsung Super Dynamic Range) (Off / On) Operational Digital Noise SSNRIII (2D+3D Noise Filter) (Off / On) Reduction...
- Page 19 Items Description Gain Control Off / Low / Middle / High White Balance ATW / AWC / Manual / Indoor / Outdoor Electronic Shutter Minimum / Maximum / Anti flicker (1 ~ 1/12,000sec) Speed Flip / Mirror Off / On Intelligent Video Audio detection, Face detection, Tampering, Virtual line, Enter/Exit, Analytics...
- Page 20 appendix Items Description TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, Protocol SSL, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour HTTPS(SSL) Login Authentication Digest Login Authentication Security IP Address Filtering User access Log Network 802.1x Authentication Streaming Method...
- Page 21 Items Description Color / Material Light Gray / Aluminum(Body), Front/Rear(ABS) Open/closure type Side open structure Mechanical Dimension 200(W) X 150(H) X 570(L)mm Weight (Main body) Approx. 4.6 Kg Camera main body User manuals 2 (1 for network camera, 1 for SNO-6059RH) Installation CD Components Test monitor cable...
-
Page 22: Product Overview
appendix proDuct overvIeW Unit : mm 22_ appendix... - Page 23 memo...
- Page 24 6, Pangyo-ro 319beon-gil, Bundang-gu, Seongnam-si, Gyeonggi-do, 463-400 Rep. of KOREA Tel : +82-70-7147-8753, 8764 Fax : +82-31-8018-3740 www.samsungsecurity.com SAMSUNG TECHWIN AMERICA Inc. SAMSUNG TECHWIN EUROPE LTD. 100 Challenger Rd. Suite 700 Ridgefield Park, NJ 07660 2nd Floor, No. 5 The Heights, Brooklands, Weybridge,...
