ENDEVCO 4830B Instruction Manual

Accelerometer simulator
Hide thumbs
Table of Contents

Advertisement

Quick Links

®
4830B AccelerometerSimulator
IM4830B
Instruction manual
IM4830B Rev B
October 9, 2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4830B and is the answer not in the manual?

Questions and answers

Summary of Contents for ENDEVCO 4830B

  • Page 1 ® 4830B AccelerometerSimulator IM4830B Instruction manual IM4830B Rev B October 9, 2019...

  • Page 2: Safety Considerations

    CFR 47, Class A Code of Federal Regulations: Pt 15, Subpart B The 4830B has been tested as an Unintentional radiator (sub part B) and as a Class A product RADIO AND TELEVISION INTERFERENCE NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules.
  • Page 3 Permission is granted to anyone to use this software commercially for the purpose of programming the device known as 4830B Simulator and to alter and redistribute it, provided that the following conditions are met: 1. The origin of this software must not be misrepresented; you must not claim that you wrote the original software. If you use this software to distribute a product, an acknowledgment in the product documentation would be appreciated but is not required.

  • Page 4: Table Of Contents

    Table of Contents Product description ................................ 6 User interface ................................. 7 Basic operation ................................8 3.1. Menu structure ................................8 3.2. Home screen ................................8 3.3. Editing screen ................................9 3.4. The “Profile” ................................9 3.4.1. Default profile ............................... 10 3.4.2.
  • Page 5 4.7. FFT .................................... 17 4.8. Setting the clock ............................... 17 4.9. Backlight operation ..............................19 4.10. Setting the display contrast ............................19 4.11. Output socket select ..............................20 4.12. Master reset ................................20 4.13. Battery charging ............................... 20 Calibration, maintenance and repair ........................... 22 5.1.

  • Page 6: Product Description

    The tachometer frequency is adjustable as a ratio of the respective output signal frequency. The 4830B also features the ability to analyze a vibration signal using a Fast Fourier Transfer function. This allows a voltage proportional vibration signal to be inputted to the instrument thereby providing an indication of both frequency and magnitude.

  • Page 7: User Interface

    User interface Figure 1: 4830B user interface IM4830B Rev B October 9, 2019...

  • Page 8: Basic Operation

    3.0 Basic operation 3.1. Menu structure The simulatormenusare accessed via the three menu keys as shown in Figure 2below. Figure 2: Menu structure 3.2. Home screen The home screen is in two parts, upper and lower. When the simulator is turned on, the upper screen becomes the default.

  • Page 9: Editing Screen

    Figure 4: Home screen, lower 3.3. Editing screen The editing screenis accessed by pressing either the left or right arrow keys when in the home screen. Similar to the home screen, the editing screens are in two parts, i.e. primary and secondary parameters. Scroll up or down with the arrow keys to move between parameters and the upper and lower screens.

  • Page 10: Default Profile

    edit screens. When a secondary parameter is changed the g level value will change as a result. See section 4.2.2for details. 3.4.1. Default profile The default profile is loaded for convenience when the simulator is turned ON. The default profile contains pre-set simulation parameters which cannot be permanently overwritten.

  • Page 11: Configuration

    therefore only connect an external signal to the Tach / FCN BNC once the FFT function has been selected . It should be noted that the maximum input capability of the FFT input is 5V pk. See section4.7for further details on the operation. 3.5.2.

  • Page 12: Power

    Figure 9: About screen 3.6. Power The simulator is primarily a battery powered instrument. Power comes from an internal rechargeable Li- on cell pack. A universal power adapter is supplied with the simulator which can be used to charge the internal battery or to power the simulator from an AC outlet.
  • Page 13 Examples of typical connection configurations for the 4830B are shown in Figure 11. Figure 11: Typical connection configurations IM4830B Rev B October 9, 2019...

  • Page 14: Detailed Operation

    4.0 Detailed operation 4.1. Parameter editing The editing function is the same process for all parameters with the exception of Type. From the home screen, press either the left or right arrow keys to enter the editing screens. Using the up and down arrow keys, move the cursor (inverted text) to the parameter to be edited, and select by pressing the ENTER key.

  • Page 15: Display Format

    value of the primary parameter g. Using the relationships above, the value of g will be adjusted whenever a secondary parameter is edited. This happens automatically when the new value of secondary parameter is saved. Note: This function is only operational in a user profile. 4.2.3.

  • Page 16: Accessing Stored User Profiles

    A short message follows indicating the profiles are being saved to memory. The display will now look like this: Figure 17: Profile after save PressENTER to load and view the profile. The upper home screen now shows the user profile name. The profile parameters can now be edited as previously described in paragraph 4.1.

