Summary of Contents for MT Displays Python
- Page 1 D I G I TA L SIGNAGE User Manuel mt-digitalsignage.com Issue No: 12/2015-01 Rev: 01...
- Page 2 This manual includes most important information about MT Displays Digital Signage products such as assembly, use and general care. MT Displays cannot be held responsible in case of misuse or use of non-approved parts of Digital Signage products.
-
Page 3: Table Of Contents
Content Safety Instructions ............................Shipping And Handling ..........................Product Information ............................•Python ..............................•Cobra ..............................•Boa ................................ •Viper ..............................Assembly Instructions ..........................Operating Instructions ..........................Cleaning and Maintaining ........................Storage Conditions ............................Warranty Conditions ........................... Certification ..............................Issue No: 12/2015-01 Rev: 01... -
Page 4: Safety Instructions
- unit is any contact with any type of liquid • If any above cases happen, do contact to MT Displays or your dealer. • In case of any break down, do not open or mend unit. Otherwise it will breach warranty conditions. -
Page 5: Shipping And Handling
• Use unit only for its purpose. Otherwise it will breach the guarantee • Do not insert any foreign substance into unit or power supply. This may cause serious injuries. • Before using unit, make sure reading the manual. Environmental Conditions Unit should be best used in temperature of 0-40 C and relative humidity of %20 –... -
Page 6: Product Information
Product Information Python Digital Kiosk-21,5”-Black 21,5” screen USB compartment Jack Screen Specifications Article Description Panel Model 21.5” LCD TFT UDKP0VB215 Without speakers Max Resolution 1920*1080 UDKP1VB215 With speakers Aspect Ratio 16:09 Pixel Pitch 0.24825x0.24825 Key Features Viewing Angle 89/89/89/89 Screen Size: 21,5”... -
Page 7: Cobra
Cobra Digital Kiosk-15,6”-Black, Portrait 15,6” screen USB compartment Jack Article Description Screen Specifications Panel Model 15.6” LCD TFT UDKC0VB156 Without speakers UDKC1VB156 With speakers Max Resolution 1920*1080 Aspect Ratio 16:09 Key Features Pixel Pitch 0.17925*0.17925 Screen Size: 15,6” Viewing Angle 89/89/89/89 Colour: Black Contrast Ratio... - Page 8 Cobra Digital Kiosk-15,6”-Black, Landscape USB compartment 21,5” screen Jack Article Description Screen Specifications UDKC0LB156 Without speakers Panel Model 15.6” LCD TFT UDKC1LB156 With speakers Max Resolution 1920*1080 Aspect Ratio 16:09 Pixel Pitch 0.17925*0.17925 Key Features Viewing Angle 89/89/89/89 Screen Size: 15,6” Colour: Black Contrast Ratio 400:1...
-
Page 9: Boa
Boa Digital Kiosk-21,5”-Black USB compartment 21,5” screen Jack Article Description Screen Specifications UDKB0VB215 Without speakers Panel Model 21.5” LCD TFT UDKB1VB215 With speakers Max Resolution 1920*1080 Aspect Ratio 16:09 Key Features Pixel Pitch 0.24825x0.24825 Screen Size: 15,6” Viewing Angle 89/89/89/89 Colour: Black Contrast Ratio 3000:1... -
Page 10: Viper
Viper Digital Board-21,5”-Black Jack 21,5” screen USB compartment HDMI compartment key Article Description Screen Specifications UDKV0VB215 Without speakers Panel Model 21.5” LCD TFT UDKV1VB215 With speakers Max Resolution 1920*1080 Aspect Ratio 16:09 Key Features Pixel Pitch 0.24825x0.24825 Viewing Angle 89/89/89/89 Screen Size: 15,6”... -
Page 11: Assembly Instructions
Assembly Instructions Python Digital Kiosk-21,5”-Black Boa Digital Kiosk-21,5”-Black Viper Digital Board-21,5”-Black Issue No: 12/2015-01 Rev: 01... -
Page 12: Operating Instructions
Operating Instructions 1. Product Description Our HD Media Player product could drive 1920x1080 and below this resolution LVDS Panel, can be used for all kinds of electronic products, support 1080p HD Video playback, it not only has digital multi-media all kinds of playback function, also has rich external function interface, making your product with full advantages, and making all kinds of market requirements. - Page 13 USB Disk Auto Copy function 1. Enter the menu first, then choose one of below two options: Copy Type and Copy Device, After finished the setup, exit the menu. 2. Insert USB into player, the player will copy the files in the USB Disk into SD Card automatically.
- Page 14 2.2 Zaman Ayarı Roll Text On/Off Text Color White/Black/Red/Blue/Yellow/Green/ Grey BG (Text background ) Color Transparent/White/Black/Red/Blue/ Yellow/Green/Grey Clock show OFF/HM/HMS/YMD_HM/YMD_HMS/ Roll Speed YMD_W_HM/YMD_W_HMS Low/Middle/High Clock Text Color Logo Setup White/Black/Red/Blue/Yellow/Green/Grey On/off Logo on Time 3S/5S/8S/10S/15S/20S/2 Clock Position 5S/30S/40S/50S/60S Right-Top/Left-Top Logo off Time (0S3S/5S/8S/10S/15S/20S /25S/30S/40S/50S/60S Timer Mode Every day/Every week...
- Page 15 2.4 Picture Color Temp Green 0~148 Color Temp Blue 0~148 Noise Reduction OFF/Low/Middle/High/Default Aspect Ratio Just Scan/Auto/4:3/16:9/Panorama OSD Rotate Normal/90°/180°/270° Brightness 0~100 Contrast 0~100 Color 0~100 Sharpness 0~100 Color Temp RED 0~148 Issue No: 12/2015-01 Rev: 01...
- Page 16 3. How to make the Roll text fi le To create a new fi le named SCROLL.TXT, use TXT tools to open, just like the below picture Then enter the text you need, save as ANSI code, than copy this fi le into root directory of USB/SD card.
- Page 17 After opening the file, it will display the below information, Date Time File Name Status 2013-1-1 14:21:03 2308.jpg Succeed! 2013-1-1 14:21:08 1280x720_100%.jpg Succeed! 2013-1-1 14:21:13 1920x1080_04.jpg Succeed! 2013-1-1 14:24:13 2308.jpg Succeed! 2013-1-1 14:24:19 1280x720_100%.jpg Succeed! 2013-1-1 14:24:24 1920x1080_04.jpg Succeed! 2013-1-1 14:24:34 022.avi Succeed!
-
Page 18: Cleaning And Maintaining
MT Displays assigned. MT Displays is not responsible for loss of the product, or for other incidental, special or consequential damages or expenses incurred by the purchaser, or for labour or other costs due to installation or removal or cost of repairs by other or for any other expenses not specifically stated above. -
Page 19: Certification
The warranty is in effect for the period and usage described above from the date of purchase from MT Displays. MT Displays can supply parts and accessories after warranty expires. To Claim Your Warranty 1. Please contact your distributor or reseller and explain the nature of problem with photos of the product which shows clearly defect and the environment it has been used. - Page 20 320 W Commercial Ave Moonachie NJ 07074 1633 Toll Free: 855.678.1000 T: +1 201 636 4144 info@mtdisplaysllc.com www.mtdisplaysllc.com MT DISPLAYS HUNGARY KFT Hungary, 2071 Páty, Prologis Park Budapest M1, DC2 épület T: +36 23 814 - 050 info.hungary@mtdisplays.com.tr mt-digitalsignage.com Issue No: 12/2015-01 Rev: 01...
