- Page 1 Commercial Grade French Fry Cutter - 1/2” Blade Instruction Manual SKU: CUTR-F12 Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/cutr-f12 help@vivo-us.com www.vivo-us.com 309-278-5303...
- Page 2 WARNING: IMPORTANT SAFETY INFORMATION READ AND FOLLOW ALL SAFETY REQUIREMENTS KEEP THIS MANUAL IN A SAFE AND DRY PLACE FOR FUTURE REFERENCE If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts.
- Page 3 PRODUCT SPECIFICATIONS MODEL CUTR-F12 TYPE MANUAL DIMENSION (Blades) 1/2” BLADE MATERIAL STAINLESS STEEL BODY MATERIAL CAST IRON PACKAGE CONTENTS B (x1) A (x2) Cutter Body Handle Parts C (x1) D (x1) E (x4) Handle Bolt Blade Suction Feet...
- Page 4 PRODUCT STRUCTURE Shield Push Plate Cutting Plate Guide Rod Handle Push Rod Handle Suction Bolt Feet...
- Page 5 ASSEMBLY STEPS STEP 1 Screw the handle parts (A) together to create the handle. STEP 2 Unscrew one end of the handle bolt (C). Place the handle at the opposite end of the cutting plate (D) face down as shown in the picture. Slide the handle bolt into the aligned holes of handle and base of fry cutter.
- Page 6 MOUNTING INSTRUCTIONS HORIZONTAL SUCTION CUP MOUNTING Fasten suction cup feet to legs of fry cutter using the nuts provided. Press firmly down on the fry cutter to create suction against the work surface. To create more suction, the surface can be wiped with a damp cloth. Suction cups work best on smooth horizontal surfaces.
- Page 7 NOTE: For larger potatoes, it may be necessary to cut a small flat edge on the end of the potato. Place the flat end of the potato against the blade and cut. CARE & MAINTENANCE CLEANING PLEASE USE CAUTION WHEN HANDLING THE CUTTING PLATE AND BLADES. Please clean French Fry Cutter before and after each use.
- Page 8 - 83% within < 2hr - 92% within < 3hr www.vivo-us.com : < 15 M AVG. RESOLUTION TIME (within office hrs) : 5M 4S 309-278-5303 AVG. RESOLUTION TIME (within office hrs) FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
