EZ Dock EZ Kayak Launch 200900 Owner's Manual And Installation Instructions

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
EZ KAYAK
LAUNCH
®
Model: 200900
Owner's Manual and
Installation Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EZ Kayak Launch 200900 and is the answer not in the manual?

Questions and answers

Summary of Contents for EZ Dock EZ Kayak Launch 200900

  • Page 1 EZ KAYAK LAUNCH ® Model: 200900 Owner’s Manual and Installation Instructions...

  • Page 2: Table Of Contents

    …….…………………….17 Dear EZ Dock Owner, The EZ Dock team thanks you for your purchase. We know that you had other choices of kayak ports, and we appreciate your decision to purchase the EZ Kayak Launch. You will find it easy to maintain your EZ Kayak Launch and to add accessories and other components to your dock in the future.

  • Page 3: General Information And Installation Overview

    GENERAL INFORMATION AND INSTALLATION OVERVIEW GENERAL INFORMATION The EZ Dock system and the EZ Kayak Launch are uniquely simple, low-maintenance designs that are versatile, safe, and durable. EZ Dock’s patented one-piece, self-floating design is fast and easy to install. Sections come in several sizes with evenly spaced coupler, hardware, and anchor pockets.

  • Page 4: Ez Kayak Launch Specifications

    EZ KAYAK LAUNCH 103547 PATCH SPINDWELD 1.125” - 51A BEIGE 00900 PORT WARNING GRAPHIC, KAYAK PORT 201030 POCKET FILLER, EZ DOCK BEIGE 00880 EZ DOCK BAR CODE GRAPHIC 110236 NUT 5/16-18 (4) PG X 9/16 316SS w/ PLATE 9000028 HYDROPHOBIC VENT 103565 SPINWELD 1.125”-1/4”NPT...
  • Page 5 EZ Kayak Launch Handrails - 200683 (Optional) PART NUMBER DESCRIPTION S20683 HANDRAILS, EZ KAYAK LAUNCH 80575SS BOLT, 5/16” X 18 PHILLIPS HEAD 11703 WASHER ,5/16” EZ Kayak Launch Bunks - 208112 (Optional) PART NUMBER DESCRIPTION S28112 WEAR STRIP, EZ KAYAK LAUNCH 80575SS BOLT, 5/16”...
  • Page 6 Site Conditions to be Considered Every EZ Dock EZ Kayak Launch installation is site specific and needs to be configured specifically for the end user’s intended application. Some factors to take into consideration when determining the components necessary for a proper installation include: intended usage, water conditions, soil/bed conditions, and climate conditions.

  • Page 7: Customer Service Assistance

    Model/Serial Number You should register your EZ Dock product to ensure proper warranty coverage. The location of the serial number may be difficult or impossible to see once installed, so we suggest that you create a record of your serial numbers and corresponding dock sections prior to installation to insure proper identification when filing a warranty claim.

  • Page 8: Ez Kayak Launch Installation Methods

    1A. EZ Dock Coupler Installation (301100) The EZ Kayak Launch mounts to existing or new EZ Dock installations using standard EZ Dock couplers kits (301100 or 315100). It can be connected to either our low profile 8” dock or to the standard 15” dock via the 6 cou- pler pockets on each respective side as shown in Figures 3 and 4.
  • Page 9 1A (Cont). EZ Dock Low ProfileCoupler Installation (315100) PART NUMBER DESCRIPTION 200900 KAYAK LAUNCH Figure 4. 15**** DOCK SECTION, LOW PROFILE 315010 COUPLER SET 9000010 IN-WATER INSTALLATION TOOL For more information go to www.ez-dock.com.
  • Page 10 8. Pull up on the in-water installation tool to seat the bottom coupler. (NOTE: The EZ Dock and EZ Kayak Launch must be sitting level on the water and at the Figure 4.

  • Page 11: Installation Of The Ez Kayak Launch To A Floating Dock Using A Hinge Kit

    BRKT, DOCK ADAPTOR HINGE TO FLOAT—SS  Pry-bar (small and large) 80580SS NUT 5/8”-11 LOCK, SELF LOCKING 18-8 SS  Hammer (rubber mallet) 8011 CLIP HITCH PIN #11, EZ DOCK SS  WOODEN DOCK Pliers  Tape Measure  Drill ...

  • Page 12: Ez Kayak Launch Accessories

    2. EZ Kayak Launch Accessories 2A. Handrail Extension Kit Installation (200683) Note: Recommended to be installed in water Note: Handrails are not side specific. 1. Line up bolt holes on handrails to the t-nuts on the entry of the port.. 2.

  • Page 13: Bunk Kit Installation

    2B. EZ Kayak Launch Bunk Kit Installation (208112) Bunks can be attached to the EZ Kayak Launch to keep the hull of watercraft from rubbing on the port while also stabilizing the water craft due to any angle of dead rise on the hull. Made from HPDE material for mar and slick surfacing.
  • Page 14 4A. Launching Instructions for Kayak #1 Enter the watercraft and prepare for launch After geared up, make sure the watercraft is stable on the launch. Next, enter the EZ Kayak Launch from the opening in the middle of the launch and step on/into the watercraft. Once seated, comfortable, and ready to port, grab the paddle/oar and insert into first slots.
  • Page 15 Launch moves with the changing water levels and protects your watercraft from wind, wave, or other environmental conditions. The EZ Kayak Launch comes from the factory accepting most common paddle craft, however EZ Dock offers accessories to accommodate less common water craft. Launching your watercraft should require only minimal effort and one person should be able to pull the watercraft back into the water.
  • Page 16 4C. Launching Instructions For Standup Paddleboard (SUP) #1 Setting up the SUP Place the SUP with the rear towards the exit and is just supported by the launch. Step onto the SUP with the paddle in the operators hands. -Do not attempt to launch while people or pets are standing on the launch or adjacent dock sections.

  • Page 17: Porting Instructions

    4D. Porting Instructions For Standup Paddleboard (SUP) #1 Paddle Up to the EZ Kayak Launch entry Paddle up to the launch until the vessel gently comes in contact with the launch or until the operator can reach the first slot/optional handholds. As you begin to reach the launch it is advised to sit or kneel to lower your center of gravity and increase stability.

  • Page 18: Sample Configurations

    Sample Configurations For more information go to www.ez-dock.com.
  • Page 19 Sample Configurations For more information go to www.ez-dock.com.

  • Page 20: Warranty

    In order to ensure proper warranty coverage, Buyer should activate these Limited Warranties by properly registering the purchase of EZ Dock products within thirty (30) days of the date of purchase via the Registration Card provided in EZ Dock’s Owner’s Manual, or by registering online by going to www.ez-dock.com, clicking “Customer Service” and then clicking “Product Registration”.
  • Page 21 Additional information regarding EZ Dock products can be found online at ez-dock.com EZ Dock may introduce new colors, products, accessories and options throughout the year. Specifications and products listed are subject to change without notice. Some products may be shown with additional or optional equipment not available through EZ Dock. Specifications may vary for international shipments. Please check with your local dealer for more information.
