TX001-00-00
DV202S Video Transmitter
TeleSite USA Inc. does not warrant that the functions contained in this equipment will meet your requirements or
that the operation will be entirely error free or perform precisely as described in the documentation. This system
has not been designed to be used in life-critical situations and must not be used for this purpose.
Product specifications subject to change without notice.
TeleSite and QuickSilver are trademarks of TeleSite USA Inc.
NOVA and its logo are registered trademarks of Vicon Industries Inc.
Windows is a registered trademark of Microsoft.
TeleSite USA, INC., 225 County Road, Tenafly, New Jersey 07670
TELEPHONE: 201-568-5050 FACSIMILE: 201-568-6444
TOLL FREE: 800-808-5780
TeleSite Part No.
T8009-8001-00-00 Rev 101
Advertisement
Table of Contents
Summary of Contents for TeleSite QuickSilver DV202S
- Page 1 TX001-00-00 DV202S Video Transmitter TeleSite USA Inc. does not warrant that the functions contained in this equipment will meet your requirements or that the operation will be entirely error free or perform precisely as described in the documentation. This system has not been designed to be used in life-critical situations and must not be used for this purpose.
-
Page 3: Fcc Notice
FCC Notice Note: Complies with Federal Communications Commission Rules & Regulations Part 15, Subpart B for a Class A digital device. WARNING This equipment generates and uses radio frequency energy and if not installed and used properly, that is, in strict accordance with the manufacturer’s instruction, may cause interference to radio and television reception. -
Page 5: Table Of Contents
Basic Audio Using Relays........................24 OPERATION ........................25 Resetting the Transmitter ........................... 25 TROUBLESHOOTING ....................... 26 Transmitter ..............................26 CRU ................................26 Receiver ................................ 26 Modem ................................26 Alarms ................................26 Contents • • • • i TX001-00-00 Rev 101 QuickSilver DV202S Video Transmitter... - Page 6 Relays ................................26 Audio................................26 SHIPPING INSTRUCTIONS....................27 REFERENCE........................28 TECHNICAL INFORMATION ..................... 29 ii • • • • Contents TX001-00-00 Rev 101 QuickSilver DV202S Video Transmitter...
-
Page 7: Important Safeguards
For units that CAN BE DISCONNECTED from the power source, use a damp cloth for cleaning. 20. Replacement Parts - Use only TeleSite specified replacement For units that CANNOT BE DISCONNECTED from the power source, use a damp cloth for cleaning and do not allow parts or an approved equivalent to prevent unit damage and injury. -
Page 9: Introduction
Configuration and Operation sections to continue the total installation. Unpacking and Inspection All Telesite USA equipment is tested and inspected before leaving the factory. It is the carrier’s responsibility to provide suitable delivery. Inspect the cartons upon delivery and, if damage is present, make detailed notes on the carrier’s bill. - Page 10 (optional), and control signals are transmitted over ordinary telephone lines (PSTN, ISDN and cellular type) as shown in Figure 1. Software information can be found in TeleSite Manual TX001-10. The core system is comprised of the DV202S Transmitter, QS Receiver Software, a PC-type computer and a pair of Modems.
- Page 11 The system also supports connection to an several manufactured Camera Domes via an RS-232 or RS- 422/485 connection. Refer to document TX006, Pan, Tilt and Zoom setup instructions for details on how to connect these. Introduction • • • • 3 TX001-00-00 Rev 101 QuickSilver DV202S Video Transmitter...
-
Page 12: Installation
Recheck all connections and power-on condition of modem. Note: For connection to other devices or more installation details, refer to the Detailed Installation sub-section. 4 • • • • Installation TX001-00-00 Rev 101 QuickSilver DV202S Video Transmitter... -
Page 13: Cru
CRU as shown in Table 2. Table 2 Note: Failure to configure additional CRUs as CRU DIP Switch Configuration shown can result in improper operation of the system. Installation • • • • 5 TX001-00-00 Rev 101 QuickSilver DV202S Video Transmitter... - Page 14 Figure 6 Transmitter Quick Installation 6 • • • • Installation TX001-00-00 Rev 101 QuickSilver DV202S Video Transmitter...
