FOR SERVICE TECHNICIAN ONLY—DO NOT REMOVE OR DESTROY
Requirement
t01 none Start
Power
t02 none Start
Start
Hold start
Power
t03 none Start
Start
Start
Start
Power
t04 none Start
Any button
Power
t05 none Start
Power
t06 none Start
Start
Start
Power
t07 Main level Start
pressure
switch must
work
Power
t08 none Start
Power
t10 none Start
Power
t11 none Start
Start
Power
t12 none Start
Start
Start
Start
Power
t13 none Start
Power
6
175D6149P002
DETAILS FUNCTION
Sequence
Displays defined Model id (1-6); displays "---" if new board (to set Model id, rotate knob until desired id (1-6)
displayed, press and hold "START" key to program this model)
Returns to "t01"
Displays most recent error code (E00=none)
Displays previous error code (up to previous 10)
Clear all error codes (and then displays E00)
Returns to "t02"
Alternate "UL" and UL software version
Alternate "cod" and Control Software version
Alternate "EE" and eePROM version
Alternate "Inv" and Inverter Software version
Returns to "t03"
Loops on lighting LED's, LCD, and cycle ids
Beeps when depressed
Returns to "t04"
Displays "P" and pump for 60 seconds
Returns to "t05"
Displays "E" (for Empty) and starts filling when reaches Foam level—displays "F"
Fill, when reaches Main level—displays "nl"
Fill, when reaches overflow level—briefly displays "OF," pumps out, displays "E" when tub empty
Returns to "t06"
For GFWH1100, GFWN1200, GFWN1300, GMAN1200 models:
Displays temperature in °F, turns on cold water (CV1) for 10 seconds, turns off CV1 and turns on HV for a maximum
pressure time-out of 5 minutes
For GFWH1200, GFWH1300, GFWH1400, GFWH1405, GFWS1500, GFWS1505 models:
Displays temperature in °F, turns on the CV and fills the tub until the Main level switch closes. Turn on the heater for a
maximum of 5 minutes
Pumps out water and returns to "t07"
Displays "SEA" and rotates the basket at 43 revolutions per minute (only for GFWS1500 and GFWS1505 models
Stops rotating the basket, turns off the steam and returns to "t08"
Displays "tt" and tumbles tub alternating the direction every 5 seconds
Stops tumbling and returns to "t10"
Spins to 400 RPM displaying increasing RPM
For GFWH1100, GFWN1200, GFWN1300, GMAN1200, GFWH1200, GFWH1300 models:
Spins to 1000 RPM (displays A00)
For GFWH1400, GFWH1405, GFWS1500, GFWS1505 models:
Spins to 1100 RPM (displays B00)
Stops spinning and returns to "t11" when stops
Displays "ddt" and turns on HV to fill detergent compartment (for GFWH1100, GFWN1200, GFWN1300, GMAN1200,
GFWH1200, GFWH1300 models)
Displays "pdt" and turns on HV to fill Pre Wash compartment (for GFWH1400, GFWH1405, GFWS1500, GFWS1505 models)
Displays "bdt" and turns on CV2 to fill bleach compartment (for GFWH1100, GFWN1200, GFWN1300, GMAN1200, GFWH1200,
GFWH1300 models)
Displays "ddt" and turns on HV to fill main dispensing compartment (for GFWH1400, GFWH1405, GFWS1500, GFWS1505
models)
Displays "Fdt" and turns on CV1 and CV2 to fill softener compartment (for GFWH1100, GFWN1200, GFWN1300, GMAN1200,
GFWH1200, GFWH1300 models)
Displays "bdt" and turns on CV to fill bleach compartment (for GFWH1400, GFWH1405, GFWS1500, GFWS1505 models)
Displays "HCt" and turns on CV1 and HV to fill detergent compartment (for GFWH1100, GFWN1200, GFWN1300, GMAN1200
GFWH1200, GFWH1300 models)
Displays "Fdt" and turns on CV to fill softener compartment (for GFWH1400, GFWH1405, GFWS1500, GFWS1505 models)
Pumps out water and returns to "t12"
Starts EOL test sequence (NOT used in Repair)
Returns to "t13"
