2.3 OSD Control

1. Click MENU to display the OSD window as shown in the following figure.
2. Click < or > to select the function to be adjusted as shown in the following figure.
3. Click the MENU to select the function to be adjusted.
4. Click < or > to change current settings.
5. To exit OSD, select "
other settings, repeat steps 2-4.

2.4 OSD Menu Screen

OSD Setting
Auto Adjustment
Message
Restore
Exit
The OSD disappears several seconds after you stop pressing the buttons while
performing an adjustment.
Any changes are automatically saved in the memory when the OSD disappears.
Turning off the power should be avoided while using the menu.
Adjustments for clock, phase and positions are saved for each signal timing. Except for
these adjustments, all other adjustments have only one setting, which applies to all
signal timings.
The color will change from white to pink while the function is selected.
All manuals and user guides at all-guides.com
" to close the OSD window and save changes. To change
16
Bright/Contract Adjustment
Phase/Clock pulse Adjustment
Horizontal/Vertical Adjustment
Color Temp. Adjustment
Language Selection