-
Page 15: I-Modem Modem
Modem manual Troubleshooting section. 8. Power-off the computer and ISDN Modem. 9. Disconnect DB connector from computer. Attach 25 to 9 pin Adapter to the end, if required. Installation • • • • 7 TX001-00-00 Rev 101 QuickSilver DV202S Video Transmitter... - Page 16 Modem has linked up with ISDN line. Figure 8 3. Power-on Transmitter. Power-on LED ISDN Modem Installation should illuminate. Transmitter is now ready for dial-in use. 8 • • • • Installation TX001-00-00 Rev 101 QuickSilver DV202S Video Transmitter...
-
Page 17: Detailed Installation
Use a BNC type T connector to loop the input. Installation • • • • 9 TX001-00-00 Rev 101 QuickSilver DV202S Video Transmitter... - Page 18 Recheck all connections and the power-on condition of the modem. 10. Refer to the Operation section of this manual. 10 • • • • Installation TX001-00-00 Rev 101 QuickSilver DV202S Video Transmitter...
- Page 19 6. Power-on the computer and go to the Microsoft Windows operating system. If the Modem software has not been installed and configured, refer to the Modem manual for instructions. Installation • • • • 11 TX001-00-00 Rev 101 QuickSilver DV202S Video Transmitter...
- Page 20 ISDN line. Figure 11 3. Power-on Transmitter. Power-on LED should illuminate. The Transmitter is ISDN Modem Operation now ready for dial-in use. Figure 12 ISDN Modem Front Panel 12 • • • • Installation TX001-00-00 Rev 101 QuickSilver DV202S Video Transmitter...
-
Page 21: Dv202S Transmitter Directly Connected To Receiver
3. Power-on the Transmitter and verify that the Power LED illuminates solid. 4. Power-on the computer and go to Microsoft Windows operating system. Double click on the QuickSilver RS-232 icon. Refer to the Operation Section of this manual. Installation • • • • 13 TX001-00-00 Rev 101 QuickSilver DV202S Video Transmitter... - Page 22 PINS 1,4 AND 6 PINS 1,4 AND 6 SHOULD BE TIED TOGETHER SHOULD BE TIED SHOULD BE TIED AT BOTH ENDS. TOGETHER. TOGETHER. Table 3 RS-232 Direct Connect Cable Wiring 14 • • • • Installation TX001-00-00 Rev 101 QuickSilver DV202S Video Transmitter...
-
Page 23: Cru
CRU Configuration CAMERA ADD-ON DIP SWITCH 1 DIP SWITCH 2 DIP SWITCH 3 DIP SWITCH 4 MODULE (SW1) (SW2) (SW3) (SW4) NUMBER Table 5 CRU DIP Switch Configuration Installation • • • • 15 TX001-00-00 Rev 101 QuickSilver DV202S Video Transmitter... - Page 24 Table 4. Figure 17 CRU Stacked Configuration 16 • • • • Installation TX001-00-00 Rev 101 QuickSilver DV202S Video Transmitter...
- Page 25 Note: To ensure proper operation, power-on CRUs prior to powering-on the Transmitter. If using several stacked CRUs, power them on from the top down. Figure 19 CM-4 Installation Installation • • • • 17 TX001-00-00 Rev 101 QuickSilver DV202S Video Transmitter...
- Page 26 Note: To ensure proper operation, power-on CRUs prior to powering-on the Transmitter. If using several stacked CRUs, power them on from the top down. Figure 21 RM-16 Installation 18 • • • • Installation TX001-00-00 Rev 101 QuickSilver DV202S Video Transmitter...
