Installation, Maintenance and Operating Instructions
DESCRIPTION
Floor mounted EMERGENCY DELUGE SHOWER and AERATED EYE/FACE WASH combination
unit. Shower is supplied with a 25mm stay open full flow ball valve, activated by a triangle pull rod.
Eye/Face wash is supplied with a 15mm stay open full flow ball valve,activated by a activation
paddle handle or foot pedal.
SPECIFICATIONS
SHOWER
SHOWER HEAD - 200mm ABS Cycolac
VALVE - 25mm Stainless Steel
ACTIVATOR - 304 Stainless Steel Tube
INSTALLATION
After unpacking carton, ensure all components are present. Mark out the floor and mount the bottom
stanchion section using suitable anchors (10-12mm x 50 Dynabolt). Then assemble top section (use
pipe sealant on all joints). Assemble pull rod and shower head, attach paddle handle and foot pedal.
Once the unit is completely assembled connect water supply to 32mm top inlet nipple. Failure to use
potable water can result in emergency units producing impure or contaminated water causing
possible further injury.Test unit.
NOTE : This unit should be connected to an uninterrupted source of potable water, no less than
25mm (1"), with a minimum flowing pressure of 130KPa and a maximum static pressure of 860 KPa.
OPERATION
The shower is activated by pulling the triangle pull rod. Once the valve is activated the head will
continue to discharge water until the valve is manually closed, this is done by pushing the pull rod to
the off position.
ON
The eye wash is activated by pushing the paddle
handle rearward. The unit will operate until the
paddle handle is manually pulled to the off position.
OFF Position
Ø 12mm
4 places
Base Plate
Details
25mm
FLOW DATA
EYE-WASH
FLOW PRESSURE (KPa) : 136
FLOW RATE (LPM) :
SHOWER
FLOW PRESSURE (KPa) : 34
FLOW RATE (LPM) :
SE - 607
EYE/FACE WASH
VALVE
ACTIVATOR
STANCHION
BASE PLATE
FOOT PEDAL ASSEM
OFF
ON Position
150mm
150mm
1090
36
69 103 138 172
76 76 76 76 76
EYE WASH
- Aerated, ABS Cycolac S/S Inserts
- 12mm Stainless Steel
- 304 Stainless Steel Paddle Handle
- 304 Stainless Steel Tube
- 304 Stainless Steel
- 304 Stainless Steel Tube
1753
2134
SPEAKMAN
SAFETY PRODUCTS
1650
ISO 9002
Lic QEC13179
