Trademarks Contents are subject to revision without prior notice. All other trademarks remain the property of their respective owners. Copyright Statement This publication may not be reproduced as a whole or in part, in any way whatsoever unless prior consent has been obtained. FCC Warning This equipment has been tested and found to comply with the limits for a Class-A digital device, pursuant to Part 15 of the FCC Rules.
1. OVERVIEW Thank you for choosing the Managed Industrial Gigabit Ethernet Switches. The Managed Industrial Gigabit Ethernet Switches are designed to meet the massive needs for Gigabit Ethernet network deployments and aim at Industrial applications that demand wide range of operating temperature. They are fully compliant with IEEE802.3, 802.3u, 802.3ab, 802.3z, 802.1p, 802.1q and 802.3x standards.
Page 6
H/W Specification Store and Forward Switching Mechanism Auto Crossover for MDI/MDI-X in TP Port Auto Negotiation in TP Port Half/Full Duplex Mode Operation Jumbo Frame up to : 9K Bytes MAC Address Table : 16K Non-Blocking Switching Fabric : 20Gbps VLAN ID : 4K 1 Digital Output(Alarm Relay) Switch Features...
Cable Specifications The following table contains various cable specifications for the Managed Switch. Please make sure to use the proper cable when connecting the Managed Industrial Gigabit Ethernet Switches. Cable Type Description UTP Category 3, 4, 5 (100 meters max.) 10BASE-T EIA/TIA- 568 150-ohm STP (100 meters max.) UTP Cat.
B. USB host (for more information, please refer to chapter 4.3) C. Console port (RJ-45 to RS-232) D. LEDs (for more information, please refer to chapter 3.1) E. 100/1000Mbps SFP port(s) F. 10/100/1000Mbps RJ-45 port(s) Rear Panel Figure 4. Rear Panel G.
2. INSTALLATION To properly install the Managed Industrial Gigabit Ethernet Switch, please follow the procedures listed below. Procedures covered in this chapter are described below in separate sections. Installation Requirements Unpacking the Managed Industrial Gigabit Ethernet Switch Installing the Managed Industrial Gigabit Ethernet Switch ...
Note: If any of the above items is found missing or damaged, please contact your local sales representative for support or replacement. 2.3 Installing the Managed Industrial Gigabit Ethernet Switch ATTENTION This product is intended to be mounted to a well-grounded mounting surface, such as a metal panel.
Page 11
Figure 6. Install the Managed Industrial Gigabit Ethernet Switch in vertical direction. Figure 7. Install the Managed Industrial Gigabit Ethernet Switch in horizontal direction Grounding the Managed Industrial Gigabit Ethernet Switch Grounding helps to limit the effects of noise due to electromagnetic interference (EMI).
Figure 8. Grounding wiring 2.4 Powering the Managed Industrial Gigabit Ethernet Switch The Managed Industrial Gigabit Ethernet Switch can be used with DC power 48-54 VDC with the terminal block. The terminal block is located on the upper panel of the Managed Industrial Gigabit Ethernet Switch. Before powering the Managed Industrial Gigabit Ethernet Switch, please make sure that network cables and power cables are securely connected.
Page 13
Tighten the wire-clamping screws to fix DC wires by using a flat-head screwdriver. Wire-clamping screws Relay Alarm Output Configuration Relay alarm has 3 contacts on the terminal block used to connect alarm devices such as speakers or LEDs to alert users when the redundant power or a port link is disconnected.
Relay Note: If there is no power redundancy, the relay alarm is not available. Insert positive or negative wire Use a flat-head screwdriver to loosen and tighten the screw Figure 9. Illustration of wiring the terminal blocks 2.5 Connecting the switch to Network Connect to Network This Managed Industrial Gigabit Ethernet Switch has 2 uplink ports (RJ-45 or SFP) and 8 downlink 10/100/1000Mbps RJ-45 ports for you to implement it in...
3.1 LED Definitions Definition Color Operation Device is powered down. Power Green Device is powered on. Device is powered down. Power Green Device is powered on. Orange System is booting up. Green System is working normally. When a USB is inserted, the Status LED indicator will blink 3 times in green.
4. MAINTENANCE It is easy to use and maintain this Managed Industrial Gigabit Ethernet Switch. The procedures are suggested when you want to identify faults, perform hardware replacement and firmware upgrading. 4.1 Fault Identification Identifying faults can greatly reduce the time required to find the problem and solution.
any Warranty. 4.3 Firmware and Configuration Upgrade This Managed Industrial Gigabit Ethernet Switch may perform firmware and configuration upgrading when required. New firmware can be obtained from your sales representative. For detailed upgrading procedures, please refer to the Network Management User’s Manual. Automatic Firmware and Configuration Upgrade via USB host The Managed Industrial Gigabit Ethernet Switch’s firmware and configuration can also be upgraded automatically via USB host.
Page 18
Firmware Upgrade Firmware upgrade Plug in USB disk and reboot* Upgrade Complete Configuration Upgrade Configuration upgrade and reboot** *Firmware upgrade process would be skipped if: The firmware file is not authorized (wrong admin/password or unauthorized). The file is too big (>16MB). ...
