ba75359e03
12/2005
Exchange electrode
AmmoLyt
for the AmmoLyt
AmmoLyt NHA/AT
®
Insert the AmmoLyt
®
AmmoLyt
NHA reference electrode:
1
1
Remove the watering cap (1) and nut (2) from the exchange
electrode. Store both accessories. You need them if you want
to store the reference electrode.
Installation instructions
®
NHA/AT
®
NHA reference electrode
AmmoLyt NHA
Junction
Membrane
NHA/AT exchange electrode in the
2
Advertisement
Table of Contents
Summary of Contents for wtw AmmoLyt NHA/AT
- Page 1 Installation instructions Exchange electrode ® AmmoLyt NHA/AT ® for the AmmoLyt NHA reference electrode AmmoLyt NHA AmmoLyt NHA/AT Junction Membrane ® Insert the AmmoLyt NHA/AT exchange electrode in the ® AmmoLyt NHA reference electrode: Remove the watering cap (1) and nut (2) from the exchange electrode.
- Page 2 ® AmmoLyt NHA/AT ® Screw the AmmoLyt NHA/AT exchange electrode into the ® AmmoLyt NHA reference electrode without leaving any gap. A flat wrench (wrench size 13 mm) or the protective hood of the sensor is suitable as a wrench (see following figure). Protection hood Caution The membrane and junction of the electrode must never...
