Congratulations on your purchase of a MODZ® Max golf cart battery
charger!
If you have questions, concerns or experiencing issues of any kind,
please contact us using one of the methods below. Please do not return
unit to online retailer.
Phone:
Speak to one of our customer service representatives at 844-
MODZ-USA Monday through Friday 8:00am – 6:00pm CST
Email:
Contact our customer service team anytime with questions
regarding your MODZ® Max battery charger at
info@cartmodz.com
Website:
Send us a message online at our website
https://cartmodz.com/max/
®
1 |
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for MODZ Max Series
- Page 1 Congratulations on your purchase of a MODZ® Max golf cart battery charger! If you have questions, concerns or experiencing issues of any kind, please contact us using one of the methods below. Please do not return unit to online retailer.
- Page 2 Safety Precautions…………………………………………………………………..3 Important Safety Instructions…………………………………………………..4 III Charger Protection Functions………………………………………………………… 8 IV Operating Instructions……………………………………………………………..9 Charger Features………………………………………………………………....10 VI Charger Status Indicator………………………………………………………………… 11 VII Warranty Information………………………………………………………....12 VIII Compliance Statements………………………………………………………... IV Dimensions & Operating Parameters.………………………………….... 14 ®...
- Page 3 • NEVER splice, extend or otherwise alter the AC/DC cord. Altering either cord may increase risk of fire or electrocution • DO NOT attempt to repair the charger. Attempting to repair or alter the charger may increase risk of fire or electrocution •...
- Page 4 Please read this manual in its entirety prior to operating the battery charger. 2. BATTERY TYPES MODZ® Max battery chargers should only be used with flooded lead- acid batteries manufactured by reputable golf cart battery brands. 3. UNPLUGGING CHARGER To reduce the risk of damage, gently unplug the charger at the charging plug and never disconnect the charger by pulling on the cord.
- Page 5 6. DO NOT OPERATE CHARGER IF IT HAS BEEN DROPPED OR DAMAGED Do not operate charger if it has been dropped, sustained a hard impact or damaged in any way. 7. DO NOT DISASSEMBLE CHARGER Do not disassemble the charger. Disassembling the charger will void the limited 18-month warranty.
- Page 6 c) Always wear proper safety equipment when working with lead-acid batteries including protective safety goggles and gloves. d) If your skin or clothing comes into contact with battery acid, immediately wash with soap and water. If battery acid comes into contact with eyes, immediately flush eyes with cold running water for at least 10 minutes and seek medical assistance as soon as possible.
- Page 7 If using an extension cord is absolutely necessary, please refer to the precautions outlined in this instruction manual. 14. MOUNTING THE CHARGER The MODZ® Max battery charger can easily be mounted to flat a surface via the mounting base. a) When mounting the battery charger, it is recommended to use nuts and bolts instead of screws.
- Page 8 ● Burnout Protection: If the charger exceeds normal operating temperatures, power output will be decreased until regular operating temperatures resume. If the charger exceeds 149° F, the charger will automatically stop charging and go into standby mode until normal operating temperatures are detected and charging can safely be resumed.
- Page 9 MODZ® Max battery chargers are intended for use with flooded/wet- acid golf cart batteries only. Always refer to your battery manufacturer’s instructions when recharging your batteries. ONLY CHARGE YOUR GOLF CART IN WELL VENTALITED AREAS AS FLOODED/WET-ACID BATTERIES PRODUCE COMBUSTABLE GASES...
- Page 10 1 meter (3.2ft) for up to 30 minutes. RUGGED CONSTRUCTION The MODZ® Max battery charger is constructed with a durable die-cast aluminum alloy casing. The internal circuitry of the charger is coated with a protective thermal silica gel providing significant protection against dust, water and vibration.
- Page 11 The MODZ® Max charger features an easy-to-read led charging status indicator light. CHARGING STATES Charging Mode Battery Level Charging State Indicators Trickle Charging 0% - 20% Red flashing: On 1 second, Off 3 seconds Low Battery Charging 20% - 80%...
- Page 12 The MODZ® battery charger includes an 18-month limited warranty. The 18-month limited warranty is non-transferable and only available to the original retail purchaser. The warranty coverage starts on the date of purchase. Within this coverage period, any product defect will warrant a full replacement charger at zero cost to the consumer excluding any replacement shipping costs.
- Page 13 All end users of the charger must comply with relevant laws and regulations when recycling the charger. Electromagnetic Compatibility The MODZ® Max charger complies with the Electromagnetic Compatibility Directive 2014/30/EU which requires devices to not: • Cause excessive electromagnetic interference •...
- Page 14 Dimensions: 11 in x 3 in x 6 in Weight: 7.2 lbs AC CORD LENGTH 8 ft DC CORD LENGTH 8 ft AC Input Voltage Range 90-120VAC; 45-65Hz AC Input Max Current: 8.0A @ 100VAC Power Factor: >0.99 Efficiency: >94.0% Noise <45dB Ingress Protection Rating...
Need help?
Do you have a question about the Max Series and is the answer not in the manual?
Questions and answers
Brand new modz 48 v, 15 amp battery charger, is the fan supposed to be moving while charging batteries
The context does not explicitly state whether the fan is supposed to move while charging batteries with the MODZ 48V, 15 amp battery charger. However, it does mention the need for at least 2 to 3 inches of space behind the fan for sufficient cooling, which implies that the fan is active and likely moves during operation.
This answer is automatically generated
Why fan not working on the modz golf cart battery charger
The fan on the MODZ Max Series golf cart battery charger may not be working because the charger has not yet begun the proper charging mode. The fan only turns on once the charger has assessed the battery level and started charging. If the charger is still assessing battery capacity and ambient temperature (while flashing red and green), the fan may not activate yet.
