Ahlborn ALMEMO 8006-RTA3 Operating Instructions Manual

Relay trigger adapter, analog
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
____________________________
Operating instructions
Relay trigger adapter, analog
®
ALMEMO
8006-RTA3
V2.4
18.03.2014
www.ahlborn.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ALMEMO 8006-RTA3 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ahlborn ALMEMO 8006-RTA3

  • Page 1 ____________________________ Operating instructions Relay trigger adapter, analog ® ALMEMO 8006-RTA3 V2.4 18.03.2014 www.ahlborn.com...

  • Page 2: Operating Controls

    <MENU> Switch display illumination ON <☼ON> F: Function selection ▲, ▼, ► Direct data selection <SET> Program PROG P: Data entry ▲, ▼, ► (5) ALMEMO ® connecting cable to measuring instrument, socket A1, A2.. 2. Connection diagram ALMEMO 8006-RTA3...

  • Page 3: Table Of Contents

    Contents 3. Contents 1. OPERATING CONTROLS................2 2. CONNECTION DIAGRAM................2 3. FUNCTION OF RELAY TRIGGER ADAPTER, ANALOG......4 4. POWER SUPPLY..................4 5. INTERFACE ELEMENTS................4 5.1 Relays....................4 5.2 Trigger inputs..................5 5.3 Analog outputs...................5 5.4 Connecting peripheral equipment............5 6. COMMISSIONING..................6 7. DISPLAY AND OPERATING CONTROLS..........7 7.1 Main menu...................

  • Page 4: Function Of Relay Trigger Adapter, Analog

    (e.g. Phoenix PLC-RSC-24DC/21, 250V 6A) : ► Current or voltage capacity greater than 50 V, 0.5 A ► For separating the mains voltage side ► For implementing an alarm in the event of failure on the control side ALMEMO 8006-RTA3...

  • Page 5: Trigger Inputs

    Relays 6.2 Trigger inputs The trigger inputs TR8 and TR9 can be driven either via optocouplers by volt- age levels (4 to 30 V) or via the two keys (configuration, see 6.3.). When using floating switch contacts the optocouplers must be appropriately wired with supply U+ and U- (see diagram).

  • Page 6: Commissioning

    8 ´driven´ using command ´ipp f9 k8´. 2. If it is intended that the relay should drop out in the event of activation it can be programmed to operate inversely - using the command ´ipp f9 k-8´. ALMEMO 8006-RTA3...

  • Page 7: Display And Operating Controls

    Commissioning 3. Activate the relay using the command ´ipp f1 Rpp´, Deactivate the relay using the command ´ipp f1 R-pp´. Application Driving the analog output : 1. Configure analog output port 6 or 7; see Manual 6.10.7: e.g. selected analog type x (command ´ipp f9 Ax´) assigning to the selected measuring point (command ´ipp f9 E-00´) or assigning to any reference channel xx (command ´ipp f9 Exx´) or output the value yyyyy via the interface (command ´ipp f9 ayyyyy´)

  • Page 8: Device Configuration

    ▼  PROG  Symbol: OFF  e.g switched off by means of : Assign relay ports configured in any way : Symbol: Px  Symbol: `Px´  flashes. In permanent alarm status : To switch this signal OFF press  <MENU>  <OFF>   ALMEMO 8006-RTA3...

  • Page 9: Messages

    Device configuration Watchdog The watchdog function ensures that all relays drop out if the control of the measuring instrument or of controlled relays via the interface fails for a duration of 60 seconds, normally displayed as a watchdog alarm. To switch the watchdog function ON press : <ON>...

  • Page 10: Programming Via The Device Interface

    06 Analog output 10 V Driven value 06:AO5 COM +08.345 V 07:AO6 COM +12.345mA 07 Anal o g output 20 mA Driven value 08 Trigger key Start / stop 08:TR1 0 09 Trigger Optocoupler Manual 09:TR2 1 NO=Normally open NC=Normally closed CO=Changeover ALMEMO 8006-RTA3...

  • Page 11: Electromagnetic Compatibility

    Electromagnetic compatibility 10. Electromagnetic compatibility We, Ahlborn Mess- und Regelungstechnik GmbH, hereby declare that the ALMEMO ® 8006-RTA3 device bears the CE mark and complies with the provi- sions of the Low Voltage Directive and the essential protection requirements of the 89/336/EEC Electromagnetic Compatibility Directive.

  • Page 12: Product Overview Order No

    OA 8006-SH2 2 additional normally closed relays per relay pair OA 8006-OH2 2 analog outputs electrically isolated 0..10V or 0..20mA selectable, incl. 1 ALMEMO ® clamp connector OA 8006-R02 Fixture for top-hat rail mounting ZB 2490-HS ALMEMO 8006-RTA3...

  • Page 13: Index

    Index 11.3 Index Accuracy 11.1 activation status Active Addressing Alarm tone All ports Ambient relative humidity 11.1 analog outputs Analog outputs Analog outputs 11.1 Appendix Changeover Changeover clamp connectors Closed command Commissioning Connecting peripheral equipment Connection diagram contact assignment Current consumption 11.1 Device configuration Display and operating controls...
  • Page 14 Standard equipment 11.1 status Suitable conditions 11.1 Summated alarm switching status Technical data 11.1 Temperature drift 11.1 terminal command Time constant 11.1 To output message top-hat rail mounting 11.2 Trigger Trigger inputs 5, 8 trigger inputs Trigger inputs 11.1 ALMEMO 8006-RTA3...
  • Page 15 Index trigger source variant voltage capacity Watchdog ® ALMEMO 8006-RTA3 15...

  • Page 16: Your Contact

    11. Appendix 11.4 your contact ALMEMO 8006-RTA3...
