- Page 1 Edition ® MOVIDYN Bracket for Heat Sink 10/2001 Addendum to the Operating Instructions 1053 5217 / EN...
- Page 2 A pair of connection brackets, part number 815 841 X, is supplied with every power supply module. The connection brackets can be used with heat sink types DKE, DKS and DKF. 05287AXX Fig. 1: Installation of the connection bracket ® Addendum to Operating Instructions – MOVIDYN Bracket for Heat Sink...
- Page 3 The connection brackets are fastened at the top and bottom with the existing bolts that are used for bolting the units onto the heat sinks. 05288AXX Fig. 2: Correctly installed bracket on the underside ® Addendum to Operating Instructions – MOVIDYN Bracket for Heat Sink...
- Page 4 SEW-EURODRIVE GmbH & Co · P.O. Box 3023 · D-76642 Bruchsal/Germany · Phone +49-7251-75-0 Fax +49-7251-75-1970 · http://www.sew-eurodrive.com · sew@sew-eurodrive.com...
