- Page 1 LED SPOT 90 MJ-1014 User manual Thank you for choosing our 90W LED moving head light. For the sake of your safety, Please read and follow these instructions carefully and keep this manual in a safe place for future reference.
-
Page 2: Table Of Contents
LED Moving Head Wash 3610 MJ-1006C User Manual ver2.0 Catalogue Chapter Page Safe Usage Of The Product -----------------------------------------------------------------------------------------3 Install The Equipment ------------------------------------------------------------------------------------------------4 Power Code Connection ---------------------------------------------------------------------------------------------4 DMX Connection ------------------------------------------------------------------------------------------------------5 DMX Terminator -------------------------------------------------------------------------------------------------------6 Function Set ---------------------------------------------------------------------------------------------------------------6 Operation Menu ---------------------------------------------------------------------------------------------------------6 Maintenance --------------------------------------------------------------------------------------------------------------8 Keeping The Product Clean ------------------------------------------------------------------------------------------9 Trouble Shooting... -
Page 3: Safe Usage Of The Product
LED Moving Head Wash 3610 MJ-1006C User Manual ver2.0 SAFE USAGE OF THE PRODUCT When unpacking and before disposing of the carton, check there is no transportation damage before using the product. Should there be any damage caused by transportation, consult your dealer and do not use the apparatus. -
Page 4: Install The Equipment
LED Moving Head Wash 3610 MJ-1006C User Manual ver2.0 Install The Equipment: Use 2pcs clamp and 1safety cord(need to purchase).Use clamp fix with light hook which in the packing box with light, then use screw install to the bottom of lamp. Hang the fixture on the structure and fasten the screws attached to each clamp. -
Page 5: Dmx Connection
LED Moving Head Wash 3610 MJ-1006C User Manual ver2.0 DMX Connection: Connection between the controller and a projector and between one projector and another must be made with a 2 core-screened cable, with each core having at least a 0.5mm diameter. Connection to and from the projector is via cannon 3 pin (which are included with the projector) XLR plugs and sockets. -
Page 6: Dmx Terminator
LED Moving Head Wash 3610 MJ-1006C User Manual ver2.0 DMX Terminator: In the Controller mode, at the last fixture in the chain, the DMX output has to be connected with a DMX terminator. This prevents electrical noise from disturbing and corrupting the DMX control signals. - Page 7 LED Moving Head Wash 3610 MJ-1006C User Manual ver2.0 X Reverse Yes/No Option Y Reverse Yes/No Yes/No XY Exchange Display Language Chinese English Lighteness 1-32 Poorlight Constant open Display LOGO ON/OFF Man Control 0－255 0－255 0－255 …… …… CH18 0－255 Test operation Program run Sound...
-
Page 8: Maintenance
LED Moving Head Wash 3610 MJ-1006C User Manual ver2.0 Settings, Choose menu by pressing ”UP&DWON” button, will show YES/NO,. Y Reverse correcting by “ENTER” Button.. Settings, Choose menu by pressing ”UP&DWON” button, will show YES/NO,. XY Exchange correcting by “ENTER” Button.. ... -
Page 9: Keeping The Product Clean
LED Moving Head Wash 3610 MJ-1006C User Manual ver2.0 Keeping The Product Clean: To ensure the reliability of the projector, it should be kept clean. It is recommended that the fans should be cleaned every 15 days. LED lens should also be regularly cleaned to maintain an optimum light output. - Page 10 LED Moving Head Wash 3610 MJ-1006C User Manual ver2.0 0~15 White 16~31 32~47 Green 48~63 Yellow Color 64~79 Blue 80~95 Pink 96~111 Cyan 112~126 Orange 127~190 Rainbow effect(Fast~slow) 191~255 Rainbow effect(slow~Fast) Color half step 0~255 Color half step 0~255 Pan movement Tilt 0~255 Tilt movement...
-
Page 11: Technical Parameters
LED Moving Head Wash 3610 MJ-1006C User Manual ver2.0 CH16 Tilt Fine 0~255 Tilt Fine CH17 Speed 0~255 XY speed CH18 Reset 0~255 Reset Technical Parameters: Voltage: AC90V-240V; 50/60Hz Power Consumption: 150W (220V) LED Bulbs: 90W*1pcs White LUMEN LED LED Current: 12A LED Lifetime: 50000Hours Color: 7color + blank color wheel Gobo: 9Fixed Gobo + 1 blank Gobo...