-
Page 27: Audio Bd Internal Audio Card
Simply unsnap the latches and allow the card to tilt at a 45° angle to lift out. Figure 23 Memory Card Installation Installation • • • • 19 TX001-00-00 Rev 101 QuickSilver DV202S Video Transmitter... -
Page 28: Configuration
1KΩ to the terminal strip. The connection of the resistor is dependant upon the type of detector that is used. Refer to Figure 25. Figure 25 Typical Alarm Configuration 20 • • • • Configuration TX001-00-00 Rev 101 QuickSilver DV202S Video Transmitter... -
Page 29: Cm-4 Module
For a NC detector, the resistor must be placed in between the S input and the wire going to the detector (series to detector). Note: TeleSite recommends the use of standard practices for Alarm system companies when wiring the alarms. It is always better practice to pre-solder all connections, if required, away from the main board and use shrink wrap tubing, in addition to tie wraps. -
Page 30: Using Relay Outputs
6. Record all wire color and relay connection associations for future reference. Note: TeleSite recommends the use of standard practices for Alarm system companies when wiring the relays. It is always better practice to pre-solder all connections, if required, away from the main board and use shrink wrap tubing, in addition to tie wraps. -
Page 31: Rm-16 Module
Each Camera and PTZ unit will have a unique configuration. Use Table 6 as a guideline in connecting each device. Do not exceed the rating of 24 VDC @ 1 amp for each relay. Configuration • • • • 23 TX001-00-00 Rev 101 QuickSilver DV202S Video Transmitter... -
Page 32: Using Audio
Refer to Figure 28 for the applicable diagram. Figure 28 Basic Audio With Relays Configuration 24 • • • • Configuration TX001-00-00 Rev 101 QuickSilver DV202S Video Transmitter... -
Page 33: Operation
When connecting to the Transmitter the next time, a dialog box should request an entry and verification password when the Setup button is selected. This indicates that the Transmitter has been reset. Operation • • • • 25 TX001-00-00 Rev 101 QuickSilver DV202S Video Transmitter... -
Page 34: Troubleshooting
Verify that the Receiver audio setup in Windows has been properly configured. Verify that the Transmitter jacks have been properly wired. Verify that any amplifiers are powered-on and properly working. 26 • • • • Troubleshooting TX001-00-00 Rev 101 QuickSilver DV202S Video Transmitter... -
Page 35: Shipping Instructions
Shipping Instructions Use the following procedure when returning a unit to the factory: 1. Call or write TeleSite for a Return Authorization (R.A.) at one of the locations listed below. Record the name of the TeleSite employee who issued the R.A. -
Page 36: Reference
CAUTION: Careful selection of the proper cable is essential to obtain the best performance from this equipment. TeleSite assumes no responsibility for poor performance when cables other than those recommended are installed. In all cases, coaxial cable impedance should be 75 ohms. -
Page 37: Technical Information
Alarms: 6 inputs using 8 Terminal Block screws. (CRU) Video inputs: 4 BNC-F. Video output: 1 BNC-F. Power: 1 Coaxial type socket. Data: 1 DB25-M. Alarms: 4 inputs using 8 Terminal Block screws. Technical Information • • • • 29 TX001-00-00 Rev 101 QuickSilver DV202S Video Transmitter... - Page 38 Each relay has one set of normally opened (NO) and one set of normally closed (NC) contacts. Relay Contact Rating (all models): 24 VDC @ 1 amp maximum. 30 • • • • Technical Information TX001-00-00 Rev 101 QuickSilver DV202S Video Transmitter...
- Page 39 Video Card: SVGA type with 4 Mb RAM minimum. Must include Windows acceleration and have ability to display High (16 bit) or True (32 bit) color. Technical Information • • • • 31 TX001-00-00 Rev 101 QuickSilver DV202S Video Transmitter...
- Page 40 Width: 11.75 in. (299 mm) Height: 6.25 in. (159 mm) CRU: Length: 16.75 in (425 mm). Width: 13.0 in (330 mm). Height: 5.5 in (140 mm). 32 • • • • Technical Information TX001-00-00 Rev 101 QuickSilver DV202S Video Transmitter...
- Page 41 0 to 95% relative, noncondensing. Storage Temperature Range: -20° to 140° F (-29° to 60° C). Storage Humidity Range: 0 to 95% relative, noncondensing. Figure 34 DV202S/CRU Outline Dimensions Technical Information • • • • 33 TX001-00-00 Rev 101 QuickSilver DV202S Video Transmitter...
- Page 42 TeleSite USA Inc. Corporate Headquarters 225 County Road Tenafly, New Jersey 07670 201-568-5050 800-808-5780 Fax: 201-568-6444 www.telesiteusa.com...