  • Page 17: Fft

    The setting of the tachometer ratio is achieved as follows: In the profile to be edited press the left or right arrow keys. The edit menu is now displayed and the header “Select to edit” is now visible. Step down through the menu using the down arrow key until “Ratio” is highlighted.
  • Page 18 IM4830B Rev B October 9, 2019...

  • Page 19: Backlight Operation

    To set or edit the time and date parameters press the left or right arrow keys to step though the different fields: • Set hours • Set minutes • Set day • Set month • Set year Figure 21: Clock setting screen Editing of values in the field selected is achieved using the up or down arrow keys.

  • Page 20: Output Socket Select

    Figure 23: Adjust contrast screen Using the up and down arrows increase or decrease the contrast as required. Press the ENTER key to save the setting. The display will now return to the home screen. 4.11. Output socket select The mV/IEPE output can be configured to simulate either a single ended millivolt source or an IEPE biased millivolt source.
  • Page 21 Thismode covers both constant current and constant voltage modes and charges the battery to approximately 85% of its capacity in approximately 3 hours. In this mode the charge indicator will be flashing green. Once 85% capacity has been achieved, the charging will automatically switch into “Stage 2”.

  • Page 22: Calibration, Maintenance And Repair

    Stage 2 – Trickle Charge Mode This mode will deliver sufficient charge to top off the battery to 100% of its capacity in approximately 45 minutes. In this mode the charge indicator will be a solid green. Once 100% capacity has been achieved the charge indicator will extinguish.

  • Page 23: Maintenance

    Press the TOOLS menu key. Using the down arrow to move to “CONFIGURATION”.Press the ENTER key. Using the down arrow step down the menu until “Calibration” is highlighted. Press the ENTER key. The calibration manager screen is displayed. Figure 25: Calibration manager screen Using the arrow keys, input the calibration password supplied.

  • Page 24: Repair

    • The internal lithium Ion battery pack - which will deteriorate as a function of time and usage. • The front panel keypad It is recommended the replacement of both the battery pack and key pad after approximately 3 years or in the case of the battery pack 300 charging cycles, whichever is sooner.

  • Page 25: Opening And Running The Utility

    If using Windows 7, locate the 4830B SimulatorUtility Setup Vxxx application file on the CD / DVD drive using windows explorer. Double click on the file to start the installation. A drop down menu will appear. Double click on “Run as administrator”.

  • Page 26: Creating And Saving Profiles / Profile Sets

    Figure 27: Utility software main screen Note that a set of 10 profiles are pre-loaded into the table. These have been loaded as part of the installer as working examples and are stored in the path shown in the profile set dialogue box. Take time to familiarize yourself with how they are constructed.

  • Page 27: Editing A Profile

    Enter the number of profiles required to make up the profile set. Click the “Create Profiles” button to generate the base template. A new window will open. Give the profile set an identification name and save to the profile sets folder. A message then appears confirming that the profiles are ready to use.
  • Page 28 Figure 30: Output socket select warning screen 6.3.2.4. Editing a parameter All parameter values can be edited either by highlighting with the mouse and overtyping, using the increase or decrease arrow keys at the side of the parameter field or the up and down arrow keys on the keyboard.

  • Page 29: Opening A Profile Set

    Connect the simulator to the host PC using the supplied USB cable. A new COM port will appear, which is the port allocated to the simulator. In the example ofFigure 32, COM5 is the port allocated to the 4830B simulator. IM4830B Rev B...
  • Page 30 Figure 32: Device Manger With the utility software open, click on the “PC Comms” tab. Select the allocated port number from the pull down menu. 6.3.7.1. Download profiles Open a profile set and ensure that some or all of the profiles are selected for use. Connect the simulator to the host PC using the supplied USB cable.

  • Page 31: Accessories

    7.0 Accessories Part Number Description QSG4830B Quick start guide Included IM4830B Instruction manual Included on CD Utility software Included on CD EP316 Twinax BNC Plug Included EP695 10-32 to BNC Adaptor Included EHM2107 Universal power supply, supplied with adaptors Included for USA, UK, EURO, JAPAN, and Australia EHM2108...

  • Page 32: Faq (Frequently Asked Questions)

    Question I’ve been unable to find the setting to tell the 4830B which output should be active(mV/IEPE, TACH, SE PE, DIFF PE). Where can I set that? Answer The 4830B outputs are active across all outputs (mV/IEPE, TACH, SE PE, DIFF PE) simultaneously.
