ELEKTROBOCK Pocket home PH-PK20 Quick Start Manual

TECHNICAL CHARACTERISTICS
Power supply
Communication type
Frequency
Range
Protection
Output
Working temperature
CHART FOR YOUR RECORDS
interval
1 2
days
Mon
Tue
Wed
Thu
Fri
Sat
Sun
ES CONFORMITY DECLARATION
We, ELEKTROBOCK CZ s.r.o., herewith declare that the PH-PK20 product is in compliance with principal
requirements and further respective stipulations of the directive 1999/5/ES.
Issued: 1.09.2007
Send PH-PK20 for guarantee and after-guarantee service
to manufacturer's address.
CERTIFICATE OF GUARANTEE
(guarantee period for the product amounts to 2 years)
date of sale:
product No.:
stamp of shop:
examined by:
230 V/ 50 Hz
two-way
433,92 MHz
300 m 35 m
(in open space), (in built-up area)
IP20
relay, max.5 A/ 250 VAC
0 to 40°C
3 4 5
ELEKTROBOCK CZ s.r.o.
Blanenská 1763
Kuřim 664 34
Tel./fax: +420 541 230 216
www.elbock.cz
MADE IN CZECH REPUBLIC
LEAD FREE
in compliance with RoHS
6
Wireless receiver for boiler control
PocketHome
Two-way radio communication on 433.92 MHz
Indication of state by coloured LED
Superior component is the central unit PH-CJ37
Power supply 230 V/ 50 Hz
PH-PK20
WIRELESS RECEIVER FOR BOILER
WALL-MOUNTED
system component
®
Operating instructions PH-PK20
version 10.01
